Table A5 - DoubleSmart-Control - Advanced parameters
Parameter
This parameter determines which
alarm frames the device should
34. Alarm
react to and how. The parameters
configuration - 5
th consist of 4 bytes, three most
slot
significant bytes are set according
to the official Z-Wave® protocol
specification.
This parameter defines the duration
of an alarm sequence. When time
35. Alarm configura- set in this parameter passes, the
tion – duration alarm is cancelled and relays restore
normal operation, but don't recover
the state from before the alarm.
This parameter determines which
actions result in sending the scene
IDs assigned to them. Values can
be combined, for example: 1+2=3
40. S1 input – scenes means that scenes for single and
sent double click are sent.
Enabling scenes for triple click
disables the setting of entering the
device in learning mode by triple
click.
This parameter determines which
actions result in sending the scene
IDs assigned to them. Values can
be combined.for example: 1+2=3
41. S2 input – scenes means that scenes for single and
sent double click are sent.
Enabling scenes for triple click
disables the setting of entering the
device in learning mode by triple
click.
This parameter enables choos-
ing operating mode for channel
controlled with the Q1 output. For
150. First channel
timed modes (value 1, 2 or 3), time
– operating mode
is set using parameter 154 and
reaction to input change is set using
parameter 152.
This parameter enables choos-
ing operating mode for channel
controlled with the Q2 output. For
151. Second channel
timed modes (value 1, 2 or 3), time
– operating mode
is set using parameter 155 and
reaction to input change is set using
parameter 153.
152. First channel
This parameter determines how the
– reaction to input
device reacts to changing the state
change in delayed/ of S1 input in timed modes for the
auto OFF modes first channel.
153. Second channel This parameter determines how the
– reaction to input device reacts to changing the state
change in delayed/ of S2 input in timed modes for the
auto OFF modes second channel.
This parameter enables setting
154. First channel – the time parameter used in timed
time parameter for modes for the first channel. For de-
delayed/auto OFF layed/auto OFF modes it determines
and flashing modes the duration, for flashing mode it
determines the cycle period.
This parameter enables setting
155. Second chan- the time parameter used in timed
nel – modes for the second channel.
time parameter for For delayed/auto OFF modes it
delayed/auto OFF determines the duration, for flash-
and flashing modes ing mode it determines the cycle
period.
Description
1B [MSB] – Notification Type
2B – Notification Status
3B – Event/State Parameters
4B [LSB] – action:
0 – infinite
1-32400 (1s-9h, 1s step) – duration
0 – no scenes sent
1 – button pressed 1 time
2 – button pressed 2 times
4 – button pressed 3 times
8 – button held down and released
0 – no scenes sent
1 – button pressed 1 time
2 – button pressed 2 times
4 – button pressed 3 times
8 – button held down and released
0 – standard operation
1 – delayed OFF
2 – auto OFF
3 – flashing
0 – standard operation
1 – delayed OFF
2 – auto OFF
3 – flashing
0 – cancels mode and sets default state
1 – no reaction, mode runs until it ends
2 – reset timer, starts counting time from the
beginning
0 – cancels mode and sets default state
1 – no reaction, mode runs until it ends
2 – reset timer, starts counting time from the
beginning
0 – 0.1 seconds
1-32000 – 0.1-3200 seconds, in 0.1 s steps
0 – 0.1 seconds
1-32000 – 0.1-3200 seconds, in 0.1 s steps
Available setting
0x00 – no action
0x01 – turn ON,
0x02 – turn OFF
0x03 – turn ON/OFF continuously
Default Parameter
setting size
[0x04, 4 [bytes]
0xFF, 0x00,
0x00]
(Heat Alarm,
any notifica-
tion,
no action)
600 (10min) 4 [bytes]
15 (all ac- 1 [byte]
tive)
15 (all ac- 1 [byte]
tive)
0 (standard 1 [byte]
operation)
0 (standard 1 [byte]
operation)
0 (cancel 1 [byte]
mode)
0 (cancel 1 [byte]
mode)
5 (0.5 s) 2 [bytes]
5 (0.5 s) 2 [bytes]
