6. Connect power to the second Quadro Sync II card using either a 6-pin PCIe or
SATA power cable (
7. Connect one Quadro Sync II card to the other Quadro Sync II card
( in Figure 2) using the included cables between the Sync II connectors.
This dual configuration enables up to eight GPUs in a single system.
Note: There is an order requirement when connecting the second Quadro Sync II
card: CON0 (closest to the PCIE bracket) should be used to connect both cards,
as shown in Figure 2.
When using a Quadro Sync II card in a system that supports NVIDIA SLI®, an SLI
bridge does not need to be connected unless you are planning to use SLI-specific
features like SLI Frame Rendering or SLI Anti-Aliasing. These SLI modes are not
compatible with most of Sync's features.
mailto:QuadroSVS@nvidia.com
Contact
these types of configurations.

NVIDIA RTX Enterprise Driver

Quadro Sync II card does not require a dedicated driver; all the files needed to
operate it are included in the latest NVIDIA RTX/Quadro Driver. Drivers are available
on the NVIDIA Web site at http://www.nvidia.com/drivers. When choosing the
drivers for use with Quadro Sync II, select the following from the pull-down lists
(see Figure 3).
NVIDIA CONFIDENTIAL
Quadro Sync II
in Figure 2.)
Installation System Requirements
with questions if you are considering
DU-08348-001_v07 | 5
