Introduction

The NVIDIA ® Quadro® Sync II card is designed as an add-on card for NVIDIA
RTX™/Quadro series GPUs.). The NVIDIA Quadro Sync II card fits into a free PCI
Express slot within the system. The card does not use any electrical or data
connection through the PCIe bus.
The Quadro Sync II card provides the following functionalities for Quadro Pascal
series graphics boards and later:
> Synchronizes up to eight GPUs in a single system with two Quadro Sync II cards
> Allows displays driven by one or more GPUs to be synchronized to an external
Synchronization source.
> Supports External Sync up to 1000 Hz*.
> Can generate a synchronization output signal for other systems with Quadro
Sync II cards.
>
Creates a group of synchronized displays driven by a single or multiple systems.
> Enables Mosaic with Synchronization.
With Firmware 2.18 or higher:
> Sync multiply and divide: sync displays to a multiple or divisor of an external
sync signal.
> Improved sync locking speed.
>
Sync different resolutions with the same refresh rate between Quadro Sync
boards in the same or different system.
