- Page 1 Axon Fleet 3 Wireless Mic User Guide Models: AX1034, AX1035 Rev: B July 2024...
- Page 2 17800 N 85th St Scottsdale AZ 85255 Axon, Axon Evidence, Axon Fleet 3, and Axon View are trademarks of Axon Enterprise, Inc., some of which are registered in the US and other countries. For more information, visit www.axon.com/legal. All other trademarks are property of their respective owners.
-
Page 3: Table Of Contents
Axon Fleet 3 Wireless Microphone User Guide Introduction ..........................1 Hardware kit ............................... 1 Charge outside the vehicle ........................1 Get to know your wireless microphone ...................... 2 Notifications ............................3 Operation ............................. 4 Charge the battery ............................. 4 Charging status ............................. 5 Pair the microphone ........................... -
Page 4: Introduction
Wireless mic while docked. The charge base also facilitates all pairing and audio communication to the microphone while in use. The Axon Fleet 3 Hub can support up to two wireless microphones and two charge bases per vehicle. -
Page 5: Get To Know Your Wireless Microphone
These are the different components of the Axon Fleet 3 wireless microphone system: Axon Fleet 3 wireless microphone and lapel microphone Top Status LED – Mirrors the Axon Fleet 3 front camera operating mode, except for error states. Axon Enterprise, Inc. -
Page 6: Notifications
Axon Fleet 3 Wireless Microphone User Guide Audio Haptic Operating Mode LEDs Notification Notification Powering on or off One beep Once The device is ready to record Blink green (buffering) Recording an event Blink red Two beeps (every Twice (every 2... -
Page 7: Operation
Axon Fleet 3 Wireless Microphone User Guide A fully charged Axon Fleet 3 wireless microphone battery has enough power for approximately 14 hours of normal operation. Charge your microphone for a minimum of 1.5 hours after a typical 12-hour shift. -
Page 8: Charging Status
Axon Fleet 3 Wireless Microphone User Guide While docked, the wireless microphone’s top and front Status LEDs show information on the charge level. The LEDs display as yellow when below 100% charge and green at full charge. Below Full Charge: Status LED is yellow Fully Charged: Status LED is green The first time the wireless microphone is docked in a charging base, it enters the pairing process. -
Page 9: Firmware Updates
Axon Fleet 3 Wireless Microphone User Guide Firmware updates for the Axon Fleet 3 wireless microphone and charging base are executed through the Fleet Dashboard application. Always dock the wireless microphone before installing a Fleet 3 update so the wireless microphone also receives the latest update. -
Page 10: Battery Exceeds Thermal Limits
Axon Fleet 3 Wireless Microphone User Guide When the microphone’s battery is too hot or too cold to operate, you’ll enter a thermal shutdown mode. If the microphone is undocked, it turns off immediately. If the microphone is docked, the displays shows TEMP. -
Page 11: Battery Status: Partial
Axon Fleet 3 Wireless Microphone User Guide Control: Battery partial icon with charge percentage shown on screen. If the wireless microphone encounters an error state, restart the wireless microphone to recover it. Control: The Status LED blinks yellow , ERROR displays on the screen. -
Page 12: Lapel Mic Plugged In
Axon Fleet 3 Wireless Microphone User Guide Control: Plug your lapel mic accessory into the right side of your wireless mic. When plugged in, the screen shows a mic icon next to the signal strength bars. Unplugging the lapel mic removes the icon. -
Page 13: Power Off
Axon Fleet 3 Wireless Microphone User Guide When attempting to record while out of range, the request fails. The microphone shows UNAVAILABLE and emits an error sound and haptic vibrations. The system then reverts to its original state. Control: Press Power for three seconds. Power down sound, devices turns off. -
Page 14: Recording Stop
Axon Fleet 3 Wireless Microphone User Guide Control: You can't terminate active recordings from the wireless microphone. All recording termination events must be initiated from the Fleet Dashboard application or the front camera primary button. LEDs go back to blinking green and display shows READY. -
Page 15: Volume Down
Axon Fleet 3 Wireless Microphone User Guide The Volume icon decreases and the wireless microphone’s speaker Control: Press Volume Down. beeps at the new volume level. At the lowest volume, the screen displays SOUND OFF and the device vibrates once. This does not change the volume of the video recording, only the volume of the microphone’s speaker. -
Page 16: Confirm Microphone Readiness With Fleet Dashboard
Axon Fleet 3 Wireless Microphone User Guide A wireless microphone ready indicator displays on Fleet 3 Dashboard’s camera view tab. The Front 1x tile has iconography on the top left that shows when a wireless microphone charging base is plugged into the Fleet 3 Hub. -
Page 17: Axon Evidence Review
MP4 format and contains the Front camera audio as an audio track, as well as one additional audio track for each wireless microphone connected to the Fleet 3 Hub. Wireless microphone audio becomes the default audio track that is used during video playback in Axon Evidence. -
Page 18: Installation
Axon Fleet 3 Wireless Microphone User Guide Unbox and separate all Fleet 3 wireless microphone components: charging base, microphone, ethernet cable, lapel microphone, windshield antenna, microphone mount. Included mounting hardware for charging base: • (5) Self-drilling #8 x ¾ screws •... - Page 19 Axon Fleet 3 Wireless Microphone User Guide Exercise caution before drilling pilot holes or screwing in the self-taping screws: ensure the surroundings are properly evaluated and you know what lies behind the mounting surface. 2. Attach the windshield antenna SMA connector to the side of the charging base. Use a 4 in/lb.
-
Page 20: Troubleshooting And Technical Information
PAIRING status, before transitioning shortly thereafter to READY status. 6. Undock the microphone and double press Event on the front of the device. Ensure the Fleet 3 front camera begins recording. This confirms the installation is successful and the communication protocols are functional. -
Page 21: Warranty And Warnings
For a full list of the warnings associated with this product, see www.axon.com. Axon Fleet 3 wireless microphone system transmission is in the frequency range of 902.4–927.6 MHz. Contact Axon for more details. Changes or modifications to the equipment not expressly approved by the manufacturer could void the product warranty and the user’s authority to operate the equipment... - Page 22 Axon Fleet 3 Wireless Microphone User Guide Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device must not be co-located or operating in conjunction with any other antenna or transmitter.
-
Page 23: Compliance Marks
Axon Fleet 3 Wireless Microphone User Guide Axon Enterprise, Inc. Page 20 of 20...
