- Page 1 Axon Fleet 3 Wireless Microphone Installation and User Manual Models: AX1034, AX1035 Document Revision: TBC Dec 2021...
- Page 2 Installation and User Manual Axon, Axon Fleet 3, Axon RapidLock, Axon View XL, Axon Evidence, and Evidence Sync are trademarks of Axon Enterprise, Inc., some of which are registered in the US and other countries. For more information, visit www.axon.com/legal.
-
Page 3: Table Of Contents
Axon Fleet 3 Wireless Microphone Installation and User Manual Table of Contents Introduction ..............................5 Getting to know the Axon Fleet 3 Wireless Microphone ..............6 Lapel Microphone Accessory ......................7 Axon Wireless Microphone Mounts ....................... 9 Mounting Information and Recommendations ................10 Clip Mount ............................ - Page 4 Axon Fleet 3 Wireless Microphone Installation and User Manual Troubleshooting ............................21 Technical Support ........................... 21 Warranty Policy ............................21 Warnings ..............................21 Radio Waves ............................21 Compliance Marks ..........................23 Axon Enterprise, Inc. Page 4 of 23...
-
Page 5: Introduction
Installation and User Manual Introduction The Axon Fleet 3 wireless microphone works with the Axon Fleet 3 camera system to provide audio for Axon Fleet 3 camera videos. The wireless microphone is not a stand-alone recording device. Before first use, the wireless microphone must be paired to the vehicle’s junction box. -
Page 6: Getting To Know The Axon Fleet 3 Wireless Microphone
Axon Fleet 3 Wireless Microphone Installation and User Manual Getting to know the Axon Fleet 3 Wireless Microphone The following images show the different components on the Axon Fleet 3 wireless microphone, TBD Axon Fleet 3 wireless microphone front If the battery status button is pressed, the battery LED displays the battery status for approximately 10 seconds and then resumes displaying the EVENT mode. -
Page 7: Lapel Microphone Accessory
Error Solid red Operation LED – Mirrors Axon Fleet 3 front camera operating mode, except for error state. When initially powering on the wireless microphone, the Operation LED will remain solid red until the wireless microphone is placed in pairing mode. - Page 8 If the lapel microphone is not connected, it is important to protect the connection socket from water or rain intrusion. Axon supplies a socket plug with a 2.5mm jack that should be inserted into the connection socket whenever the lapel microphone is not connected.
-
Page 9: Axon Wireless Microphone Mounts
Installation and User Manual Socket plug The socket plug can be attached to the Axon RapidLock mounts using the flexible lanyard by simply looping the lanyard through an opening in the mount body or looping the lanyard around the belt clip, as shown in the figures below. -
Page 10: Mounting Information And Recommendations
To engage the Axon RapidLock mount, insert the key of the wireless microphone into the lock of the mount and turn the microphone 90 degrees counterclockwise (when you are looking straight at the mount). -
Page 11: Clip Mount
Axon Fleet 3 Wireless Microphone Installation and User Manual Clip Mount The clip mount provides a quick and easy way to mount the wireless microphone on your patrol vest, jacket, or belt. 1. Insert the key on the back of the wireless microphone into the lock. - Page 12 Axon Fleet 3 Wireless Microphone Installation and User Manual Magnetic Mount Assembly and Use 1. Insert the key on the back of the wireless microphone into the lock. 2. Twist the wireless microphone, 90 degrees counter-clockwise. 3. Place the magnetic back underneath the shirt, patrol vest, or whatever you are using.
- Page 13 Axon Fleet 3 Wireless Microphone Installation and User Manual 4. Hold the back in place and place the Axon RapidLock mount over the back. Magnetic attraction will hold the wireless microphone in place. Axon Enterprise, Inc. Page 13 of 23...
-
Page 14: Wireless Microphone Operation
Recording can also be started using Axon View XL, momentarily pressing the EVENT button on Axon Fleet 3 front camera, or when the Axon Signal Vehicle unit sends a signal. The wireless microphone provides you with indications that it is recording in EVENT... -
Page 15: Muting Audio Recording
Installation and User Manual The Operation LED on top of the camera blinks red. • Recordings can only be stopped using Axon View XL or the Axon Fleet 3 Front camera EVENT button. Muting Audio Recording If your system administrator has configured your Axon Fleet 3 system to do so, you can use the function button to disable audio recording during an event. -
Page 16: Notification Reference Tables
Axon Fleet 3 Wireless Microphone Installation and User Manual Notification Reference Tables This section list all the audio, vibration, and LED indications associated with the Axon Fleet 3 wireless microphone. Audio Prompts The Axon Fleet 3 wireless microphone emits beeping sounds called “audio prompts” to notify you of the system status. -
Page 17: Led Status
LED Status Operation LED The operation LED mirrors Axon Fleet 3 front camera operating mode, except for error state. When initially powering on the wireless microphone, the Operation LED will remain solid red until the wireless microphone is placed in pairing mode. -
Page 18: Installation
Axon Fleet 3 wireless microphone hardware. Axon Fleet 3 Wireless Microphone Contents Every Axon Fleet 3 Wireless Microphone system comes with the following parts required for installation. One Axon Fleet 3 Wireless Microphone – AX1035 One charging base –... - Page 19 Additional Axon Fleet 3 wireless microphones • AB2 Sync cables (for charging from USB) • Axon Dock with bays for Axon Body 3 cameras, for in station charging of the wireless • microphones Axon Enterprise, Inc. Page 19 of 23...
-
Page 20: Installing The Charging Base
Axon Fleet 3 Wireless Microphone Installation and User Manual Installing the Charging Base Attach the Charging Base to the Fleet 3 Hub. Axon Enterprise, Inc. Page 20 of 23... -
Page 21: Troubleshooting And Other Information
For a full list of the warning associated with this product, see www.axon.com. Radio Waves An Axon Fleet 3 Wireless Microphone system transmission is in the frequency ranges of 902.4 – 927.6 MHz for some countries, and 915 – 928 MHz for other markets. Please contact Axon for more details. - Page 22 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult Axon Technical Support for help This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 23 Axon Fleet 3 Wireless Microphone Installation and User Manual Cet appareil numérique de classe B est conforme à la norme NMB-003 et RSS-247. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.
