460 HORIZON DR. SUITE 400 | SUWANEE, GA 30024 | PHONE: 770-614-6101 | FAX: 770-614-6069 | info@omix-ada.com
JEEP WRANGLER
Contents:
• Eclipse Sun Shade
• Mesh Storage Bag
NOTE: The Eclipse Sun Shade has
been designed to work for both
2dr @ 4dr models. Design allows
shade to remain in place with soft
top closed or Freedom panels in
place.
1. Before installing flip soft top to
Sunrider feature or lower top
to full down position. Freedom
panels will need to be removed
for installation on hard top
vehicles. Slide front side Velcro
straps through windshield
footman loops and secure (fig.1).
Loop rear Bungee straps over
factory sports bar and back to
strap button (fig.2)
2. Slide center Velcro strap through
center windshield footman loop.
Note: Two straps have been
provided for all years (07-09)
(10 - UP). The strap not used can
be cut away (fig.3). Connect
Bungee hooks to footman loops.
Hooks go to the inside of footman
loops (fig.4)
PHONE: M-F 8am - 5pm EST 1-800-449-6649 | EMAIL: techsupport@omix-ada.com
ECLIPSE SUN SHADE (Front: 2007-2013 2dr / 4dr JK)
®
OMIX-ADA
TECHNICAL SUPPORT
®
FOR WARRANTY INFORMATION VISIT: www.Omix-Ada.com
Copyright © 2013 Omix-Ada
Figure 1
Figure 3
, Inc.
®
Page 1/2
13579.04
Figure 2
Figure 4
