Unist SmartFlow Instruction Sheet page 8

1137400
RELOAD CURRENTLY LOADED TOOL IF YOU CHANGE IT
If you change settings for a tool that is currently loaded, you should load the tool again after
you make the settings. If you do not re-load the tool, the old settings will be used.
4. If you have made any changes to the currently loaded tool or intend to load this tool number you
must select the "Load This Tool" button on the right side of the screen. A message appears
indicating that the tool is being loaded.
SmartPAC PRO Run Mode Setup
This section shows how to make settings in the SmartPAC PRO Program mode. In Run mode, you
can view and adjust settings only for the tool that is currently loaded. You cannot create new tool
numbers or modify settings for an unloaded tool as you can in Program mode.
1. With the key set to "RUN Mode" the Main Run Mode Menu displays (see Figure 15).
Depending on the options installed, you may need to advance to the next menu screen to
view Oiler settings.
Page 8
Figure 14.
Load Tool Warning Message
Figure 15. Main Run Mode Menu
