Unist SmartFlow Instruction Sheet page 6

1137400
7. Select the "Comms Enabled" button and toggle it to TRUE as shown in Figure 11.
8. Once the previous steps are performed, press the "Apply Changes" button. After you apply
changes the SmartPAC PRO will display the message "Settings Applied".
If the SmartPAC PRO does not connect to the Oiler or if you have any questions on these
settings, you can select the Help button
Pro screen and a help window will be displayed describing each setting's purpose.
9. Once the Oiler setup is complete and you exit the setup screen to the Main initialization
menu then select the "OILER CONTROL" button again, the Oiler Ethernet Setup Menu
displays the message "Comms Okay" as shown in Figure 11.
Figure 11. Oiler Ethernet Setup Menu Showing "Comms Okay".
Page 6
Figure 10. Oiler Ethernet IP Address Setup Window.
in the upper left hand corner of the SmartPAC
USB Backup and Restore Instruction Sheet
