- Page 1 OPERATING MANUAL UG2000D SERIES SPRAY GUN CLEANERS UG2000D, UG2000DM UG2000DM UG2000D UNI-RAM CORPORATION • ONTARIO • CANADA REVISION 2015-08...
-
Page 2: Cautions And Warnings
REVISION 2015-08 INTRODUCTION Uni-ram holds many patents on designs used in its innovative products. Every machine is rigorously tested for compliance with stringent Quality Assurance standards. Follow the directions in this manual under Setup, Operation and Maintenance in order to operate this machine safely and effectively. Not following these instruction can lead to malfunction or damage to the machine. -
Page 3: Leveling, Vent And Air Supply
Inspect the shipping carton for signs of damage. It is your responsibility to report damage to the transport company. Uni-ram Corporation does not accept responsibility for shipping damage once the machine has left our warehouse. Keep the packaging materials until you are sure the machine has not been damaged during shipping. -
Page 4: Solvent Selection
MANUAL - SPRAY GUN CLEANERS - UG2000D SERIES REVISION 2015-08 SOLVENT SELECTION The adhesion quality of automotive paint has dramatically improved in recent years. The choice of sol- vent is critical. Only use good quality solvent that is formulated for your paint and intended for use with automatic spray guns cleaners. - Page 5 MANUAL - SPRAY GUN CLEANERS - UG2000D SERIES REVISION 2015-08...
-
Page 6: Operation
MANUAL - SPRAY GUN CLEANERS - UG2000D SERIES REVISION 2015-08 OPERATION PRE - CLEAN • Disconnect the spray gun from the air hose. Pour paint from the cup (when present) into a 5 gallon pail (not supplied). • Rinse cup with solvent and pour into the same 5 gallon pail for later disposal or recycling. -
Page 7: Troubleshooting Chart
MANUAL - SPRAY GUN CLEANERS - UG2000D SERIES REVISION 2015-08 TROUBLESHOOTING CHART SYMPTOM REASON CORRECTIVE ACTION After Each Step Below, Turn Timer. If solvent does not flow, WASH SOLVENT carry out next step. • Drain valve closed • Open drain valve (put in verti-... - Page 8 MANUAL - SPRAY GUN CLEANERS - UG2000D SERIES REVISION 2015-08 TROUBLESHOOTING CHART SYMPTOM REASON CORRECTIVE ACTION CLEANING PROBLEMS GUNS NOT CLEAN, After Each Step Below, Turn Timer. If guns are not clean, carry out next step. PUMP WORKING, SOLVENT FLOW •...
-
Page 9: Troubleshooting Procedures
MANUAL - SPRAY GUN CLEANERS - UG2000D SERIES REVISION 2015-08 TROUBLESHOOTING PROCEDURES PROCEDURE 1 Blocked Fluid Passage In Diaphagm Pump If the pump sounds like it is working but liquid does not flow, clear the fluid passage as follows: •... -
Page 10: Flow Diagram
MANUAL - SPRAY GUN CLEANERS - UG2000D SERIES REVISION 2015-08 FLOW DIAGRAM Use the diagram to trace the flow of compressed air and solvent. - Page 11 MANUAL - SPRAY GUN CLEANERS - UG2000D SERIES REVISION 2015-08 ACCESSORIES, CONSUMABLES and OPTIONAL PARTS art No. Description 110-430 Nozzle Adapter, Push On, Conventional Systems Only 110-430PPS Nozzle Adapter, Push On, Disposable and Conventional Systems 780-3530 Nozzle Adapter, Disposable Cup Systems Only...
- Page 12 "Conditions of Warranty" as consumables are not covered. Uni-ram reserves the right to direct the customer to ship the unit collect to the Uni-ram factory or to an approved Service Center for repair using the Uni-ram Return Goods Procedure or to repair the unit on-site.
