CYBT-423054-02/CYBT-423060-02
A I R O C ™ B l u etooth ® & B l u etooth ® Low
E n e rg y m o d u l e

General description

The Infineon AIROC™ CYBT-423054-02/CYBT-423060-02 are dual-mode Bluetooth® BR/EDR and low energy
wireless module solutions. CYBT-423054-02 include onboard crystal oscillators, passive components, and
CYW20719 silicon device. CYBT-423060-02 includes onboard crystal oscillators, passive components, and
CYW20721 silicon device.
CYBT-4230xx-02 supports a number of peripheral functions (ADC, PWM), as well as multiple serial communication
protocols (UART, SPI, I
compatible with Bluetooth® 5.0 in a small 11.0 × 11.0 × 1.70 mm module form-factor.
CYBT-4230xx-02 includes an integrated chip antenna, is qualified by Bluetooth® SIG, and includes regulatory
certification approval for FCC, ISED, MIC, and CE.

Features

CYBT-4230xx-02 is fully integrated and certified solution that provides all necessary components required to
operate Bluetooth® communication standards:
• Proven hardware design ready to use
• Ultra-flexible supermux I/O designs allows maximum flexibility for GPIO function assignment
• Large nonvolatile memory for complex application development
• Over-the-Air (OTA) update capable for development or field updates
• Bluetooth® SIG qualified with QDID and declaration ID
• ModusToolbox™ provides an easy-to-use integrated design environment (IDE) to configure, develop, program,
and test your Bluetooth® application
• Module description
- Module size: 11.00 mm × 11.00 mm × 1.70 mm
- Complies with Bluetooth® Core specification version 5.0 and includes support for BR, EDR 2/3 Mbps, eSCO,
Bluetooth® LE, and LE 2 Mbps features.
• QDID:
152533
• Declaration ID:
- Certified to FCC, ISED, MIC, and CE standards
- 1024-KB flash memory, 512-KB SRAM memory
- Industrial temperature range: –30 °C to +85 °C
- Integrated Arm® Cortex®-M4 microprocessor core with floating point unit (FPU)
• RF characteristics
- Maximum TX output power: +4.0 dbm
- RX receive sensitivity: –95.5 dbm
- Received signal strength indicator (RSSI) with 1-dB resolution
• Power consumption
- TX current consumption
• Bluetooth® silicon: 5.6 mA (MCU + radio only, 0 dbm)
- RX current consumption
• Bluetooth® silicon: 5.9 mA (MCU + radio only)
- CYW20719/21 silicon Low-power mode support
• PDS: 6.1 µA with 512 KB SRAM retention
• SDS: 1.6 µA
• HIDOFF (external interrupt): 400 nA
Datasheet
www.infineon.com
Arrow.com.
Downloaded from
2
2
C, I
S/PCM). CYBT-4230xx-02 includes a royalty-free Bluetooth® Low Energy stack
D050854
Please read the Important Notice and Warnings at the end of this document
page 1 of 55
002-30912 Rev. *C
2024-03-12
