Installation • Instalación
Installation • Instalação
Allgemeine bauaufsichtliche Zulassung
BEKO
Z-83.5-9 Deutsches Institut für Bautechnik, Berlin
Deutsches Institut für
Bautechnik, Berlin
Zulassungs-Nummer Z-83.5-9
5.51
QWIK-PURE CS 200
®
0.35
5.31
0.35
1.25
0.47 5.51
1.57
Note:
Shut off condensate drain outlet until the
oil-water separator has been installed and
is ready to be put into service!
Atención:
¡Mantenga cerrada la salida del purga-
dor de condensado hasta que finalice la
puesta en marcha!
14
Bottom view
Vista desde abajo
Vue de dessous
Vista do fundo
1
QWIK-PURE
A
0.39
Important:
Condamner la conduite d´évacuation du
condensat jusqu´à la fin de l´installation!
Atenção:
Mantenha fechada a saída do purgador
de condensação até o final da colocação
em funcionamento!
The QWIK-PURE
has been approved for the treatment of
compressor condensates by the Institute
of Construction Engineering, Berlin. In
Germany, it is therefore not necessary
to apply for an operating permit.
Please check the relevant legal regula-
tions in your country. You should also
contact the public authorities in your area,
since there may be regional variations.
1. Area of installation
3
• Sealed floor or spill basin !
( > 10 l : QWIK-PURE
> 19 l : QWIK-PURE
It is crucial to ensure that untreated
condensate or oil cannot get into the
sewer system in the event of damage.
• The floor area must be stable and level
(max. inclination 1°) to ensure reliable
functioning of the QWIK-PURE
2. Installation
1
See enclosed assembly drawing!
Floor mounting
Use elongated holes of the 4 mounting
(1) feet. Screws and dowels supplied with
1
unit.Install the QWIK-PURE
3.93
to plumb line (± 1°).
Wall mounting
CS 100
®
Fix mounting brackets (2) perpendi-
cularly on the wall.
Push in QWIK-PURE
A
mounting area (3) and lock home clamp
2
(4).
QWIK-PURE
4
ing brackest (2), screw lateral support
bracktes (5) onto QWIK-PURE
A A -
and install at the wall.
Lay condensate feed line(s) along the
wall with a downward slope. Hoses must
3.93 always be fixed in such a manner that they
6.69
do not make flapping movements and lead
to injuries and/or damage.
Lay water discharge line with a continu-
ous downward slope to the wastewater
discharge point. Install siphon to avoid
disagreeable smells.
An area of installation must be chosen
where untreated condensate cannot
reach the public sewer system.
english
CS oil-water separator
®
CS 100,
®
CS 200)
®
CS.
®
CS unit true
®
CS 100 with
®
CS 200 : mount on mount-
®
CS 200
®
QWIK-PURE CS 100, 200
®
