Diesel generator

Advertisement

DDAE
10500
DSE-3G
Diesel generator
USER'S MANUAL
www.daewoopowerproducts.com
Manufactured under license of Daewoo International Corporation, Korea

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DDAE 10500 DSE-3G and is the answer not in the manual?

Questions and answers

Brants Marc
February 8, 2025

Hoe kan ik de frequentie regelen Van de generator

1 comments:
Mr. Anderson
February 11, 2025

If the indication on the voltmeter is too low or too high, the revolution speed can be adjusted to modify the generator's frequency.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for Daewoo DDAE 10500 DSE-3G

  • Page 1 DDAE 10500 DSE-3G Diesel generator USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
  • Page 2: Table Of Contents

    INDEX 1. MAIN TECHNICAL SPECIFICATIONS AND DATA.................. 2 2. USE FOR THE GENERATOR SET ......................3 3. MAINTENANCE OF THE GENERATOR SET ..................10 4. MAINTENANCE AND REMEDY OF THE GENERATOR SET ............... 12 5. APPENDIXES ............................13 WARRANTY ............................... 16...
  • Page 3: Main Technical Specifications And Data

    1. MAIN TECHNICAL SPECIFICATIONS AND DATA Max power: 8.1 kVA (400 V) 7.3 kVA (230 V) Rated power: 7.5 kVA (400 V) 6.7 kVA (230 V) Rated frequency (Hz) Engine power: 15 hp Displacement: 498 cc Rated speed (r/min) Fuel tank capacity: 15 L Oil tank capacity: 1.65 L 110-220 110-220...
  • Page 4: Use For The Generator Set

    2. USE FOR THE GENERATOR SET 2.1 Use Essentials and Cautions In order to ensure that you safely operate the generator set, be sure that you read and understand the operation manual. Especially the attention should be paid to the use main points listed below. Otherwise the personal accidents and the equipment damages may be caused.
  • Page 5 should be kept far from the welder and generator set. 2.1.6 Charge the battery. The electrolyte of the battery contains sulphuric acid. In order to protect your eyes, skin and clothes, if you touch it, it is necessary to use water for wash. If your eyes touch it, you should go to a clinic for wash.
  • Page 6 The factor of the affection, to the performance and reliability of the diesel engine, caused by your lubrication oil, is bigger than other factors. If you use any poor quality machinery oil or if you do not change the oil for your diesel engine according to the stipulation, it is easy to block up the piston. It is also to quicken the wearing of the cylinder, bearings, and other moving components so that the life of your diesel engine is reduced.
  • Page 7 rature will go up too high. On the other hand, it is also dangerous if there is too much oil. Because the machinery oil may be burned, this will make that the revolution speed of the engine increases sudden- ly and results in “abnormal fast running”. For this purpose, it is necessary to check the machinery oil and the oil level should reach the stipulated height.
  • Page 8 2. Battery Check the electrolyte level height of the battery once a month. When the liquid level goes down to a lower mark, add some distilled water to make that the liquid level goes up to a higher mark. If the electrolyte in the battery is too less, the diesel engine will not start. Because the electric power is insufficient at this time, it is necessary to keep the liquid is at a place between the higher limit and the lower limit.
  • Page 9 2.6. How to Operate the Welder and Generator Set 2.6.1 Operating the Diesel Engine Preheat the diesel engine for three minutes under the condition without any load. For the diesel engine having the low oil pressure alarm system, it is necessary to check whether the oil pressure signal indicator lights up.
  • Page 10 At the time of using 12Vfor charge, the air switch should be set at “OFF” state. On the 12Voutput terminals, a charge switch can be connected so the switch can be used for on-and-off purpose. At the time of using the automatic type battery with the battery conductors, be sure that the battery negative conductor should be disconnected at the time of charge.
  • Page 11: Maintenance Of The Generator Set

    3. MAINTENANCE OF THE GENERATOR SET 3.1 Regular Maintenance Service period Every year Daily First month or Every 3 months Every 6 months regular check 20 Hrs or 100 Hrs or 500 Hrs or 1000 Hrs Item ○ Check and replenish fuel ○...
  • Page 12 maintenance manual for each assembling section. Before carrying out the maintenance to the set, please turn off the diesel engine. If it is necessary to run the diesel engine, its surrounding should be in good ventilation to discharge the gas that contains the poison carbon monoxide.
  • Page 13: Maintenance And Remedy Of The Generator Set

    All these require special tools and skills. Do not perform the injection nozzle test near an open fire or any other kind of fire. The fuel spray may ignite. Do not expose bare skin to the fuel spray. The fuel may penetrate the skin and cause injury to the body.
  • Page 14: Appendixes

    The specified oil level should be Check the level of lubricant between upper level “H” and lower level “L” diesel Start the diesel engine according to the The speed and force to pull the engine requirements of operating proc edure of recoil starter is not enough can no start...
  • Page 15 HDY3000LX\HDY4200LX\HDY6500LX Generator Control Box FIELD STATOR LOAD AC SWITCH WINDING WINDING U1 red yellow black grey white VOLT METER AC SOCKET RECTIFIER ELECTRIC LOCK U2 black ALARM Z1 yellow INDICATOR CAPACITY WINDING black white CAPACITOR Z2 yellow fuse brown brown CHARGE WINDING RECTIFIER DC OUTPUT...
  • Page 16 EC DECLARATION OF CONFORMITY DIESEL GENERATOR Model: DDAE10500DSE-3G Brand: We GBR Corp. LTD, Room 1002, 10/F., David House, 8-20 Nanking Street, Jordan, Kowloon, Hong Kong, China, declare under our sole responsibility that this product is in conformity and accordance with the following standards and regulations. The undersigned is responsible for the compilation of technical documentation.
  • Page 17: Warranty

    WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed.
  • Page 18 Manufactured under license of Daewoo International Corporation, Korea...
