- Page 1 ASSEMBLY INSTRUCTIONS RESIN GARDEN SHED SKU: T-PS24-0436A YOUR Resin Garden House LIFE BUILDER Installation Tutorial https://www.patiowell.com/ pages/video-T-PS24-0436A www.patiowell.com saleservice@patiowell.com...
- Page 2 SITE PREPARATION Level the ground surface. Recommendation: Construct a wooden or concrete base as a foundation. The external dimensions of the product : 76.6’’ 103.1’’ 49.6’’...
- Page 3 Requires two people and takes 2-3 hours for Installation. Recommended to wear gloves to avoid scratches. Please read the manual carefully before installation. DO NOT RETURN YOUR UNIT TO THE STORE Contact us first saleservice@patiowell.com...
- Page 4 FLOOR PARTS A1 X4 A2 X4 WALL PARTS B1 X2 B2 X5 B3 X2 B5 X2 B4 X4 B1-1 X1 B1-2 X1 B4-1 X4...
- Page 5 WINDOW PARTS W1 X4 W2 X2 ROOF PARTS F1 X2 F2 X4 F3 X2 C7 X2 F4 X1 F5 X2 F6 X1 C1 X1 C2 X1 C3 X1 C4 X1 C5 X1 E3 X2 C6 X1 E2 X1 E4 X4...
- Page 6 DOOR PARTS D1-2 X2 D1 X1 D1-4 X1 D1-1 X1 ACCESSORIES C7-1 X2 F4-1 X1 F4-2 X1 E1 X2 D1-3 X1 D1-1-2 X2 D1-2-1 X1 B1-2-1 X1 A1-1 X4...
- Page 7 SCREW 179+2 54+2 inch inch SC5x14 M5*14 SC5x30 M5*30 12+2 inch inch SC4x30 M4*30 SC5x12 M5*12 CHOOSE THE LOCATION OF THE WINDOW Multiple methods exist for installing wall panels with windows, with our instructions detailing the first method of installation.(as shown in the picture) ①...
- Page 8 CONTENTS 09-13 Floor Part Instruction (page) 13-22 Wall Part Instruction (page) 23-30 Roof Part Instruction (page) 31-33 Door Part Instruction (page)
- Page 9 STEP 1 STEP 2...
- Page 10 STEP 3 STEP 4...
- Page 11 STEP 5 STEP 6...
- Page 12 STEP 7 Insert A1 at an angle.
- Page 13 STEP 8 SC5x14 Screw position SC5x14 16 pcs STEP 9 ① ② Textured side facing down. FINISH ③...
- Page 14 STEP 10 STEP 11...
- Page 15 STEP 12 STEP 13...
- Page 16 STEP 14 STEP 15...
- Page 17 STEP 16 STEP 17...
- Page 18 STEP 18 STEP 19...
- Page 19 STEP 20 STEP 21...
- Page 20 STEP 22 STEP 23...
- Page 21 STEP 24 STEP 25 Note: After installing B1-1, B1-2 in B1-1/B1-2 sequence, please measure whether the size is equal to 30mm (as shown in the picture). √ × B1-2 B1-1 SC5x14 SC5x14 6 pcs...
- Page 22 STEP 26 Do not hit the screws here yet. B4-1 SC5x14 SC5x14 21 pcs STEP 19 STEP 27 Do not hit the screws here yet. B4-1 SC5x14 SC5x14 21 pcs...
- Page 23 STEP 28 Note the snaps on C7-1. C7-1 SC5x14 SC5x14 For Front Door SC5x14 3 pcs STEP 29 Note the snaps on C7-1. C7-1 SC5x14 SC5x14 3 pcs...
- Page 24 STEP 30 SC5x14 SC5x14 SC5x14 6 pcs STEP 31 SC5x14 SC5x14 SC5x14 7 pcs...
- Page 25 STEP 32 SC5x12 SC5x12 8 pcs STEP 33 SC5x14 SC5x14 4 pcs...
- Page 26 STEP 34 SC5x30 SC5x30 4 pcs STEP 35 SC5x30 SC5x30 18 pcs...
- Page 27 STEP 28 STEP 36 Adjusting roof and wall joints with a scraper.
- Page 28 STEP 37 F4-2 F4-2 F4-1 F4-1 STEP 38 CLICK F4-1...
- Page 29 STEP 39 Note: Another person should be on the outside to hold down the roof while the screws are being driven. ① ② SC5x14 SC5x14 ④ ③ SC5x14 SC5x14 SC5x14 60 pcs...
- Page 30 STEP 40 SC5x14 SC5x14 24 pcs...
- Page 31 STEP 41 D1-2 SC5x14 √ × D1-4 SC5x14 D1-1 Note: After installing D1, D1-1, D1-4, D1-2 in sequence, please measure whether the size is equal to 167.8mm (as shown in the picture). SC5x14 D1-2 8 pcs STEP 42 D1-1-2 D1-3 D1-2-1 SC4x30 SC5x30...
- Page 32 STEP 43 SC4x30 B1-2-1 SC4x30 6 pcs SC4x30 STEP 44 A1-1...
- Page 33 STEP 45 SC5x30 SC5x30 30 pcs...
- Page 34 CARE & SAFETY • In case of fire, do not attempt to extinguish any burning polypropylene with water Unsuitable for storage of flammable or corrosive substances. • It is of utmost importance to assemble all of the parts according to the directions. Do not skip any step.
