Exclusion of liability ZIEHL-ABEGG SE is not liable for damage due to misuse, incorrect use, improper use or as a consequence of unauthorized repairs or modifications.
Assembly instructions – model series ZAtop Safety precautions Requirements placed on the personnel / due diligence Danger! " Installation, connection to the power supply and commissioning may only be performed by qualified service personnel! The relevant regulations must be observed! "...
Assembly instructions – model series ZAtop Versions of the brake 4 Versions of the brake RSO 1300 - ZAtop SM250.60B Figure 4-01 Figure 4-02 - Brake with a mechanical hand release system RSO 1800 - ZAtop SM250.80D/SM250.100C Figure 4-03 Figure 4-04 - Brake with a mechanical hand release system...
Assembly instructions – model series ZAtop Scope of delivery 5 Scope of delivery • Brake • Assembly kit brake - article number 70029992 (optionally available) Figure 5-01 Figure 5-02 - Brake bodies 1 in version with hand release A-TIA20_10-GB 2021/21 Index 003 Part.-No.
You must discharge your own body before touching. This can be done, for example, by touching a conductive, earthed object (for example bare metal switch cabinet parts) immediately before. Figure 7-01A - ZAtop SM250.60B Figure 7-01B - ZAtop SM250.80D/100C 1. ZAtop SM250.80D/100C: Unscrew the 4 socket cap screws M5 x 10 - 8.8 (2) with a size 4 allen wrench.
Page 9
Assembly instructions – model series ZAtop Dismounting the brake Figure 7-04 Figure 7-05A - ZAtop SM250.60B Figure 7-05B - ZAtop SM250.80D/100C Figure 7-06 8. Remove the covers (7). 9. Dismounting absolute encoder (8), see "Replacement of the absolute encoder A-TIA17_02-..."...
Page 10
RSO 1300 - Socket cap screw M16 x 250 (11) with a size 14 allen wrench RSO 1800 - Hexagon head bolts M20 x 300 (11) with a size 30 screw wrench 14. Replace the two fixing screws (11) with threaded bolts (12) from the ZIEHL-ABEGG tool set, item number 70027450:...
Page 11
Assembly instructions – model series ZAtop Dismounting the brake Figure 7-11 Figure 7-12 20. Detach the brake rotor 2 (14) from the toothed hub. The brake rotor may only be detached by hand. ATTENTION! Do not use screwdrivers to release the brake rotor. The screwdrivers damage the friction lining.
Assembly instructions – model series ZAtop Mounting the brake 8 Mounting the brake During the mounting as well as the dismounting also the operating manual of the brake has to be observed. Risk of death! Incorrect mounting can have a detrimental impact on the braking action. Attention! "...
Page 13
Assembly instructions – model series ZAtop Mounting the brake Figure 8-05 Figure 8-06 8. Slide brake body 1 (16) slightly over the threaded bolts Attention! Note the weight of the brake body. RSO 1300 - Approx. 75 kg. RSO 1800 - Approx. 100 kg. 9.
Page 14
Assembly instructions – model series ZAtop Mounting the brake Figure 8-09 Figure 8-10 19. On the design with levers for hand release only: Slide the 2 tension blocks (16A) for brake body 2 (13) onto the 2 hexagon head bolts on the levers for hand release with the projection pointing towards the outer diameter of the brake and towards brake body 2 (13).
Page 15
Assembly instructions – model series ZAtop Mounting the brake Figure 8-13 Figure 8-14 24. Replace the two threaded bolts (12) with fixing screws (11): RSO 1300 - Socket cap screw M16 x 250 (11) RSO 1800 - Hexagon head bolts M20 x 300 (11) 25.
Page 16
Assembly instructions – model series ZAtop Mounting the brake Figure 8-17 Figure 8-18 Figure 8-19A - ZAtop SM250.60B Figure 8-19B - ZAtop SM250.80D/100C 35. Tighten the cover hoods (7). 36. ZAtop SM250.80D/100C: Attach the encoder flange (10) with the fastening lug.
Page 17
Figure 8-22 and Figure 8-23) inside the cover of the junction box (1). 41. Fit strain reliefs (4). Figure 8-24B - ZAtop SM250.80D/100C Figure 8-24A - ZAtop SM250.60B 42. Close the cover (1) of the junction box. 43. ZAtop SM250.80D/100C: Screw on the cover (1) with the 4 socket cap screws M5 x 10 - 8.8 (2) with a torque wrench for...
Assembly instructions – model series ZAtop Functional test on microswitch/inductive proximity switch for release monitor 9 Functional test on microswitch/inductive proximity switch for re- lease monitor After mounting of the brake, a functional test must be performed on the micro switches/inductive proximity switches (see chapter "Brake operating instructions - release monitor"...
Page 19
Assembly instructions – model series ZAtop Functional test on microswitch/inductive proximity switch for release monitor A-TIA20_10-GB 2021/21 Index 003 Part.-No. 01013487-GB 19/20...
