Summary of Contents for ZIEHL-ABEGG ZA top SM200.15D
-
Page 2: Table Of Contents
Assembly instructions – model series ZAtop Content General ..............Structure of the assembly instructions . -
Page 3: General
Exclusion of liability ZIEHL-ABEGG SE is not liable for damage due to misuse, incorrect use, improper use or as a consequence of unauthorized repairs or modifications. -
Page 4: General Safety Instructions
Assembly instructions – model series ZAtop Safety precautions General safety instructions Danger! " " The elevator machine has attachment points: integrally cast eyelets or screwed-on eye bolts, eye plates or steel cable loops. The attachment points are designed exclusively for transporting the elevator machine including brake and traction sheave. -
Page 5: Versions Of The Brake
Assembly instructions – model series ZAtop Versions of the brake 4 Versions of the brake Figure 4-01 - Brake without a mechanical hand release system Figure 4-02 - Brake with a mechanical hand release systemFigure 4-03 - Brake with hand release for bowden cable A brake with a mechanical hand release system is available optionally. -
Page 6: Scope Of Delivery
Assembly instructions – model series ZAtop Scope of delivery 5 Scope of delivery • Brake • Tool kit for brake exchange and encoder exchange - Article number 70030741 (optionally available) • Assembly kit brake - Article number 70029992 (optionally available) Figure 5-01- Delivery parts Figure 5-02 - additional delivery parts brake with manual release system Designation... -
Page 7: Tools Required
Assembly instructions – model series ZAtop Tools required Designation Pos. Count Hand release lever set 21A - Hand release lever set for hand-operated version 21B - Hand release lever set for bowden cable Wire-end sleeves Micro-active cloth Feeler gauges, 13-part Anti tamper paint 20 ml Technical vaseline 50 g ®... -
Page 8: Dismounting The Brake
Assembly instructions – model series ZAtop Dismounting the brake 7 Dismounting the brake During the mounting as well as the dismounting also the operating manual of the brake has to be observed. Risk of death! When dismounting the brake make sure that the cabin and the counterweight are mechanically secured against movement! Caution! "... - Page 9 Assembly instructions – model series ZAtop Dismounting the brake Figure 7-05 8. Remove the absolute encoder (12), see assembly instructions "Replacement of the absolute encoder - A-TIA17_02-..." Figure 7-07 Figure 7-06 9. Using the tightening wrench (13) and a wrench size 32, unscrew the adaptor shaft for the absolute encoder (14) from the drive shaft.
- Page 10 Assembly instructions – model series ZAtop Dismounting the brake 12. Completely unscrew the four hexagon head screws (17) alternately diagonally using a wrench. RTW 250 - ZAtop SM200.15D: loosen hexagon head screws M8 x 110 - 10.9 (17), wrench size 13 RTW 350 - ZAtop SM200.23D: loosen hexagon head screws M10 x 110 - 8.8 (17), wrench size 16 RTW 450 - ZAtop SM200.30D:...
-
Page 11: Mounting The Brake
Assembly instructions – model series ZAtop Mounting the brake 8 Mounting the brake During the mounting as well as the dismounting also the operating manual of the brake has to be observed. Risk of death! Incorrect mounting of the brake can have influence to the braking action! Caution! "... - Page 12 Assembly instructions – model series ZAtop Mounting the brake RTW 450 - ZAtop SM200.30D approx. 45 kg RTW 800 - ZAtop SM200.40E and SM200.45E approx. 71 kg Figure 8-05 Figure 8-06 8. Slightly screw on the brake body (18) with the 4 hexagon head bolts (17). Do not forget the washers! 9.
- Page 13 Assembly instructions – model series ZAtop Mounting the brake Figure 8-09 16. Check the air gap "A" between the coil carrier and armature disc with the feeler gauge when de-energised. ZAtop SM200.15D, SM200.23D and SM200.30D: Air gap 0.3 mm ≤ "A" ≤ 0.5 mm ZAtop SM200.40E and SM200.45E: Air gap 0.4 mm ≤...
- Page 14 Assembly instructions – model series ZAtop Mounting the brake 18. Fix the cover plate (11 ) with the two cylinder head screws M6 x 12 - 8.8 (6) with torque wrench with allen wrench size 5 and washers (7). Tightening torque: 9.5 Nm 19.
-
Page 15: Functional Test On Microswitch/Inductive Proximity Switch For Release Monitor
Assembly instructions – model series ZAtop Functional test on microswitch/inductive proximity switch for release monitor 9 Functional test on microswitch/inductive proximity switch for re- lease monitor After mounting of the brake, a functional test must be performed on the micro switches/inductive proximity switches (see chapter "Brake operating instructions - release monitor"... - Page 16 Customer Service phone +49 7940 16-308 +49 7940 16-249 drives-service@ziehl-abegg.com Headquarters ZIEHL-ABEGG SE Heinz-Ziehl-Straße · 74653 Künzelsau Germany phone +49 7940 16-0 · fax +49 7940 16-249 drives@ziehl-abegg.de · www.ziehl-abegg.com...
