Step 1 - Attach Corner Pieces to Top Panel

•
Parts Involved
•
Attach the corner pieces to the top panel using x6 M4 10mm Button Head Fasteners.

Step 2 - Attach Corner Pieces and Feet to Bottom Panel

•
•
Parts Involved
•
Attach the Corner Pieces to the Bottom Panel using x6 M4 10mm Fasteners in the marked holes
below.
Revision 1.00
a
Top Panel x1
e
Corner Pieces x2
b
Bottom Panel x1
e
Corner Pieces x2
f
Feet x2
•
M4 x 10mm Button Head Fasteners x6
•
Vertical GPU Mount
•
M4 x 10mm Fasteners x6
•
M4 x 6mm Fasteners x2
