Summary of Contents for GeoVision GV-Mount107
- Page 1 GV-A/T/EBD Series IP Camera Mount Installation Guide GV-Mount107 GV-Mount511 Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. MT-ATEBDSERIES...
- Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
- Page 3 Contents Preface ........................1 1. Pendant Mounting with GV-Mount107 ................. 2 2. Wall Box Mounting with GV-Mount511 ................. 5...
- Page 4 Preface Welcome to the GV-A/T/EBD Series IP Camera Mount Installation Guide. This Installation Guide is designed for the following models: Model Model Number Multi-Sensor IR IP Dome GV-TMS8800...
- Page 5 1. Pendant Mounting with GV-Mount107 + Mount511 GV-Mount107 GV-Mount511 GV-Mount107 Packing List GV-Mount107 Pendant Mount Bracket Pendant Tube Tube Connector Torx Wrench Applicable Models: GV-TMS8800 Note: Before installing GV-Mount107, note the following: Prepare 3 long screws for securing the Pendant Bracket to the ceiling.
- Page 6 GV-Mount107 + GV-Mount511 Installation Place GV-Mount107 on the ceiling and mark the location for the center socket and the 3 screws. Drill the marks and secure the Pendant Bracket onto the ceiling. Attach one end of the Pendant Tube to the Pendant Bracket, and the other end to the Tube Connector.
- Page 7 Fix the camera base to GV-Mount511, adjust the lens angle, and fix the housing to the camera base. Caution: Do not pull hard when leading the tail cables; otherwise, it will cause loose or disconnected tail cables.
- Page 8 2. Wall Box Mounting with GV-Mount511 Packing List GV-Mount511 M3 Screw (25 mm) x 4 M3 Screw (12 mm) x 2 Screw Anchor x 4 Drill Template Paster Applicable Models GV-TMS8800 GV-Mount511 Installation Drill 4 mounting holes and a hole at the center socket location on the wall using the drill template paster.
- Page 9 Unscrew the four screws of the camera to remove the housing from the camera base. Cut open GV-Mount511 base and thread the camera cables through the center socket and waterproof the Ethernet cable. For details, see 9 Waterproofing the Cable. Fit the cables into GV-Mount511.
