TI-96
Tire Inspector
with Dunk Tank
buyTSI.com - 800.223.4540
READ INSTRUCTIONS THOROUGHLY BEFORE OPERATING
Tire Service International, LLC
Contact us for any assistance
3451 S. 40TH ST.
Phoenix, AZ 85040
800.223.4540
Office: 602.437.5020
Email: sales@buytsi.com
Fax: 602.437.5025
Revised: March 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tire Inspector TI-96 and is the answer not in the manual?

Questions and answers

Summary of Contents for TSI Instruments Tire Inspector TI-96

  • Page 1 TI-96 Tire Inspector with Dunk Tank buyTSI.com - 800.223.4540 READ INSTRUCTIONS THOROUGHLY BEFORE OPERATING Tire Service International, LLC Contact us for any assistance 3451 S. 40TH ST. Phoenix, AZ 85040 800.223.4540 Office: 602.437.5020 Email: sales@buytsi.com Fax: 602.437.5025 Revised: March 2024...
  • Page 2: General Description

    General Description The TI-96 Tire Inspector is designed to inspect non mounted tires from 13” to 24.5” using an expandable hub and rim assembly. The TI-96 allows the operator to inspect tires for tread leakage using a dunk test tank. A foot operated power lift will save time and injury by lifting those heavy tires from floor into the test tank.
  • Page 3: Primary Parts

    Primary Parts Expanding Fig. 1 Fig. 1 Hub & Rim Control Panel Tire Inflate - Hub Inflate Water Air Cylinder Dunk Tank Foot Pedal Extracter Assist Arm Lock buyTSI.com 800.223.4540...
  • Page 4 Operating Instructions • CAUTION: Operation of this machine for use other than checking tires for air leaks is strictly prohibited. • Use the foot pedal to raise the Rotating Lift Arm. • Disengage the Arm Locking Pin and rotate the Lift Arm and Expandable Hub assembly clockwise from the Pivot Post into a clear workspace.
  • Page 5: Maintenance

    Maintenance Daily, inspect assembly for loose fittings, damaged parts, or water in the expanded rim assembly. Weekly or as needed, empty, clean, and refill water in tank. Every 30 days, grease all zerks with standard Chassis grease. Expanding Rims buyTSI.com 800.223.4540...
  • Page 6: Parts Listing

    Parts Listing buyTSI.com 800.223.4540...
  • Page 7 Parts Listing buyTSI.com 800.223.4540...
  • Page 8 Pneumatic Part Listing buyTSI.com 800.223.4540...
  • Page 9 Pneumatic Parts Listing buyTSI.com 800.223.4540...
  • Page 10 Notes buyTSI.com 800.223.4540...
  • Page 11 Notes buyTSI.com 800.223.4540...
  • Page 12: California Proposition

    California Proposition 65 California’s Proposition 65 entitles California consumers to special warnings for products that contain chemicals known to the state of California to cause cancer and birth defects or other reproductive harm if those products expose consumers to such chemicals above certain threshold levels. WARNING: Some of Tire Service International’s products can expose you to chemicals including chromium compounds, which are known to the State of California to cause cancer, birth defects or other reproductive harm.
