- Page 1 MIDI INDUSTRIAL VACUUM CLEANER Version 080724 - This superseded and should be used instead of all previous versions. Please read this manual before using the www.v-tuf.co.uk For the Latest Version...
- Page 2 VLX15 V-TUF Universal Power tool Adaptor For MINI, MIDI, MIDI SYNCRO VTM103 VLX10 ROUND BRUSH - WITH HORSE HAIR 32 MM for V-TUF VACUUM CLEANER VTVS7021 V-TUF ULPA15 Cartridge Essential Filter - For MIDIHSV, MAXI50 DUST BAGS - for M & H CLASS (Pack of 10) - FSC Certified...
-
Page 3: Before Use
MIDIHSV MIDIHSV Follow these steps BEFORE USE ENSURE FULL FILTRATION IS IN PLACE. NEVER OPERATE WITHOUT FULL FILTRATION Un-clip head Basket Filter Essential Filter Fully sealed with no gaps Waste bag tted correctly... - Page 4 MIDIHSV Place basket lter in tank. No gaps. Fit head ensuring that it is sealed ADD HOSE AND ACCESSORIES AS REQUIRED Ensure hose locked in place Remove tank bung and t hose Fit wand elbow Push t extensions...
- Page 5 MIDIHSV MIDIHSV Floor head Crevice tool onto elbow Crevice tool onto elbow Upholstery tool onto elbow CONNECT TO POWER SOURCE AND TURN ON Air Flow indicator...
-
Page 6: Waste Disposal
MIDIHSV WASTE DISPOSAL For best practice follow BS8520-1:2009 Operation, cleaning and maintenance of class H vacuum cleaners. - Code of practice. - Page 7 MIDIHSV...
- Page 8 VTVS7163 Gasket MTP 30/AU waved 10+10 VTVS7478 E.2 Black Cover Ø40 VTVS7422Y SWITCH - VRS SEALED & YELLOW V-TUF 'VRS' TYPE 10AMP - fits RAPIDS, MIDI, Mighty, MAXI, VACW&D, RAPID - VTVS7422Y VTVS7437 LIGHT BUZZER FOR DUSTEX, MIDI, MIDI SYNCRO, MAXi 50...
- Page 9 MIDIHSV Pos. Cod. Q.ty Description VTVS7473 Black Plastic Barrel H=250 VTVS7164 Gasket Inlet Ø48 VTVS7165M Inlet Ø48 VTVS7491 Barrel Hook VTVS7514 Blind Rivet 4,8x17 VTVS7512 Self tapping screw 5x25 ZN VTVS7007 Polyester Bag 21 l...
- Page 10 MIDIHSV Pos. Cod. Q.ty Description VTVS7497 black trolley 400x420 VTVS7496 Pivot wheel Ø50 VTVS7511 Self Tipping Screw 5x16 ZN...
-
Page 11: General Information
Thank you for purchasing V-TUF product. V-TUF is focused on research and development to make sure you are fully satisfied with our products. Please read this manual carefully and follow the instructions to ensure you get the best performance from this machine. - Page 12 Ø32mm Accessories Kit Power Cable Safety Instructions These instructions are for the user’s safety. All users of the V-TUF cleaning equipment should ensure to have read this literature before using the machine. • This machine shall be used only be trained, competent and experienced operators. Operators should observe any safety regulations appropriate to the materials being handled.
- Page 13 If any substance has penetrated beyond the essential filter, ensure that the vacuum is decontaminated and has the correct filtration fitted prior to use. 6. Keep Filters Clean 7. Use genuine V-TUF Filter Bags 8. Keep the machine clean 9. Only use the accessories provided with the machine 10.
-
Page 14: Safety Indications
VACUUM CLEANER – CLASS H SAFETY INDICATIONS Operator safety This manual is to be considered as an integral part of the general user manual and provides the necessary instructions for the special class H dust vacuum cleaners. Therefore, the supplied general instruction booklet must be read before operation. In addition to the user instructions and the current regulations in the country of use, the sector’s recognised technical regulations for the safe and appropriate use of this equipment must also be followed. -
Page 15: Before First Use
Failure to carry out maintenance as necessary, include the replacement of parts to the correct standard could render the equipment unsafe and the manufacturer can accept no responsibility in this respect. Before performing any cleaning or maintenance operations on the device, make sure that it is disconnected from the mains power supply by removing the plug from the socket. - Page 16 FILTER BAG REFERENCE TABLE: CODE DESCRIPTION VACUUM MODEL VTVS7021U V-TUF UILPA15 Essential Filter MIDIHSV VTVS7007 Polyester Filter Bag MIDIHSV VTVS7008 Coned Filter Basket MIDIHSV ATTENTION The dust collection bag must not be filled past 3⁄4 of their capacities. Check periodically during use.
-
Page 17: Troubleshooting
All contaminated items which cannot be satisfactorily cleaned are to be disposed of; such items shall be disposed of in impervious bags in accordance with any current regulation for the disposal of such waste. Be careful to not disturb dusts when performing cleaning operations, filter checks or filter replacements. Use the correct PPE, equipment and procedures according to BS8520-3:2009 Replacing the Essential Filter element Open the closure hooks, lift the vacuum’s cover from the container and set it down in a way that you can... -
Page 18: Maintenance Log
MAINTENANCE LOG EQUIPMENT HISTORY SHEET Unit: Serial Number: Model: Log all electrical and product safety and performance tests Date of last test : Date of next test : Inspected By Satisfactory Defects and or Date Approx Hours Run (Company, print name, sign) YES/NO remarks... - Page 19 NOTES...
