- Page 1 M class certified vac MAMMOTH XLR 240 Volt & 110 Volt INDUSTRIAL VACUUM CLEANER User Operating Manual English Operators Manual V-TUF...
- Page 2 ASSESSORIES INCLUDED P a g e...
- Page 3 INTRODUCTION Thank you for purchasing a product from the V-TUF Industrial Cleaning Equipment range. V-TUF is focused on research and development to make sure you are fully satisfied with your purchase. Please read this manual carefully and follow the instructions to ensure you get the best performance from this machine.
-
Page 4: General Information
3. Make sure that the electrical data of the appliance, shown on the label, corresponds to those of the mains supply. 4. The appliance must only be used with V-TUF accessories and spare parts as these ensure safe and perfect operation. - Page 5 IMPORTANT INFORMATION Never use the machine if you are unsure or become uncertain due to any faults of any kind, including those not mentioned in this manual. Technical Information Model MAMMOTH XLR Capacity 110 Litres Working Voltage 110 & 240 Volts...
- Page 6 Safety Instructions These instructions are for the user’s safety, and all users of the V-TÜF cleaning equipment should ensure to have read this literature before using the machine. ➢ Do not use with a damaged cable. ➢ Do not run over the cable. ➢...
-
Page 7: Vacuum Cleaner
5. Do not soak the appliance or spray it with liquid substances. SHORT-CIRCUIT. 7. Do not pull or lift the appliance using the power cable. SHORT-CIRCUIT RISK. VACUUM CLEANER SAFETY INDICATIONS Operator safety This manual is to be considered as an integral part of the general user manual and provides the necessary instructions vacuum cleaners. - Page 8 Maintenance, cleaning and repair Only perform the maintenance work described in this booklet on the equipment. In case of uncertainty, contact the dealer or an authorized service centre. BEFORE FIRST USE Vacuum assembly and testing Before using the device, check that: No foreign elements are present within the container.
- Page 9 3. Drop drainpipe to an area you wish to dispose if the liquid. (See below) Please note: You cannot run the vacuum motors while doing this. USE OF THE DEVICE ATTENTION The aspiration of flammable dusts/substances is forbidden. The sector’s reference standard, EN 60335-2-69/A1:2004, lists the dusts which present a risk of explosion when brought into contact with ignition sources.
-
Page 10: Troubleshooting
Emptying the dirt from the container ATTENTION The container can only be emptied when the device is switched off. Remove the device’s cover, turn the container upside down and empty it. The waste materials must always be disposed of in compliance with the current local laws. Replacing the foam element Open the closure hooks, lift the vacuum’s cover from the container and set it down with the filtering system oriented upwards (use the container as a support surface if necessary). - Page 11 Vacuum head 110 volt MAMMOTHXLRB Vacuum XLR complete base. VTVS7423 SWITCH - SEALED & BLACK TYPE 10AMP I3.325YEL-1M CABLE 3 CORE V-TUF PVC 2.5 YELLOW (per meter) I4.000 PLUG 240 VOLT 13AMP (TOUGH PLASTIC) I5.000 PLUG 110 VOLT 16 AMP (YELLOW) 11 |...
- Page 12 Common wearing parts: Vacuum head parts (continued): LIST 1: LIST 2: Number Order code Description LIST 1 VTVS042XLR Vacuum motor 240 volt VTVS066 Vacuum motor 110 volt LIST 2: VTVS7020L FILTER Sponge - Anti-Foaming Device VTVS021XLR FILTER Basket - AQUADRY 29.3a VTVS7026L High Efficiency FILTER (Optional)
- Page 13 Common wearing parts: Tank parts: Number Order code Description VTVS7165M HOSE FLANGE VTVS042XLR Tank Clip XLRDH Drain Hose kit 7 & 12 VTVS023XLR Caster Wheel 8 & 9 VTVS024XLR REAR WHEEL 300mm x 13mm Wheel Clip XLR Drain hose clip XLR Drain hose plug 13 | P a g e...
- Page 14 HOSE END - Machine End 52mm Ø VTVS044 HOSE END - TOOL END 40MM WND/2 TUBE SET - 38MM STAINLESS STEEL 3 PIECES BIO384WD FLOOR HEAD - V-TUF 38MM BRUSH ROUND VTVS032 CREVICE TOOL - V-TÜF 40mm VTVS021XLR FILTER Basket - AQUADRY...
- Page 15 For more details contact us: V-TÜF FENCO GROUP LTD UNIT 5 CHRIS SHARP BUILDING SCAMPTION LN1 2SX United Kingdom E-mail: enquiries@v-tuf.com Web: www.v-tuf.com Follow us: 15 | P a g e...
