AUTOMAZIONI A PISTONE PER CANCELLI A BATTENTE
I
ELECTROMECHANICAL PISTON FOR SWING GATES
GB
VERIN ELECTROMECANIQUE POUR PORTAILS A VANTAUX
F
ELEKTROMECHANISCHER KOLBEN FÜR FLÜGELTORE
D
PISTON ELECTROMECANICO PARA CANCELAS DE BATIENTE
E
AUTOMATIZAÇÕES DE PISTÃO PARA PORTÕES DE BATENTE
P
ISTRUZIONI D'USO E DI INSTALLAZIONE
INSTALLATION AND USER'S MANUAL
INSTRUCTIONS D'UTILISATION ET D'INSTALLATION
MONTAGE- und BEDIENUNGSANLEITUNG
INSTRUCCIONES DE USO Y DE INSTALACION
INSTRUÇÕES DE USO E DE INSTALAÇÃO
Via Lago di Vico, 44
36015 Schio (VI)
Tel.naz. 0445 696511
Tel.int. +39 0445 696533
Fax 0445 696522
Internet: www.bft.it
E-mail: sales@bft.it
D811414 ver. 01 15-05-03
PHOBOS L BT
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BFT PHOBOS L BT
Summary of Contents for BFT PHOBOS L BT
- Page 1 VERIN ELECTROMECANIQUE POUR PORTAILS A VANTAUX ELEKTROMECHANISCHER KOLBEN FÜR FLÜGELTORE PISTON ELECTROMECANICO PARA CANCELAS DE BATIENTE AUTOMATIZAÇÕES DE PISTÃO PARA PORTÕES DE BATENTE PHOBOS L BT ISTRUZIONI D'USO E DI INSTALLAZIONE INSTALLATION AND USER'S MANUAL INSTRUCTIONS D'UTILISATION ET D'INSTALLATION MONTAGE- und BEDIENUNGSANLEITUNG INSTRUCCIONES DE USO Y DE INSTALACION INSTRUÇÕES DE USO E DE INSTALAÇÃO...
- Page 2 It must be controlled by an electronic control panel provided with torque setting. The end-of-stroke operation is regulated by two electromechanical limit devices. The operator is provided with an obstacle detection system complying with EN12453 and EN 12445 standards. PHOBOS L BT Ver. 01 -...
- Page 3 When “a” and “b” are at their maximum, the piston develops the maximum The operator is provided with an electronic torque limiter. It must be force. controlled by an electronic control panel provided with torque setting. PHOBOS L BT Ver. 01 -...
- Page 4 Any malfunction should be corrected immediately by a qualified specialist. the connections of motor + and motor - (red/black) on the control board. Keep children at a safe distance from the field of action of the automation. 10 - PHOBOS L BT Ver. 01...
-
Page 5: Maintenance
After fixing or replacing the defective device, reset all the devices previously disconnected. Refer to the relevant instruction manual for all the devices installed on the automation. PHOBOS L BT Ver. 01 -... - Page 6 Fig. 1 FC1 (OPEN) FC2 (CLOSE) Cu MAX 410 mm Fig. 2 α° (mm) α° Installazioni consigliate / Recommended installation Installations conseillées / Empfohlene Installationen Instalaciones aconsejadas / Instalações Aconselhadas 24 - PHOBOS L BT Ver. 01...
- Page 7 Fig. 3 Fig. 4 1050 Fig. 6 Fig. 5 Fig. 7 + 4° - 4° PHOBOS L BT Ver. 01 -...
- Page 8 Fig. 8 Fig. 9 Fig. 10 Fig. 11 Fig. 12 ECB 24 Va.c. Fig. 13 26 - PHOBOS L BT Ver. 01...
- Page 9 1 2 3 4 5 Einstellung anzugsdauer relais Configuración del tiempo de excitación relé Definição do tempo de excitação do relé ECB 24 Va.c. LIBRA 11 12 13 14 15 24V ~ VSafe PHOBOS L BT Ver. 01 -...
