  • Page 1 version 130308 tuned to you...
  • Page 2 – ● – ● – ● – ● ’...
  • Page 3 • • ’ • • • • • • • • • • ’ • • • • • • • • • • ’ ’ ● ● ● ● ● ● ● ’ ● ● ● ● ’ ● ●...
  • Page 4 TECH SUPPORT U.S. TOLL FREE: 877-995-8155 / INT'L: +1-561-995-8155...
  • Page 5 Please read and follow all instructions before installing and operating this product. Follow all local and federal building and electrical. BFT is not responsible for faults or damage cause by improper installation, application, or failure to comply with building codes.
  • Page 6 Depending on the size of the post, the type of hinge and its placement, the post bracket might have to be mounted offset to the gate post. This should require custom welding a brace or gusset (not supplied) Hinge offset: Distance between the center-line of the hinge and the inside edge of the gate post The black dots represent the recommended bolt placement.
  • Page 7 This measurement is taken with the gate fully closed magnet Install the magnet holder into the gate bracket magnet The top surface of both post and gate bracket must be leveled between the two When the gate is on its fully open, or fully closed position, the distance from the center of the mounting hole of the gate bracket, to the hinge center-line, must be equal or less than that of the mounting hole on the post bracket to...
  • Page 8 WARNING: Push to open installations are not standard installations. The post bracket should require modifications and/or welding. The following illustrations do not represent the actual assembly of the post bracket. Its intentions is to illustrate the directions and dimensions of the bracket in relationship to the gate With the gate opened 90°, the distance between the mounting hole in both brackets must be 27 inches...
  • Page 9 1. Strip about 1-1/2” off the outer jacket of the motor cable. Install the o-ring over the cable so that it is about 1/2” from the edge of the outer jacket 2. Turn the actuator upside down. Connect the white wire to terminal 1; the red wire to terminal 2;...
  • Page 10 MAKE SURE THAT THE BODY OF THE ACTUATOR DOES NOT HIT THE MOUNTING BRACKET WHEN THE GATE IS FULLY CLOSED...
  • Page 11 1) SET TO MANUAL OPERATION - Disengage the drive gear by using the triangular key and turning clockwise. 2) SET THE CLOSE LIMIT - Push the gate to its fully closed position. Remove the screw that holds the proximity sensor at the front end of the actuator. Slide it back so that the back end of the sensor housing is 3-1/2”...
  • Page 12 Several sizes knock-out punch conduit entries are provided Using the lid screws port holes to fix the enclosure, ensures weatherproof protection of the electronic components. Use plastic anchors for best results Federal and local electrical codes must be followed. 120 Volts, single phase power is connected to the terminal strip on the lower left corner of the control board as shown.
  • Page 13 Do not perforate the top of the enclosure Use the mounting holes on the top and bottom flanges of the enclosure. Do not drill through the interior of the enclosure. Bring all your wiring and/or conduits through the bottom of the enclosure. For best results, use a step drill bit to perforate the enclosure to the needed size opening Power box...
  • Page 14 █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ For single gate installations, connect your motor wires to Motor 1 motor output (terminals 10 & 11), and Motor 1 limit input (terminal 42).
  • Page 15 ► ► ► ► ► ► ► ► ► ► Pressing the [+] button scrolls UP Pressing the [-] button scrolls DOWN EXIT █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █...
  • Page 16 next the screen will scroll down using the press [ok] to select display: “n. mot” [-] button and look (number of motors). for “phob” (phobos) if two motors are if only one motor is … and then press connected , press [ok] connected , press the [ok] to select.
  • Page 17 Automatic Closing Timer: Automatically closes the gate after gate fully opens and all safety devices are cleared. Pre-Alarm: Energizes auxiliary relay with value set to “6”, for 3 seconds before energizing the motors. Uninterrupted Open Cycle: Remote controls and START input is ignored during the open cycle. Instant Reverse On Closing: A START command will instantly re-open gates during the close cycle.
  • Page 18 be aware that the the screen will the after selecting your display “ autoset” gate will run at full preset, the screen will torque during the display “prog” process. press [ok] (programming) for a when ready few seconds make sure that the path of the gate is clear of traffic and obstructions.
  • Page 19 24 volts accessories and peripherals can be powered from terminals 50 and 51 - 24 V Accessory power negative common + 24 V Accessory power positive █ █ █ + 24 V-Safe Positive power when gate is not closed The Thalia board provides two command inputs (IC1 and IC2). Command positive common common █...
  • Page 20 The Thalia board provides one STOP command input, and two programmable obstruction sensing device inputs, SAFE1 and SAFE2. All 3 safety inputs are N.C. (normally closed) contacts. Both SAFE 1 and 2 have a device supervision circuit labeled FAULT. Fault inputs, when enabled, are all normally open.
  • Page 21 The Thalia board has two auxiliary outputs. The first (20 & 21), is a 24 volt, courtesy light output that will activate upon activation of the gate, and will remain on for 90 seconds after the gate has closed. The second output labeled AUX 3 (26 & 27), is defaulted as second channel radio receiver output, but can be re- █...
  • Page 22 Pressing the [+] button scrolls up or increases value Pressing the [-] button scrolls down or decreases value BACK █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █...
  • Page 23 MAIN S ELECTION DES CRIPTION DEFAULT RANGE PARAM > OPEN DELAY TIME Motor 2 opening delay in s econds 0-10 CLS DELAY TIME Motor 1 clos ing delay in s econds 0-10 Auto-clos e time adjus tment in s econds 1-180 TRF.
  • Page 24 Dedicated power supply RED (+24V) WHITE (-24V) YELLOW (normally closed contact) BLUE (common) P/N: KRELAY24V Transformer SBS – battery backup board Power plug █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █ █...

  • Page 25: Common Error Codes

    For actuators installed in areas where dirt and dust are a concern, maintenance should be done at shorter intervals. Keep the screw-drive lubricated using BFT grease part number: I101115. Do not apply grease if gears are dirty. If necessary, clean with degreaser before applying new grease.
  • Page 26 Thalia control board Includes enclosure and transformer P/N: D113745 00001 Secondary fuse 3.15 Amps, slow-blow 5mm x 20mm Primary fuse 2.5 Amps, slow-blow 5mm x 20mm Manual release key P/N: D610180 Phobos motor board Trolley assembly P/N: D111709 00001 P/N:I099827 End Cap P/N: I105800 Gate Bracket &...
  • Page 27 THALIA P LE-B ECOSOL THALIA P/N: KTHALIA12U Solar powered system. Large 12” x 14” control board Includes 10W 24V solar panel enclosure. Includes battery (30W panel optional), (2) 9Ah backup with (2) 12V, 9 Ah batteries, Ecosol solar batteries. The Thalia “P” interface board, (2) remotes.
  • Page 28 ⵀ 2.5A SLOW BLOW ⵀ...
