SMC Networks FHIA Series Operation Manual

Vertical type suction filter

Advertisement

Quick Links

Doc.no.DOC1075631
PRODUCT NAME
Vertical type suction filter
MODEL / Series / Product Number
FHIA series

Advertisement

loading
Need help?

Need help?

Do you have a question about the FHIA Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SMC Networks FHIA Series

  • Page 1 Doc.no.DOC1075631 PRODUCT NAME Vertical type suction filter MODEL / Series / Product Number FHIA series...
  • Page 2 Contents ●Safety Instructions P2~P3 1. Constructional view 2. Method of installation and operation 3. Maintenance and inspection...
  • Page 3 Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
  • Page 5 Constructional view ⑰ Reset button Peep hole ⑯ Peep hole ⑪ ⑩ ⑥ ⑦ ② ③ ① Casing ② “O”ring ① ③ Cover ⑮ ④ Relief valve ⑤ Retaining ring ⑥ “O”ring ⑦ Wave washer ④ ⑧ Packing ⑨ Element ⑤...
  • Page 6 Method of installation and operation 1. Install this suction filter between the tank and pump on the suction side of the hydraulic circuit. Example 2 Example 1 Beside oil tank Over oil tank Vertical type suction filter Diff.press.indicators Diff.press.indicators Pump Pump Vertical type suction filter Valve...
  • Page 7 G1/2 To be connected to alarm Cord Connector Micro switch Figure 2 Example of NO (Normally Opened) Connection 3. Remove cord rubber plug ④, then perform wiring according to the following procedure. 3-1. Using a connector, or the like, connect the plane terminals of the micro switch to either the NO or NC contacts.
  • Page 8 Revision history 1st edition:March 2024 Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved...
