Danfoss PV05 Installation Manual page 5

EKE 1A - connection overview
Pressure Transmitter
Ratiometric 0.5 – 4.5 V
1
3
2
e.g. AKS 32R
Power supply
24 V AC
± 20%
© Danfoss | Climate Solutions | 2024.03
AKS cable
connection
060G1034
24 V DC
± 20%
–
+
2.5 A
Batt
backup
T fuse
(optional)
(optional)
ETS 6 valve
ETS / KVS
Colibri ®
CCMT / CTR valve
Master controller
C
CAN RJ CAN RJ
CAN RJ CAN RJ CAN RJ
Superheat controller
Superheat controller
EKE 1A - 080G5300
+
18 V
Normally open or
normally closed
(optional)
ON/OFF
solenoid
valve
MMIGRS2 Display
CAN RJ
080G0294 (optional)
MMIMYK
Gateway
KoolProg PC tool
* Note: If Dl1(On/O ) switch is not used
it must be turned o in Dl1 parameter
con guration
C1 NC1
Power
C1 NO1
Relay
Power
Alarm
AN232086439413en-000706 | 5
