Danfoss PV05 Installation Manual page 4

DIN rail mounting / demounting
The unit can be mounted onto a 35 mm DIN rail simply by snapping it into place and securing it with a stopper to prevent
sliding. It is demounted by gently pulling the stirrup located in the base of the housing.
1
Connection overview: EKE 1A
© Danfoss | Climate Solutions | 2024.03
2
3
"Click"
ANALOG / DIGITAL INPUT
ANALOG / DIGITAL INPUT
Superheat controller Superheat controller
EKE 1A - 080G5300
STEPPER VALVE
PWR 24V Vbat STEPPER VALVE
CAN - RJ
CAN RJ
CAN RJ
DIGITAL OUTPUT
DIGITAL OUTPUT
AN232086439413en-000706 | 4
