Quick guide for parameter selection
Apart from wizard setup, users can also use the following section which describes quick parameter
settings for general applications.
Driver
Start : Main switch= O
Select valve type
Application mode
Driver- Controller
Analog signal type
e.g 1- 5V / 0 - 20mA
Parameter
EKE 1A
Driver reference
-
con guration
Ext ref voltage
I034
low
Ext ref. voltage
I035
high
Ext ref. voltage
-
low
Ext ref. voltage
-
high
© Danfoss | Climate Solutions | 2024.03
Controller
Select Refrigerant
Select Temperature sensor
Select Pressure transmitter
De ne Min/Max Pressure
Select Superheat Control
Set Min/Max Ref value
Select Other features
Finish: main switch = ON
Dl1=ON
Make sure that main switch is OFF before changing
the settings. The setting will depend on the system
requirement.
Parameter: R012 Main Switch
Select prede ned Danfoss valve type ETS, ETS C, KVS,
KVS C, CCM, CCMT, CTR, or user de ned.
Parameter: I067 Valve con guration
Select how you want to use EKE: driver or superheat
controller.
Parameter: R102 Operation mode
Select the prede ned refrigerant
Parameter: O030 Refrigerant
Select Temperature sensor type: EKS, ACCPBT, MBT,
Sensata 112CP
Parameter: I082 - S2 sensor con guration.
Select Pressure transmitter type : AKS 32R , Sensata
112CP, OEM Ratio, NSK, AKS 32 1 - 5 V, OEM Voltage
Parameter: I086 - Pe transmitter con guration
De ne min and max Pressure transmitter in barg.
Parameter: O020 - Pe min., O021 Pe max., Check
parameter list for other sensors.
Select application control type SH control. 1: MSS,
2: LoadAp, 3: Fixed, 4: Delta SH.
Parameter: N021 SH reference mode.
Set the value for the selected control min./max.
superheat reference.
Parameter N009 SH max., N010 - SH min.
Optional – Force start up, MOP, LOP, Alarm,
Thermostat function.
Check parameter list for details.
Remember to turn on main switch to start "ON" .
Parameter R012 Main switch.
ON=Regulation start
Parameter O003 :0 = Not Used | 1 = Main Switch
