Snapshot - Digital Watchdog DWC-VSTB04Bi User Manual

5.6.6 Snapshot

Set the format, resolution and quality of the snapshot image that is saved to
the SD card.
Go to Setup>System>Snapshot to go to the interface as shown below.
Snapshot Parameters
• Image Format: Image will be saved as JPEG.
• Resolution: Image will be saved at 640x480 resolution.
•
Image Quality: Select the preferred image quality.
Event Trigger
•
Snapshot Interval: Select the cooldown time for snapshot images
when an event alarm has been triggered within the camera.
•
Snapshot Quantity: The number you set here is the maximum
quantity of snapshots that are permitted while remaining within
Snapshot Interval
the
Timing
• Enable Timing Snapshot: Enable timing snapshot to have the
camera regularly take snapshot images.
• Snapshot Interval: Select the cooldown time between snapshot
images for the camera. For example, if set to "5 sec." the camera
limit.
53
