  • Page 1 www.solaxpower.com eManual in the QR code or at http://kb.solaxpower.com/...
  • Page 2 Table of Contents Safety ........................1 Installation ......................13...
  • Page 3 Safety General Notice 1. Contents may be periodically updated or revised. SolaX reserves the right to make improvements or changes in the product(s) and the program(s) described in this manual without the prior notice. 2. The installation , maintenance and grid-related setting can only be performed by qualified personnel who: •...
  • Page 4 DANGER! To prevent personal injuries and equipment damage, strictly do as follows in the process of operation: • DO NOT power on while installing the device. If the device is powered on in the process of installation and disassembly of cables, an electric arc, electric spark or fire will occur at the moment that the cable core contacts conductors.
  • Page 5 DANGER! To prevent personal injuries and equipment damage, strictly do as follows when installing the batteries: • Never dismantle, change or damage battery, including penetrating with a sharp object, deforming, soaking in water or other liquids, to keep it away from leakage, smoke, release of flammable gases, thermal runaway, fire or explosion.
  • Page 6 WARNING! Operators shall strictly do as follows to prevent personal injuries and equipment damage: • To ensure that a complete set of tools is prepared, are firm and secure. They must pass the verification of professional authorities. DO NOT use any tools that are broken, failed to verify, or are expired.
  • Page 7 CAUTION! • Do not stop the safety switch on the equipment, and neglect the “Danger” sign, "Warning" sign, "Caution" sign, and "Notice" sign on the equipment, as well as safety precautions in the document. • Must stop working at once, report to the relevant person in charge, and activate protection schemes in case of possible danger that may cause human injury and damage to equipment in the installation and operation process.
  • Page 8 CAUTION! Safety precautions for storage, installation and wiring: • Ensure that the packing cabinets are intact before unpacking. Do not use if package is damaged, and contact forwarder and manufacturer immediately. • May leak electrolytes or release flammable gases if the battery is damaged, including dropping, crashing, bulging, or housing indentation.
  • Page 9 CAUTION! Safety precautions for handling: • To prevent injury from oversize loads, assess the device you're about to lift before you start lifting. • If more than 2 people lift a device, reasonably arrange to have a balanced weight distribution •...
  • Page 10 CAUTION! Safety precautions for working at heights: • Should avoid working on the up and down work platform at the same time. Or, a special protective shed should be built or some protective measures should be taken between two work platforms to protect workers. In addition, do not stack tools and materials on the upper work platform.
  • Page 11 CAUTION! Drilling safety: • Wear personal protective equipment when drilling, such as safety glasses, safety gloves, etc. • Avoid drilling around pipes, and light switches and sockets, as the electrical wires can go horizontally and vertically around these fixtures. • Cover the device to protect it from dusts and debris entering when drilling, and clean it at once after finishing drilling.
  • Page 12 NOTICE! Grounding requirements: • The equipment grounding impedance shall meet the requirements of the local electrical code. • The equipment shall be permanently connected to a grounding wire within the building’s electrical system. Check that the equipment is reliably grounded. •...
  • Page 13 NOTICE! The static electricity generated by human beings can damage the static-sensitive components on the board, like large scale integrated circuit. Therefore, please follow the steps below to prevent static electricity: • Operators must wear anti-static clothing, and anti-static gloves or wrist straps before contacting the boards, modules with exposed circuit boards, or application specific integrated circuits (ASIC).
  • Page 14 NOTICE! Effective ways to deal with accidents: • In case of the damaged battery module, place it into a segregated place, and call the local fire department at the place where the user lives or qualified personnel. • If any part of the battery module, or wiring is submerged, do stay out of the water and do not touch anything;...
  • Page 15 Packing List / Packliste / Liste du matériel livré / Lista de piezas / Lista da embalagem / Paklijst / Contenuto della confezione / Zawartość opakowania / Seznam balení / Packlista / Listă de ambalare / Опаковъчен лист / Pakkeliste / Λίστα συσκευασίας / Pakkeleht / Pakkausluettelo / Popis pakiranja / Csomaglista / Pakuotės turinys / Iepakojuma saraksts / Zoznam položiek balenia / Seznam pakiranja / Kutu Listesi / Lista de Embalagem...
  • Page 16 Item No. Items Quantity Angle support 4 pcs Key (to open front door) 2 pcs Key (to open rear door) 2 pcs Key (to open screen) 2 pcs Allen key 2 pcs Antenna 1 pc Hexalobular key 1 pc Installation Site / Installationsort / Site d'installation / Sitio de instalación / Local de instalação / Installatiesite / Sito di installazione / Miejsce instalacji / Místo instalace / Installationsplats / Loc de instalare / Монтажен...
  • Page 17 Fork Position Installation Carrier / Installationsträger / Partie porteuse / Soporte de instalación / Suporte de Instalação / Installatiedrager / Supporto di installazione / Powierzchnia montażowa / Nosič instalace / Installationsfästen / Suport instalație / Монтажна основа / Monteringsholder / Μεταφορέας εγκατάστασης / Paigalduskandja / Asennusteline / Nosač...
  • Page 18 Dimension and Installation Foundation Angle supports installed at front and rear sides Unit: mm Plan view Installation position for eye bolt Fork position, Angle support Foundation 1580 1396 1680 Right view Front view Unit: mm Foundation 1040 Cable threading hole ≥...
  • Page 19 Angle supports installed at left and right sides Unit: mm 1846 Installation position for eye bolt Fork position, 1760 Angle support Foundation Plan view 1200 1880 Left view Front view Unit: mm Foundation Cable 1400 threading hole ≥ 300 1520 1520...
  • Page 20 Installation Space / Installationsraum / Espace d'installation / Espacio de instalación / Espaço de instalação / Installatieruimte / Spazio di installazione / Przestrzeń instalacyjna / Instalační prostor / Installationsutrymme / Spațiu de instalare / Монтажно пространство / Monteringsplads / Χώρος εγκατάστασης / Paigaldusruum / Asennustila /Mjesto ugradnje / Telepítési tér / Montavimo erdvė...
  • Page 21 Multimeter Hammer drill (Ø16 mm) (Range: 1500 V) Measuring tape Utility knife Flat-head screwdriver Wire cutter Marker Cross screwdriver Wire stripper Crimping tool for RJ45 Hydraulic wire crimper Rubber mallet Torque screwdriver Heat shrink tubing (Flat-head: M3) (Ø30~60 mm) Torque wrench (M4~M12) Heat gun (Phillips head: M5) Diagonal pliers...
  • Page 22 Safety vest Safety helmet Safety belt Additionally Required Materials / Zusätzlich erforderliche Materialien / Matériaux supplémentaires requis / Materiales adicionales necesarios / Materiais Adicionais Necessários / Extra benodigde materialmen / Materiali aggiuntivi necessary / Materiały wymagane dodatkowo / Další požadované materiály / Ytterligare materialkrav / Materiale suplimentare necesare / Други...
  • Page 23 Front Silicone gasket Front Steel pipe (Ø25-30 mm) Note! 3. Regarding personal safety, please refer to “Safety precautions for L > 1900 mm working at heights”. 60° Installation of Antenna Silicone cap...
  • Page 24 Antenna The reserved antenna port Note! 1. The user can decide whether the reserved port connects an antenna based on the actual situation. 2. Regarding the other antenna port (the right one), the antenna is delivered with the accessories kit. Installation of Angle support and Cover Align the holes in the cabinet, Draw circles on the ground.
  • Page 25 Ø16 mm 95~105 mm 90° 42±4.2 N·m Note: Reinstall the angle supports, ensuring that the screw holes on the angle support align with the screw holes on the cabinet and foundation. 42±4.2 N·m Each cover has 4 screws, with a total of 4 covers. Hexalobular 5±0.5 N·m...
  • Page 26 Wiring / Verkabelung / Câblage / Cableado / Ligação / Bedrading / Cablaggio / Połączenie przewodów / Zapojení / Kabeldragning / Cablare / Свързване / Ledningsføring / Καλωδίωση / Juhtmed / Kytkennät / Ožičenje / Vezetékezés / Elektros instaliacija / Elektroinstalācija / Zapojenie / Ožičenje / Kablolama / Fiação Dismantlement of Cable Entrance Hole Cover before Wiring Note: Please keep the keys properly.
  • Page 27 Parts that Need Wiring Note! Before wiring, operators are required to learn which parts need to be conducted wiring. For details, see the following figure. Part a Part b Part b Front view Rear view Grid Connection Regarding the grid connection, namely Part a in “Parts that Need Wiring”, please strictly follow the steps below.
  • Page 28 Note! It’s important to give the power cable a health check before stripping it. It’s necessary to use controlled motion to strip the insulation down the wire, to prevent damage to the wires. Make sure that the insulation layer has been stripped to a sufficient length so that the center conductor is fully exposed without any damage or nicks.
  • Page 29 Right view of cabinet Foundation Foundation *To thread To thread grid wire communication wire Note: The mark "*" indicates that the cable threading hole is reserved for parallel. 12±1 N·m...
  • Page 30 Cable threading holes Grid wire Note: There are four common grounding points in the copper bar. Any one of these point can be selected. Fireproof mud 12±1 N·m Notice for fireproofing mud: Take out the fireproof mud delivered with the cabinet and knead it into a ball shape. In the case of the low temperature, place it into warm water, of which the temperature range is between 40°C and 70 °C, with its package until it is soft.
  • Page 31 Grounding Plate Connection Regarding the grounding plate connection, namely Part b in “Parts that Need Wiring”, either connection area is available, please strictly follow the steps below. Grounding plate 42±2 N·m Power on the System / Schalten Sie das System ein / Mise sous tension du système / Encienda el sistema / Ligue o sistema / Het systeem inschakelen / Accensione del sistema / Włączanie systemu / Zapnutí...
  • Page 32 For the detailed steps, see following figures. Power HVAC Power MCCB-Feedback SPD-Feedback ESS Meter IO-DI1 IO-GND IO-DI4 IO-GND RS485A RS485B 220V AC Power L 220V AC Power N Emergency Stop Control 24V DC Power + 24V DC Power - L-2 LDAS FAN LED UPS- UPS- LED FAN LDAS N-2...
  • Page 33 Tap the power button, at the same time, the light flashes green. Note: Please properly keep the keys. High Voltage Box Power off the System There are two circumstances: 1. Normal power off; 2. Emergency power off. Normal Power Off Note: Please keep the keys properly.
  • Page 34 Power on/off Setting Power MCCB-Feedback SPD-Feedback ESS Meter HVAC Power IO-DI1 IO-GND IO-DI4 IO-GND RS485A RS485B 220V AC Power L 220V AC Power N Emergency Stop Control 24V DC Power + 24V DC Power - UPS- UPS- IO-D IO-D L-2 LDAS FAN LED LED FAN LDAS N-2 N-3 SB-23 SB-24...
  • Page 35 Emergency Power Off Warning! Do not press the emergency stop button except for emergencies. Note! If it has been pressed, the emergency stop button must be reset before starting the equipment. The reset steps are shown as follows: Rotate the cover; Rotate the button according to the arrow direction shown on the button.
  • Page 36 Status Description Solid yellow light In sandby Solid green light In operation Solid red light System failure High-voltage Box's LED Light LED light Status Description Press and hold "power button" ≥15 seconds to enter into "operating state". During this Flashing green light period, the system will assign each battery pack in a communication loop a unique address (battery number).
  • Page 37 Battery Pack's LED Light LED light Status Description Flashing green light In operation Technical Data / Technische Daten / Fiche technique / Datos técnicos / Dados Técnicos / Technische gegevens / Dati tecnici / Dane techniczne / Technické údaje / Tekniska data / Date tehnice / Технически...
  • Page 38 Battery Model TRENE-P100B215I Battery Type LiFePO4 Battery capacity [kWh] Rated battery voltage [V] Battery voltage range [V] 600 ~ 876 Discharge depth [%] Rated charge/discharge current [A] General Parameter Model TRENE-P100B215I Dimension (W×H×D) [mm] 1680 × 2420 × 1200 Weight [kg] 2800 Operating temperature range [°C] -30 ~ 55...
