X3-ULTRA
15 kW / 19.9 kW / 20 kW / 25 kW / 30 kW
User Manual
Version 3.0
www.solaxpower.com
eManual in the QR
code or at http://
kb.solaxpower.com/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X3-ULTRA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SolaX Power X3-ULTRA

Summary of Contents for SolaX Power X3-ULTRA

  • Page 1 X3-ULTRA 15 kW / 19.9 kW / 20 kW / 25 kW / 30 kW User Manual Version 3.0 www.solaxpower.com eManual in the QR code or at http:// kb.solaxpower.com/...
  • Page 3 No part of this manual may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means without the prior written permission of SolaX Power Technology (Zhejiang) Co., Ltd. Trademarks and other symbol or design (brand name, logo) that distinguishes the products or services offered by SolaX has been trademark protected.
  • Page 4 About This Manual Scope of Validity This manual is an integral part of X3-ULTRA series inverter. It describes the installation, electrical connection, commissioning, maintenance and troubleshooting of the product. Please read it carefully before operating. This manual is valid for the following inverter models: •...
  • Page 5 Conventions The symbols that may be found in this manual are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, DANGER will result in death or serious injury. Indicates a hazardous situation which, if not avoided, WARNING could result in death or serious injury.

  • Page 6: Table Of Contents

    Table of Contents Safety ......................1 1.1 General Safety ........................1 1.2 Safety Instructions of PV, Inverter and Grid ...............1 1.2.1 Safety Instructions of PV ..................2 1.2.2 Safety Instructions of Inverter ................2 1.2.3 Safety Instructions of Utility Grid ..............3 Product Overview ..................4 2.1 System Description ......................4 2.2 Appearance .........................4 2.3 Supported Power Grid .....................5...
  • Page 7 Unpacking and Inspection ..............29 6.1 Unpacking ..........................29 6.2 Scope of Delivery.......................30 Mechanical Installation ................32 7.1 Dimensions for mounting ....................33 7.2 Installation procedures.....................34 Electrical Connection ................37 8.1 Terminals of Inverter ......................37 8.2 PE Connection ........................38 8.3 AC Connection ........................41 8.4 PV Connection ........................45 8.5 Battery Power Cable Connection .................49 8.6 COM 1 Communication Connection ................56 8.6.1 Pin Assignment of COM 1 Terminal ..............56...
  • Page 8 10.7.2 Advanced Setting ....................96 10.8 About .............................110 Operation on SolaX Cloud App .............112 11.1 Introduction of SolaX Cloud App ..................112 11.2 Downloading and installing App ...................112 11.2.1 Downloading and installing App ..............112 11.3 Operation Guide on SolaXCloud Web ................113 Troubleshooting and Maintenance ............114 12.1 Power off ..........................114 12.2 Troubleshooting .........................114 12.3 Maintenance ........................123...

  • Page 9: Safety

    Safety General Safety The series inverter has been meticulously designed and thoroughly tested to comply with the relevant state and international safety standards. Nevertheless, like all electrical and electronic equipment, safety precautions must be observed and followed during the installation of the inverter to minimize the risk of personal injury and ensure a safe installation.

  • Page 10: Safety Instructions Of Pv

    Safety 1.2.1 Safety Instructions of PV DANGER! Potential risk of lethal electrical shock associated with the photovoltaic (PV) system • Exposure to sunlight can result in the generation of high DC voltage by PV modules, which can lead to electric shock causing severe injuries or even death. •...

  • Page 11: Safety Instructions Of Utility Grid

    Safety WARNING! • During operation, avoid touching any parts of the inverter other than the DC switch and LCD panel. • Never connect or disconnect the AC and DC connector while the inverter is running. • Prior to conducting any maintenance, turn off the AC and DC power and disconnect them from the inverter.

  • Page 12: Product Overview

    Product Overview System Description The X3-ULTRA series is the energy storage inverter that supports grid connection of photovoltaic system. It greatly meets the requirements of solar-powered roofs and supports various intelligent solutions such as load management, wireless metering, dual battery terminals, microgrids, etc., to achieve efficient and economical energy utilization.

  • Page 13: Supported Power Grid

    Product Overview Supported Power Grid There are different ways of wiring for different grid systems. TT / TN-S / TN-C-S are shown as below: 400 V 400 V 400 V L1 L2 L3 Inverter 1.L-N: 230 V; L-L: 400 V 2.L-N: 220 V; L-L: 380 V Figure 2-2 Supported power grid-TT 400 V 400 V...

  • Page 14: Symbols On The Label And Inverter

    Product Overview Symbols on the Label and Inverter Table 2-2 Description of symbols Symbol Description CE mark. The inverter complies with the requirements of the applicable CE guidelines. TUV certified. RCM mark. The inverter complies with the requirements of the applicable RCM guidelines.

  • Page 15: Working Principle

    DC SPD BAT 1 BAT1+ BAT 1 Circuit BAT1- Filter AC SPD BAT2 BAT2+ BAT 2 Circuit BAT2- Filter Figure 2-5 Circuit Diagram for X3-ULTRA series inverter NOTICE! • MPPT 3 is available for X3-ULT-15KP, 20KP, 25K and 30K inverter.

  • Page 16: Application Schemes

    Product Overview 2.5.2 Application Schemes Breaker Main Breaker Grid Breaker Grid Inverter Battery 1 Loads … N-BAR for loads Battery 2 Distribution box Figure 2-6 Whole home backup for most countries Breaker Main Breaker Grid Breaker Grid Inverter Battery 1 Loads Loads …...
  • Page 17 Product Overview Main Breaker Breaker Grid Breaker Grid Inverter Battery 1 Loads … N-BAR for loads Battery 2 Distribution box Figure 2-8 Whole home backup for Australia Breaker Main Breaker Grid Breaker Grid Inverter Battery 1 Loads Loads … N-BAR for EPS loads N-BAR for loads Battery 2 Distribution box...

  • Page 18: Working State

    Product Overview Working State The series inverter has Waiting, Checking, Normal, EPS Checking, EPS, Fault, Idle and Standby state. Table 2-3 Description of working state State Description The inverter is waiting for the following two conditions to be met in order to enter the Checking state ： Waiting •...

  • Page 19: Working Mode

    Product Overview Working Mode Six working modes are available for you to choose in on-grid status, i.e Self use, Feed- in priority, Backup, Peak shaving, TOU and Manual. You can choose the working modes according to your lifestyle and environment. When the power supply from the electric power company is stopped due to a power outage, it automatically switches to EPS mode and connects to the distribution board for a specific load, thereby providing power to important electrical appliances.
  • Page 20 Product Overview PV is sufficient (PV → load → battery → grid) • The power generated from PV prioritizes supplying the load. Any excess power is then directed towards charging the battery, and if there is still surplus electricity, it can be sold to the grid.

  • Page 21: Feed-In Priority (Priority: Loads > Grid > Battery)

    Product Overview 2.7.2 Feed-in Priority (Priority: Loads > Grid > Battery) The feed-in priority mode is suitable for areas with high feed-in subsidies. The power generated from PV is directed towards supplying the loads. Any excess power beyond the load requirements will be fed into the grid. Feed-in Priority Power (Assu ming p eak p ower from 7: 00 to 23: 00)

  • Page 22: Backup Mode (Priority: Loads > Battery > Grid)

    Product Overview NOTICE! • You can set two configurable working periods: forced charging period and allowed discharging period in feed-in priority mode. Please refer to "Charge & Discharge Period" for details. In this mode, consider whether the battery can be charged during the day.
  • Page 23 Product Overview The working logic remains the same as for self-use mode. The difference is: • In the self-use mode when there is no PV input and the battery SOC reaches Min SOC (on-grid min SOC), the battery will enter a dormant state. At this time, if the grid power is lost, the Allowed discharging inverter cannot switch to EPS mode.

  • Page 24: Peak Shaving Mode

    Product Overview 2.7.4 Peak Shaving Mode Peak shaving mode is set for leveling out peaks in electricity use. The system is intelligently controlled to ensure charging takes place during off-peak hours and discharging occurs during peak hours. Power Peak Shaving Mode (Assu ming p eak p ower from 7: 00 to 9: 00 and from 18:00 to 23:00) Battery powers the load I dea: Leveling out peaks in electricity use...

  • Page 25: Tou Mode

    Product Overview ChargePowerLimits: The charging power from grid. 1000 W by default, the settable range is 0-60000 W PeakLimits: The load consumption from grid side. 0 W by default, the settable range: 0-60000 W. Reserved SOC: The lower limit of battery SOC required for later peak shaving period. 50% by default, the settable range is 10~100%.

  • Page 26: Eps Mode (Priority: Loads > Battery)

    Product Overview 2.7.6 EPS Mode (Priority: Loads > Battery) During a power failure, the system will provide uninterrupted power supply to the EPS loads using the power from PV and the battery. It is important to ensure that the EPS loads should not exceed the maximum output power of the battery.

  • Page 27: Manual Mode

    Product Overview NOTICE! • When the battery supplies power to the load, the available capacity of the battery decreases as the SOC decreases. 2.7.7 Manual Mode This working mode is only for the professional technical personnel to perform debugging and maintenance. It includes Forced Discharge, Forced Charge and Stop chrg&dischrg. The system will restore to the original working mode after six hours Manual mode set.
  • Page 28 Product Overview 6 kW 0 kW 0 kW 0 kW 0 kW 0 kW Meter Grid Inverter: 30 kW Pmax: 30 kWp Load: 6 kW Figure 2-16 Zero export control with Phase Unbalance enabled Note: Export Control value can be set from 0W to more than the rated output power. For how to set the Export Control function, please refer to "Setting Export Control".

  • Page 29: System Overview

    System Overview System Overview PV modules SolaX Cloud X3-ULTRA Dongle PV modules Grid Critical loads PV inverter Normal loads Wireless meter Transmitter for wireless meter Receiver for wireless meter Battery 1 Battery 2 Datahub Charger Adapter Box Generator Cloud Communication...
  • Page 30 "15.4 Datahub Application" for specific wiring and setting. EV Charger X3-ULTRA series inverter can communicate with SolaX EV-Charger (supported) to form an intelligent photovoltaic, storage and EV charging energy system, thus maximizing the utilization of photovoltaic energy. Please refer to "15.3 EV-Charger Application"...

  • Page 31: Transportation And Storage

    Observe the caution signs on the packaging of inverter before transportation. • Pay attenting to the weight of inverter. Be cautious to avoid injury when carrying X3-ULTRA (gross weight: 62 kg). Transport according to the personnel quantity required by local regulations. •...

  • Page 32: Preparation Before Installation

    Preparation before Installation Selection of Installation Location The installation location selected for the inverter is quite critical in the aspect of the guarantee of machine safety, service life and performance. It has the IP66 ingress protection, which allows it to be installed outdoor. The installation position shall be convenient for wiring connection, operation and maintenance.

  • Page 33: Installation Carrier Requirement

    Preparation before Installation • Install the inverter at least 500 meters away from the coast and avoid sea breeze directly hit. Sea breeze Inverter 500 m 1000 m Figure 5-1 Recommended installation position Sea breeze Inverter 500 m 1000 m Figure 5-2 Incorrect installation position NOTICE! •...

  • Page 34: Clearance Requirement

    Preparation before Installation NOTICE! • Please take the weight of battery into account when wall-mounting the whole system. 5.1.3 Clearance Requirement The minimum clearance reserved for the connected terminal at the bottom of inverter should be 10 cm. When planning installation space, it is important to simultaneously consider the bending radius of the wires.

  • Page 35: Tools Requirement

    Preparation before Installation Tools Requirement Installation tools include but are not limited to the following recommended ones. If necessary, use other auxiliary tools on site. The following tools must all comply with regulatory requirements. Hammer drill Multimeter (drill bit: Ø12 mm) Measuring tape Utility knife (≥...

  • Page 36: Additionally Required Materials

    Preparation before Installation Additionally Required Materials Table 5-10 Additionally required wires Conductor Required Material Type Cross-section Dedicated PV wire with a voltage rating of 1000 V, a temperature PV wire 4 mm²-6 mm² ℃ , resistance of 105 a fire resistance grade of VW-1 Communication Network cable CAT5E / CAT6...

  • Page 37: Unpacking And Inspection

    Unpacking and Inspection Unpacking • The inverter undergoes 100% testing and inspection before shipping from the manufacturing facility. However, transport damage may still occur. Before unpacking the inverter, please check the outer packing materials for damage, such as holes and cracks. •...

  • Page 38: Scope Of Delivery

    Unpacking and Inspection Scope of Delivery Positive PV connector Negative PV connector Positive PV pin contact Inverter Bracket Negative PV pin contact Cable fixture OT terminal Expansion screw Positive battery Negative battery RJ45 terminal M5 screw connector connector RJ45 connector 8-pin terminal block Handle 7-pin terminal block...
  • Page 39 Unpacking and Inspection Item Description Quantity M5 screw 2 pcs Positive & battery connector 2 pcs Negative battery connector 2 pcs RJ45 terminal 8 pcs RJ45 connector 1 pcs 8-pin terminal block 1 pcs 7-pin terminal block 1 pcs Document Handle 2 pcs Removal tool (Fast removal of...

  • Page 40: Mechanical Installation

    Mechanical Installation WARNING! • Only the qulalified personel can perform the mechanical installation following the local standards and requirements. • Check the existing power cables or other piping in the wall to prevent electric shock or other damage. CAUTION! • Always be aware of the weight of the inverter. Personal injuries may result if the inverter is lifted improperly or dropped while being transported or mounted.

  • Page 41: Dimensions For Mounting

    Mechanical Installation Dimensions for mounting Check the dimensions of the bracket before mounting and reserve sufficient space for heat dissipation and installation of the whole system. Figure 7-3 Dimensions 1 (Unit: mm) Ø 619.5 Figure 7-4 Dimensions 2 (Unit: mm)

  • Page 42: Installation Procedures

    Mechanical Installation Installation procedures Step 1: Align the bracket horizontally on the wall and mark the position of the drill holes. Figure 7-5 Marking the holes NOTICE! • Take the height of the stacked battery into account when mounting the bracket. •...
  • Page 43 Mechanical Installation Figure 7-7 Inserting the screws Step 4: Open the anti-static bag and take out the inverter, and then install the handles. Figure 7-8 Install the handles NOTICE! • Avoid placing the inverter in a way that the wiring terminals are in contact with the floor or any other objects as they are not designed to bear the weight of the inverter.
  • Page 44 Mechanical Installation Step 6: Secure the inverter to the bracket with M5 screw, 0.8± 0.1 N·m Figure 7-10 Securing the inverter Step 7: (Optional) For safety reason, install an anti-theft lock. Please note that the lock is not in the scope of delivery. Prepare it suitable for the lock hole diameter (Ø10 mm) by yourself.

  • Page 45: Electrical Connection

    Electrical Connection DANGER! • Before electrical connection, make sure the DC switch and AC breaker are disconnected. Otherwise, electrical shock may be caused by high voltage, resulting in serious personal injury or death. WARNING! • Only the qulalified personel can perform the electrical connection following the local standards and requirements.

  • Page 46: Pe Connection

    We recommend that the inverter is earthed to a nearby ground point. NOTICE! • X3-ULTRA series inverter has the grounding detection function which is used to check whether the inverter is properly grounded before it starts. If the the inverter is...
  • Page 47 Electrical Connection PE connection procedures Step 1: Strip the insulation of conductor by wire stripper. Stripping length of 16 mm² wire is 13.5 mm-15.5 mm. 10 mm2 Figure 8-2 Striping the PE cable Step 2: Pull the heat-shrink tubing over the PE cable and insert the stripped section into the OT terminal.
  • Page 48 Electrical Connection Figure 8-5 shrinking the tubing Step 4: Loosen the PE screw on the inverter with cross screwdriver. 2.0± 0.2 N·m Figure 8-6 Uninstalling the screw Step 5: Connect the PE cable to the inverter and secure it with the original screw (Torque: 2.0±0.2 N·m).

  • Page 49: Ac Connection

    Electrical Connection AC Connection NOTICE! • Before connecting the inverter to the grid, approval must be received by local utility as required by national and state interconnection regulations. The inverter has an EPS function. When the grid is connected, the inverter outputs go through the on Grid terminal, and when the grid is disconnected, the inverter outputs go through the EPS terminal.
  • Page 50 Electrical Connection » For inductive load such as fridge, air conditioner, washing machine, etc., ensure that the start power does not exceed the EPS peak power. When configuring off-grid loads, leave a certain margin. Table 8-3 EPS load information Equipment Start power Type of load Lamp...
  • Page 51 Electrical Connection Ferrite core Figure 8-9 Disassembling the AC connector Step 3: Thread the Grid cable through swivel nut and connector enclosure in sequence. Figure 8-10 Threading the Grid cable Step 4: Insert the conductors L1, L2, L3, N, and grounding conductor into the ferrules. Use crimping tool for ferrules to crimp it.
  • Page 52 Electrical Connection Step 5: Insert the crimped conductors L1, L2, L3, N, and grounding conductor into the terminal block according to the labeling and tighten the terminal block screws. Click! Figure 8-12 Assembling the AC connector Step 6: Remove the AC terminal caps and plug the assembled AC connectors into Grid terminal and EPS terminal correspondingly.

  • Page 53: Pv Connection

    Electrical Connection WARNING! • Reinstall AC terminal caps immediately after removing the connectors from terminals. PV Connection DANGER! • High DC voltage will be generated by PV modules when exposed to sunlight. Death or lethal injuries will occur due to electric shock. •...
  • Page 54 Electrical Connection Wiring procedures Step 1: Strip approx. 7 mm of the cable insulation. 4-6mm² Figure 8-15 Striping the PV cable Step 2: Insert the stripped cable into the PV pin contact. Ensure that the stripped cable and the PV pin contact are of the same polarity. Crimp it with crimping tool for PV terminal.
  • Page 55 Electrical Connection Figure 8-18 Threading the PV cable Click! Click! Figure 8-19 Securing the PV cable Step 4: Use a multimeter to measure the positive and negative voltage of the assembled PV connectors. Make sure the open circuit voltage does not exceed the input limit of 1000 V.
  • Page 56 Electrical Connection Step 5: Remove the PV terminals caps and connect the assembled PV connectors to corresponding terminals until there is an audible "Click". The PV+ on the string side must be connected to the PV+ on the inverter side, and the PV– on the string side must be connected to the PV–...

  • Page 57: Battery Power Cable Connection

    Electrical Connection Battery Power Cable Connection DANGER! • Make sure the breaker of battery is in OFF position. • Always ensure correct polarity. Never reverse the polarity of the battery cables as this will result in inverter damage. Requirments for battery connection •...
  • Page 58 Electrical Connection • The battery connection scheme » Battery connection in one string. Inverter Inverter Series Box BAT- BAT+ COMM • For T-BAT-SYS-HV-S2.5/3.6, up to 13 battery modules can be connected. • For T-BAT-SYS-HV-5.8, up to 4 battery modules can be connected.
  • Page 59 Electrical Connection Inverter T-BAT H5.8 T-BAT H5.8 HV11550 HV11550 BAT- HV11550 HV11550 BAT+ COMM HV11550 HV11550 • Up to 8 battery modules can be connected. Figure 8-24 Battery connection in two strings (T-BAT-SYS-HV-5.8)
  • Page 60 Electrical Connection » Battery connection with BMS-Parallel Box-II G2 (The BMS-Parallel Box-II G2 can be used with T-BAT-SYS-HV-5.8) Inverter BMS-Parallel Box-II G2 HV11550 T-BAT H5.8 HV11550 T-BAT H5.8 HV11550 HV11550 HV11550 HV11550 BAT- BAT+ COMM HV11550 HV11550 HV11550 HV11550 • With BMS-Parallel Box-II G2, HV11550 HV11550 HV11550...
  • Page 61 Electrical Connection Wiring procedures WARNING! • The terminal caps of unused terminals should not be removed. Keep the terminal caps in a safe place if batteries are connected to the inverter. Reinstall the caps after removing the connectors from terminals. NOTICE! •...
  • Page 62 Electrical Connection Figure 8-28 Threading the battery cable Step 3: Close the spring until a "Click" is heard. Make sure that the spring is snapped in. Click! Figure 8-29 Press down on the Spring Step 4: Push the insert into the sleeve. Tighten the cable gland to 2.0 ± 0.1 Nm. 2.0±...
  • Page 63 Electrical Connection Click! Figure 8-31 Connecting the battery connector...

  • Page 64: Com 1 Communication Connection

    Electrical Connection COM 1 Communication Connection 8.6.1 Pin Assignment of COM 1 Terminal The COM 1 terminal is used for parallel connection via Parallel-1 and Parallel-2 communication terminal, battery communication via BMS-1 and BMS-2 terminal, Communicate via RS485 and DRM, or external communication. Parallel-1 Parallel-2 1: Parallel_485A...

  • Page 65: Parallel Communication Connection

    Electrical Connection 8.6.2 Parallel Communication Connection The inverter provides the parallel connection function. One inverter will be set as the “Master inverter” to control the other "Slave inverters" in the system. NOTICE! • The communication cable length between two parallel inverters should not exceed 10 meters, and the total cable length of all parallel inverters should not exceed 80 meters.
  • Page 66 Electrical Connection Remove Figure 8-33 Disassembling the connector Step 3: Thread the cable through the swivel nut, cable support sleeve, and connector enclosure in sequence. Figure 8-34 Threading the cables Step 4: Install the network cables to Parallel-1 and Parallel-2 of cable fixture according to the labeling.
  • Page 67 Electrical Connection Click! COM 1 terminal on the inverter Figure 8-36 Inserting the connector to COM 1 Step 6: Secure the assembled connector on COM 1 terminal. Install the connector enclosure back into the COM 1 terminal. Install the cable support sleeve into the enclosure. Tighten M3 screw to secure it.

  • Page 68: Bms Communication Connection

    Electrical Connection 8.6.3 BMS Communication Connection Through BMS-1 and BMS-2 communication terminal, two models of batteries can be communicated with inverter. BMS connection diagram *For detailed connection on the battery side, please see documentation of the battery manufacturer. Figure 8-38 BMS connection diagram BMS wiring procedure Step 1: Loosen the screws on the COM 1 terminal.
  • Page 69 Electrical Connection Figure 8-39 Installing RJ45 terminal to the cable fixture Step 5: Connect the assembled connector to COM 1 terminal. Make sure the cable fixture part is well inserted into the slot of terminal. You will hear an audible "Click" if it is connected securely.

  • Page 70: Rs485 Communication Connection

    Electrical Connection 8.6.4 RS485 Communication Connection For SolaX products, such as the Adapter Box, EV-Charger, and Datahub they can be connected to pin3 and pin 6 or pin4 and pin5. As for pin1, pin2, pin7,and pin8 they can be utilized to connect devices other than SolaX products. If you require simultaneous connections of multiple devices, a splitter adapter can be employed.

  • Page 71: Drm Connection (Applicable To As/Nzs 4777)

    Electrical Connection Step 4: Install the network cable to RS485 of cable fixture according to the labeling. Figure 8-42 Installing RJ45 terminal to the cable fixture Step 5: Connect the assembled connector to COM 1 terminal. Make sure the cable fixture tongue is well inserted into the slot of terminal.
  • Page 72 Electrical Connection Table 8-5 Desciptions of DRM Mode Pin location Requirement When S0 is closed, the inverter shuts down. DRM 0 Pin 6 When S0 is open, the inverter resumes grid connection. When S1 is closed, the inverter does not input active DRM 1 Pin 1 power.

  • Page 73: Com 2 Communication Connection

    Electrical Connection COM 2 Communication Connection 8.7.1 Pin Assignment of COM 2 Terminal The COM 2 terminal is used for Meter/CT connection, ripple control and DIO function. Meter/CT Ripple control Table 8-6 Pin assignment of COM 2 terminal Pin assignment Meter/CT CT_R1_CON CT_S1_CON...

  • Page 74: Meter/Ct Connection

    Electrical Connection Pin assignment DIO port DO_1 DO_2 DI_1+ DI_1- DI_2+ DI_2- GND_COM 8.7.2 Meter/CT Connection The inverter should work with an electric meter or current transformer (CT for short) to monitor household electricity usage. The electricity meter or CT can transmit the relevant electricity data to the inverter or platform.
  • Page 75 Electrical Connection Meter/CT Connection Diagram NOTICE! • The following figures take inverter with Meter DTSU666 as an example. • If you have other power generation equipment (such as an inverter) at home and wants to monitor both equipment, our inverter provides Meter 2 communication function to monitor the power generation equipment.
  • Page 76 Electrical Connection • CT connection diagram CT-T CT-S CT-R Grid E-BAR The arrows direction on the CT must point to the public grid side. Grid Inverter … L line Loads … N-BAR for loads Figure 8-46 CT connection diagram NOTICE! •...
  • Page 77 Electrical Connection CT_S2_CON For CT connection CT_R2_CON Meter/CT wiring procedure Step 1: Loosen the screws on the COM 2 terminal. Pinch the tabs on the sides of the COM 2 connector enclosure and pull it at the same time to remove it. Figure 8-48 Disassembling the COM 2 terminal Step 2: Loosen the swivel nut and pull out the sealing plugs.
  • Page 78 Electrical Connection Step 4: Connect the assembled communication cable into the COM 2 terminal. Secure the assembled connector on COM 2 terminal. Install the connector enclosure back into the COM 2 terminal. Install the cable support sleeve into the enclosure. Tighten M3 screw to secure it.

  • Page 79: Ripple Control Communication Connection

    Electrical Connection 8.7.3 Ripple Control Communication Connection Ripple Control is a common form of grid management. Its communication is based on superimposing a very high frequency signal onto the 50/60Hz mains power. The inverter supports to connect a digital signal source (e.g. ripple control receiver) to the digital input. Requirments for Ripple control •...

  • Page 80: Dio Communication Connection

    Electrical Connection Step 3: Strip approx.6 mm of the cable insulation. Insert the conductors into the 8-pin terminal block and tighten the terminal screws. (torque: 1.5 N·m.) Ensure that the conductors are firmly seated in the terminal. Four-core Four-core Figure 8-56 Connecting to 8-pin terminal block Step 4: Connect the assembled communication cable into the COM 2 terminal.
  • Page 81 Electrical Connection DI_1+ For system switch dry contact input DI_1- DI_2+ Reserved DI_2- Reserved GND_COM NOTICE! • If there is strong interference in the surroundings, it is recommended to use shielding cables and ground the shielding layer of the cables. System switch connection diagram DIO terminal System switch...

  • Page 82: Monitoring Connection

    Electrical Connection Four-core Three-core Figure 8-59 Connecting to 7-pin terminal block Step 5: Connect the assembled communication cable into the COM 2 terminal. Lightly pull the cable to confirm tight insertion and then install the connector back. 0.4 ± 0.1 N·m Figure 8-60 Connecting to the inverter Monitoring Connection The inverter provides a DONGLE terminal, which can transmit data of the inverter to the...
  • Page 83 Electrical Connection SolaX Cloud Router Figure 8-62 LAN mode connection diagram Monitoring wiring procedure Wi-Fi mode: Assemble the dongle; M2.5 0.8 ± 0.1 N·m Figure 8-63 Assembling the dongle Plug the dongle to the inverter. Figure 8-64 Wi-Fi connection procedure CAUTION! •...
  • Page 84 Electrical Connection NOTICE! • The longest connection distance between the router and the equipment should be no more than 100 meters; if there is a wall between the router and the equipment, the longest connection distance is 20 meters. • When the Wi-Fi signal is weak, please install a Wi-Fi signal booster at the appropriate location.

  • Page 85: System Commissioning

    System Commissioning Checking before Power-on Serial Item Checklist Installation • The inverter is correctly installed and securely fixed. • The battery is correctly installed and securely fixed. Wiring • All DC, AC, and communication cables are connected correctly and securely. •...

  • Page 86: Operation Of Lockable Dc Switch

    System Commissioning Operation of lockable DC Switch This series of inverters are provided with two kinds of DC switches: unlockable DC switch (optional; without lock) and lockable DC switch (standard; with lock). For locakable DC switch: The lockable DC switch includes 3 states: ON, OFF, and OFF+Lock. The DC switch is in the OFF state by default.
  • Page 87 System Commissioning Lock the DC switch Rotate the DC switch to OFF state, then rotate the DC switch to the left side; Push the position indicated by the arrow upward (as shown in the diagram below). (Optional) After pushing the position upward, choose to lock the DC switch with a lock.

  • Page 88: 10 Operation On Lcd

    10 Operation on LCD 10.1 Introduction of Control Panel Operating indicator light Timely output power Power Today’s energy Today 0.0KWh Battery Battery indicator light Normal Down Error indicator light Enter Battery connection status Status or error information Battery SOC Figure 10-1 Control Panel •...

  • Page 89: Introduction Of Menu Interface

    Operation on LCD Table 10-2 Definition of keys Definition Exit from the current interface or function ESC key Move the cursor to the upper part or increase the value Up key Move the cursor to the lower part or decrease the value Down key Confirm the selection Enter key...
  • Page 90 Operation on LCD Battery1 System status Battery2 On-grid Meter/CT • Parallel Status: Dispaly all the status data from master inverter when the inverters are parallel-connected. History Data: Display the history data of On-grid, EPS, E_fEEDIN, E_USERDEF • and Error Log. On-grid History Data E_Feedin...
  • Page 91 Operation on LCD Parallel Setting Safety Code Main Breaker Limit Grid Parameters Phase Unbalanced Charger EPS Setting Export Control AS4777 Setting Meter/CT Settings Self Test ExternalGen Reset GMPPT Advance Setting Battery Heating Modbus Extend BAT FUNC External ATS HotStandby Setting Power Factor Pgrid Bias Pu Funtion...

  • Page 92: System On/Off

    Operation on LCD 10.3 System ON/OFF Setting path: Menu>System ON/OFF Select ON or OFF to switch on and off the inverter. The interface is displayed ON by default. When you select OFF, the inverter stops running. ====System ON/OFF==== Switch > <...
  • Page 93 Operation on LCD ====System Status==== ======Battery1======= >U 0.0V 0.0A >Battery1 Battery2 ======Battery1======= Cell Temp 20℃ BMS Connected • On-grid status: Information contains the voltage, current, frequency, and output power of Grid terminal. The "A", "B" and "C" in On-grid A, On-grid B and On-grid C refers to L1, L2 and L3 respectively.

  • Page 94: History Data

    Operation on LCD 10.6 History Data Displaying path: Menu>History Data After entering into the History Data interface, the status of On-grid, EPS, E_Feedin, E_ USERDEF, Error Log will be displayed on the LCD as follows: • On-grid: A record of the output and input electric energy of inverter from grid today and the total.
  • Page 95 Operation on LCD » Consume Today: Electricity bought from grid today. » Consume Total: Total electricity bought from grid since the inverter activated for the first time. =====History Data===== >E_Feedin E_USERDEF Error Log ======E_Feedin====== ======E_Feedin====== >Feedin Today >Feedin Total 0.0kWh 0.0kWh ======E_Feedin====== ======E_Feedin======...

  • Page 96: Setting

    Operation on LCD 10.7 Setting Settings includes User Settings and Advanced Settings. 10.7.1 User Setting Setting path: Menu>Setting ("0 0 0 0 ")>User Setting NOTICE! The default password for User Setting is "0 0 0 0". Setting Date & Time You can set the current date and time of the installation site.
  • Page 97 Operation on LCD Setting Self Use Mode Please refer to "2.7.1 Self-use Mode" for working logic of this mode. Min SOC: Default: 10%; range: 10%~100% • » The minimum SOC of the battery. The battery will not discharge power when the SOC of the battery reaches this value.
  • Page 98 Operation on LCD » Set the amount of SOC to charge the battery from grid (applicable only when the Charge from grid is enabled). » You can set your own target value, i.e. during the forced charging period, the inverter will use both PV & GRID energy to charge the battery SOC to the target SOC value+5%, after the battery SOC meets the target value, if the PV energy is still sufficient, the surplus power will be fed into the grid.
  • Page 99 Operation on LCD » Forced Charg Period Start Time: Time to start charging; default: 00:00; range: 00:00~23:59 » Forced Charg Period End Time: Time to stop charging; default: 00:00; range: 00:00~23:59 » Allowed Disc Period Start Time: Time allows to start discharging (The charging or discharging of the battery depends on the work mode.) default: 00:00;...
  • Page 100 Operation on LCD DisChgPeriod1 can be regarded as Peak shaving period. This period should be set to cover load peaks. Battery will be discharged to shave load peak until battery SOC drops to Min SOC (10% by default). » PeakLimits1: Default:0 W, range: 0-60000 W Once the consumption (grid side) reaches this value, the inverter will start shaving to keep the consumption lower than this value.
  • Page 101 Operation on LCD ==Peak shaving mode== ===ChargeFromGrid=== ChargeFromGrid >ChargeFromGrid > Enable < Reserved_SOC ===ChargeFromGrid=== ===ChargeFromGrid=== >MAX_SOC ChargePowerLimits 1000W Reserved_SOC: Default: 50%; range: 10%-100% • » It can be used in specific time period. In this period, inverter does not allow taking grid energy to charge battery.
  • Page 102 Operation on LCD the grid exceeds the set PeakLimit value, the battery is allowed to discharge power. The excess power beyond the limit is provided by the combination of photovoltaic and battery to ensure that the maximum power purchased from the grid does not exceed the set limit.
  • Page 103 Operation on LCD =====User Setting===== Peak shaving mode >Load Management User PassWord ===Load Management=== ===Load Management=== ===Load Management=== >Mode Select >Mode Select >Mode Select Disable Manual SmartSave » Mode 1 Disable: The Adapter Box function is disabled under this operation mode.

  • Page 104: Advanced Setting

    Operation on LCD • Setting minimum / maximum duration » Minimum duration per on-signal: Minimum working hours, heat pump will work at least the time set here every time been activated. High priority than other power threshold settings. » Maximum duration per day: Maximum working hour limitation per day. High priority than other power threshold settings.
  • Page 105 Operation on LCD NOTICE! • The inverter cannot be connected to the grid before the safety code is correctly set. If there is any doubt about your safety code where the inverter installed, please consult your dealer or SolaX service for details. •...
  • Page 106 Operation on LCD Region Australia A Australia B Australia C New Zealand Standarad AS4777_2022 AS4777_2022 AS4777_2022 Setting New Zealand Code Name Range OV-G-F1 52 Hz 52 Hz 55 Hz 55 Hz 50-55 Hz OVGF1-T 0.1 s 0.1 s 0.1 s 0.1 s OV-G-F2 52HZ...
  • Page 107 Operation on LCD ======Charger===== ======Charger===== ======Charger===== >Charger upper limit >Max Charge >Max DisCharge Current: Current: 60.0A 100% 60.0A Setting Export Control This function allows the inverter to control power output to the grid. The user value set must be less than the maximum value. If the user does not want to supply power to the grid, set User Value to "0".
  • Page 108 Operation on LCD NOTICE! • CT and meter 1 can not be used simutaneously. ====CT/MeterSetting==== ====CT/MeterSetting==== >Select >Select Meter Enable ====CT/MeterSetting==== ====CT/MeterSetting==== >Meter 1 Addr >Meter 1 Direction Positive » Case 3: CT and Meter 2 are connected. (CT for SolaX Hybrid inverter, Meter 2 for another power generation equipment or CT for another power generation equipment, Meter 2 for SolaX Hybrid inverter) For CT setting, please refer to Case 1.
  • Page 109 Operation on LCD • Off: Switch off the shadow tracking function. • Low: Scan the shadow every four hours. • Middle: Scan the shadow every three hours. • High: Scan the shadow per hour. =======GMPPT======= PV1 Control > < Setting Modbus You can set the address and select the braud rate of the external communication protocol for communicating with external equipment.
  • Page 110 Operation on LCD Power 2 Power 3 Power 4 Curve PflockInPoint PflockOutPoint 3Tua SetQuPower1 SetQuPower2 SetQuPower3 Q(u) SetQuPower4 QuRespondV1 QuRespondV2 QuRespondV3 QuRespondV4 Q(u) 3Tua QuDelayTimer QuLockEn Fixed Q Power Q Power • Reactive power control, reactive power standard curve cos Ø = f(P) »...
  • Page 111 Operation on LCD cos Ø Leading 0.9/0.95 *) P/PEmax 0.9/0.95 *) Lagging Curve A » *) If the grid-connected power of the inverter ≤ 4.6 kW, the Power Factor is 0.95 at 1.0 power; if the grid-connected power of the inverter > 4.6 kW, the Power Factor is 0.90 at 1.0 power.
  • Page 112 Operation on LCD » *) Depend on the required Q capacity V1=1.10Vn Qmax V2=1.08Vn=QuVlowRate V3=0.90Vn V4=0.92Vn=QuVlowRate -Qmax Setting Pu Function (Applicable to specific countries, please refer to local grid requirements.) The PU function is a volt-watt response mode required by certain national standards such as VDE 4105.
  • Page 113 Operation on LCD The percentage of rated output power is used as the actual output power. Proportion: Default: 1.00; range: 0.11~1.10. The 30 kW model of this series of inverters supports an output proportion of 0.11-1.00, while other models support an output proportion of 0.11-1.10.
  • Page 114 Operation on LCD divided equally as above and it is unrelated with the loads connected with each phase. Three phase inverter Load 1 Load 2 Load 3 4 kW 5 kW 6 kW 5 kW 5 kW 5 kW Meter Setting EPS Setting Select and enter EPS Setting interface and set Frequency, Min SOC and Min ESC SOC.
  • Page 115 Operation on LCD Peak apparent power (VA) 9750 9750 12999 13000 13000 16250 19500 130% overload Setting AS4777 Setting The function of AS4777 Setting is only activated when the Safe Code is set to Australia and New Zealand, which is only applicable to Australia and New Zealand. Select and enter AS 4777 Settings in Advance Settings interface.
  • Page 116 Operation on LCD • Reset Meter/CT =======Reset======= ====Reset Meter/CT==== Reset Error Log >Reset >Reset Meter/CT > Yes < Reset INV Energy Reset INV Energy • =======Reset======= ===Reset INV Energy=== Reset Meter/CT >Reset >Reset INV Energy > Yes < Reset Wifi •...
  • Page 117 Operation on LCD Setting Extend BAT FUNC This function allows for the extension of battery modules, such as adding a new battery module to an existing system. It is only applicable and functional in on-grid mode. In on- grid mode, enabling this function will make the inverter to charge or discharge the battery SOC to approximately 38%.

  • Page 118: About

    Operation on LCD Select the equipment which needs to be connected and set the corresponding Braud Rate and Address. Take EV Charger as an example, The default baud rate is 9600. =====Internal485===== =====Internal485===== =====Internal485===== >Function Control >Braud Rate >EV Charger Addr: EV Charger 9600 NOTICE!
  • Page 119 Operation on LCD » BatBrand, Bat_M SN (SN of BMS), Bat_PS1 SN (SN of battery module 1), Bat_ PS2 SN (SN of battery module 2), Bat_PS3 SN (SN of battery module 3), Bat_ PS4 SN (SN of battery module 4), Battery M Version (software version of BMS) and Battery S version (software version of battery module).

  • Page 120: 11 Operation On Solax Cloud App

    11 Operation on SolaX Cloud App 11.1 Introduction of SolaX Cloud App SolaX Cloud provides customers with a platform that can monitor SolaX inverter data and set it remotely. The inverter connects the system through Pocket Wifi, Pocket LAN, Pocket 4G or Ethernet direct connection, and upload the operation data to SolaX Cloud every 5 minutes.

  • Page 121: Operation Guide On Solaxcloud Web

    Operation on SolaX Cloud App NOTICE! • The screenshots in this chapter correspond to the SolaX Cloud App V4.2.8. 11.3 Operation Guide on SolaXCloud Web Open a browser and enter www.solaxcloud.com to complete registration, login, add site and other related operations according to the guidelines of user guide. Figure 11-3 User guide on Web...

  • Page 122: 12 Troubleshooting And Maintenance

    12 Troubleshooting and Maintenance 12.1 Power off Turn off the system by System ON/OFF on LCD screen. Switch off the battery or the load-break switch of the battery (see documentation of the battery manufacturer). Turn off the AC switch between the inverter and the power grid. Set the DC switch to “OFF”.
  • Page 123 Troubleshooting and Maintenance Error Code Fault Descriptions and Diagnosis IE 03 Grid Volt Fault Power grid voltage overrun • Wait a moment, if the utility returns to normal, the system will reconnect. • Please check if the grid voltage is within normal range.
  • Page 124 Troubleshooting and Maintenance Error Code Fault Descriptions and Diagnosis IE 12 RC OCP Fault Overcurrent protection fault. • Check the impedance of DC input and AC output. • Wait for a while to check if it's back to normal. • Or contact SolaX for help. IE 13 Isolation Fault Insulation fault...
  • Page 125 Troubleshooting and Maintenance Error Code Fault Descriptions and Diagnosis IE 21 Low TempFault Low temperature fault. • Check if the ambient temperature is too low. • Or contact SolaX for help if it can not return to normal. IE 25 InterComFault Inter_Com_Fault •...
  • Page 126 Troubleshooting and Maintenance Error Code Fault Descriptions and Diagnosis IE 33 ParallelFault Parallel Fault • Check the communication and earth cable connection and matching resistor settings. • Or contact SolaX for help if it can not return to normal. IE 36 HardLimitFault HardLimitFault •...
  • Page 127 Troubleshooting and Maintenance Error Code Fault Descriptions and Diagnosis IE 106 Bat Temp Low Battery temperature low • Check the battery installation environment to ensure good heat dissipation. • Check if the battery heat function is enabled on the LCD screen of inverter and the heating time period is correctly set.
  • Page 128 Troubleshooting and Maintenance Error Code Fault Descriptions and Diagnosis BMS1_OverVolt Over voltage in battery system BE 03 • Please contact SolaX for help. BMS2_OverVolt BMS1_LowerVolt Low voltage in battery system BE 04 • Please contact SolaX for help. BMS2_LowerVolt BMS1_ChargeOCP Battery fault - over charge fault BE 05 •...
  • Page 129 Troubleshooting and Maintenance Error Code Fault Descriptions and Diagnosis BE 17 TypeUnmatch1 Battery type fault • Upgrade the battery BMS software. TypeUnmatch2 • Please contact SolaX for help. BE 18 Ver Unmatch1 Battery version mismatch fault • Upgrade the battery BMS software. Ver Unmatch2 •...
  • Page 130 Troubleshooting and Maintenance Error Code Fault Descriptions and Diagnosis AirSwitchBreaker1 Battery air switch fault BE 30 • Check if the battery breaker is off. AirSwitchBreaker1 • Please contact SolaX for help. • Check if the inverter correctly and normally connected to PV, battery or grid. Screen not on •...

  • Page 131: Maintenance

    Troubleshooting and Maintenance Error Code Fault Descriptions and Diagnosis • Check if the meter/CT is connected correctly. • Check if the meter/CT parameter on the LCD No Feedin data (on screen displays normally. App or Web) • Check if the monitoring module works normally. •...

  • Page 132: Replacement Of Fans

    Troubleshooting and Maintenance General status • Check if there is any damage on the Every 6 months of inverter inverter. • Check if there is any abnormal sound when the inverter is running. 12.3.2 Replacement of Fans When the fan is not rotating and the feedback speed of the fan is 0, the LCD screen will display FAN1FAULT / FAN2FAULT / FAN3FAULT error.

  • Page 133: Upgrading Firmware

    Troubleshooting and Maintenance 12.3.3 Upgrading Firmware WARNING! • Please make sure that the category format is correct, do not modify the firmware file name. Otherwise, the inverter may not work! WARNING! • Do not modify the folder name and file path where the firmware file is located, as it may cause the upgrade to fail.
  • Page 134 Troubleshooting and Maintenance screen returns to the Update page. ====Upgrade (ARM)==== ====Upgrade (ARM)==== >XXX.XXXXX.XX_ULT_3P_ Upgrading..25% ARM_V001.07_0606.usb For DSP: Please wait for 10 seconds. When Update page shown as below, press down to select DSP and then press Enter key. Please confirm the firmware version again and press Enter to upgrade.

  • Page 135: 13 Decommissioning

    13 Decommissioning 13.1 Disassembling the Inverter WARNING! • When disassembling the inverter, strictly follow the steps as below. NOTICE! • The AC terminals, battery terminals, and PV terminals should be disassembled using the dedicated disassembly tool provided with the package. This is to prevent any damage to the equipment or potential injury to personnel.
  • Page 136 Decommissioning Figure 13-2 Releasing the PV connector Step 7: Slight pull the dongle module. Figure 13-3 Removing the dongle Step 8: Disconnect the battery connecters: Insert the removal tool into the notch of connectors and slight pull the connectors. Figure 13-4 Removing the Battery connector Step 9: Disconnect the AC connector: Insert the removal tool to the slot of the AC connector to release it.
  • Page 137 Decommissioning Figure 13-5 Removing AC connector Step 10: Disconnect the COM 1 connector and COM 2 connector: Please loosen the swivel nut of the COM connector and anti-clockwise loosen M3 screw of the communication connector by cross screwdriver. Pinch the tabs on the sides of the connector and pull the connector at the same time to remove it.

  • Page 138: Packing The Inverter

    Decommissioning 13.2 Packing the Inverter • Load the inverter into the original packing material if possible. Figure 13-7 Packing the inverter • If the original packing material is not available, use the packing material which meets the following requirements: » Suitable weight and dimensions for inverter.

  • Page 139: 14 Technical Data

    14 Technical Data • INPUT PV Model X3-ULT-15KP X3-ULT-15K X3-ULT-19.9K X3-ULT-20K X3-ULT-20KP X3-ULT-25K X3-ULT-30K Max. PV array 30000 30000 40000 40000 40000 50000 60000 power [Wp] Max.input PV 30000 30000 40000 40000 40000 50000 60000 power [W] Max. DC voltage 1000 Norminal DC operating voltage...
  • Page 140 Technical Data Model X3-ULT-15KP X3-ULT-15K X3-ULT-19.9K X3-ULT-20K X3-ULT-20KP X3-ULT-25K X3-ULT-30K Displacement 1 (-0.8 ~ 0.8) power factor Total harmonic distortion (THDi, < 3% rated power) Maxinum out fault current [A] Maximum output overcurrent protection [A] • INPUT AC Model X3-ULT-15KP X3-ULT-15K X3-ULT-19.9K X3-ULT-20K X3-ULT-20KP X3-ULT-25K X3-ULT-30K Norminal AC 15000 15000...
  • Page 141 Technical Data EPS rated current 22.8 22.8 30.4 30.4 30.4 37.9 45.5 [A] [220V] EPS rated current 21.8 21.8 29.0 29.0 29.0 36.3 43.5 [A] [230V] Switchover time < 10 [ms] Total harmonic distortion (THDv, < 3% linear Load) • EFFICIENCY Model X3-ULT-15KP X3-ULT-15K X3-ULT-19.9K X3-ULT-20K X3-ULT-20KP X3-ULT-25K X3-ULT-30K Max.
  • Page 142 Technical Data Model X3-ULT-15KP X3-ULT-15K X3-ULT-19.9K X3-ULT-20K X3-ULT-20KP X3-ULT-25K X3-ULT-30K Humidity [%] 0 ~ 100 Altitude [m] < 3000 Storage -40 ~ +70 temperature [℃ ] Noise emission < 45 (typical) [dB] Over voltage PV: Ⅱ ; Main: Ⅲ category •...

  • Page 143: 15 Appendix

    15 Appendix 15.1 Generator Application Introduction of generator application In certain regions where utility power is unstable, the use of generators becomes necessary to ensure uninterrupted operation of loads. The characteristic of this system is its ability to seamlessly switch to generators combined with an energy storage system, forming a new power supply configuration in the absence of utility power.
  • Page 144 Appendix ① Wiring connection diagram CLOUD Meter Grid EPS loads Generator Common loads Figure 15-1 ATS control wiring diagram ② Inverter settings for ATS control mode Setting path: Menu>Setting>Advance Setting>ExternalGen Select and enter ExternalGen interface and select ATS Control. =====ExternalGen===== >Function Control ATS Control Set the relative parameters as below in accordance with actual needs.
  • Page 145 Appendix =====ExternalGen===== =====ExternalGen===== >Forced Charg Period >Allowed Disc Period Start Time Start Time 00:00 00:00 =====ExternalGen===== =====ExternalGen===== >Forced Charg Period >Allowed Disc Period End Time End Time 00:00 00:00 » Charge from Gen and Charge battery to: The SOC which allows the system charging from generator.
  • Page 146 Appendix ② Inverter connection for dry contact mode • Connection terminal-DIO terminal Meter/CT Ripple control Figure 15-3 Connection terminal for generator • Connection pins-Pin 1 and Pin 2 Table 15-1 Connection pins for generator Generator dry System switch dry Application Reserved contact output contact input...
  • Page 147 Appendix =====ExternalGen===== =====ExternalGen===== >Start Gen Method >Start Gen Method Reference soc Immediately » Switch on/off SOC: the option is activated when you select Reference SOC for Start Gen Method. Inverter will turn on the generator when the battery reaches the set Switch on SOC and turn it off when the battery reaches the set Switch off SOC.

  • Page 148: Adapter Box Application

    Appendix =====ExternalGen===== =====ExternalGen===== Charge from GEN >Charge battery to > Enable < 15.2 Adapter Box Application Introduction of Adapter Box application SolaX offers a comprehensive solar home energy management solution by integrating a heating solution into its existing system. With the SolaX Adapter Box G2, users can effectively utilize solar energy by commanding it to power their heat pump using settings available on the SolaX inverter and SolaXCloud.
  • Page 149 Appendix Communication connection with inverter • Connection terminal-RS485 terminal RS485 terminal Figure 15-5 Connection terminal for Adapter Box • Connection pins For SolaX products, such as the Adapter Box, EV-Charger, and Datahub they can be connected to pin3 and pin 6 or pin4 and pin5. •...
  • Page 150 Appendix Settings for Adapter Box Setting path: Menu>Setting>Advance Setting>Internal485 Select and enter Internal485 interface. Select the AdapBox G2 and set the Braud Rate and corresponding Address. =====Internal485===== =====Internal485===== =====Internal485===== >Function Control >Braud Rate >AdapBoxG2 Addr: AdapBoxG2 9600 NOTICE! • When two equipments need to be connected at the same time, the braud rate and address of the two equipments shall be set to the same.

  • Page 151: Ev-Charger Application

    Appendix 15.3 EV-Charger Application Introduction of EV-Charger application The X3-EVC series are AC EV charger and intended for charging electric vehicles. It should be installed in a fixed location and connected to the AC supply. The EV-Charger can communicate with other devices or systems (inverter, meter, CT, third-party charger management platform, etc.) to realize intelligent control of charging process.
  • Page 152 "8.6.4 RS485 Communication Connection" for specific wire making and connection. Figure 15-9 Connecting to EV-Charger NOTICE! • The EV-Charger in the connection diagram is the home version, and both the home version and fusion version of SolaX's EV-Charger are compatible with X3-ULTRA.
  • Page 153 Appendix Setting for EV-Charger Setting path: Menu>Setting>Advance Setting>Internal485 Select and enter Internal485 interface. Select the EV Charger and set the Braud Rate and corresponding Address. =====Internal485===== =====Internal485===== =====Internal485===== >Function Control >Braud Rate >EV Charger Addr: EV Charger 9600 NOTICE! • When two equipments need to be connected at the same time, the braud rate and address of the two equipments shall be set to the same.

  • Page 154: Datahub Application

    Meter Grid X3-Parallel EPS BOX EPS loads Figure 15-10 Datahub wiring diagram The inverter is connected to the Datahub through the RS485. In the entire system, a maximum of 10 X3-ULTRA series inverters can be connected to the Datahub.
  • Page 155 Appendix Communication connection with inverter • Connection terminal-RS485 terminal RS485 terminal Figure 15-11 Connectiong terminal for Datahub • Connection pins For SolaX products, such as the Adapter Box, EV-Charger, and Datahub they can be connected to pin3 and pin 6 or pin 4 and pin 5. •...
  • Page 156 Appendix NOTICE! • The braud rate, communication protocol and verification method of the inverters connected to the same RS485 terminal of Datahub must be consistent, and the communication addresses of the inverters must be consecutive and not repeated. NOTICE! Datahub 1000 User Manual •...

  • Page 157: Micro-Grid Application

    Appendix 15.5 Micro-grid Application Introduction of Micro-grid application Due to Islanding Effect, on-grid inverter is unable to work during off-grid. This characteristic makes user losing the on-grid inverter PV energy when off-grid. Micro-grid is the function that making hybrid inverter simulate the grid to active on-grid inverter during off-grid by connecting on-grid inverter to hybrid inverter's EPS terminal.
  • Page 158 Appendix Working modes ① Grid on • When PV is sufficient, the hybrid and on-grid inverters power the general and critical loads together. When there is surplus energy on the on-grid inverter, it will also charge the battery connected to the hybrid inverter. •...
  • Page 159 Appendix ② Grid off In this case, the hybrid inverter will simulate the grid so as to make the on-grid inverter can still work. Hybrid and on-grid inverter will power the EPS loads together. If there is surplus energy, it will charge the battery. On-grid inverter CLOUD Grid...
  • Page 160 Grid and EPS connection on X3-ULTRA series inverter. Cable connection (On-grid inverter) Please connect the AC cable of on-grid inverter to the EPS terminal of X3-ULTRA series inverter through a circuit breaker. Please refer to the user manual of specific on-grid inverter.
  • Page 161 Appendix Inverter terminal Meter 2 L2 L3 N Load On-grid inverter Figure 15-16 Connection diagram of Meter on EPS terminal NOTICE! • If a splitter adapter for RJ45 terminal is used, it should be placed in a waterproof enclosure. • Pin definition Table 15-2 Pin defition for meter and CT Application...
  • Page 162 Appendix Setting path: Menu>Setting>Advance Setting>Meter/CT Setting ① For meter 1 and meter 2 solution (Meter 1 for gird connection, Meter 2 for EPS connection) Select and enter the Meter/CT Setting according the setting path. Set the the address and direction of Meter 1: You can check the connection status in Meter/CT Check.

  • Page 163: Parallel Application

    Appendix 15.6 Parallel Application Introduction of Parallel application This series of inverters supports parallel operation in both grid-tied and off-grid modes. It can be paralleled without an external parallel cabinet, supporting a maximum of 3 units, or with an external parallel cabinet, supporting a maximum of 10 units. Requirements for parallel connection •...
  • Page 164 Appendix Parallel connection diagram PV+ PV- Battery PV+ PV- Battery Inverter Inverter Master Slave Grid Grid PE PE R S T R S T Meter/CT Parallel 1 Parallel 2 Parallel 1 Parallel 2 Parallel 1 Meter Grid R S T Parallel R S T Single-phase...
  • Page 165 Appendix PV+ PV- Battery PV+ PV- Battery Inverter Inverter Master Slave Grid Grid PE PE R S T R S T Meter/CT Parallel 2 Parallel 1 Parallel 2 Parallel 1 Meter Grid R S T Three-phase Single-phase Single-phase Single-phase Three-phase Normal Load Normal Load Normal Load...
  • Page 166 Appendix inverter Master inverter Slave 1 inverter Slave 4 inverter Slave 5 Figure 15-19 Power cable connection with X3-Parallel EPS BOX • Powerl cable connection without X3-Parallel EPS BOX. » Use a five-core copper wire to connect the master and slave inverters. »...
  • Page 167 Appendix ② Communication connection - COM1 and COM2 terminals. • Communicaiton connection with X3-Parallel EPS BOX. » Use network cables for Master-Slave inverter connection. » Master inverter Parallel-1 connects to the COM terminal of X3-Parallel EPS BOX. » Master inverter Parallel-2 connects to Slave 1 inverter Parallel-1. »...
  • Page 168 Appendix NOTICE! Installation Guide • Please refer to X3-Parallel EPS BOX for parallel connenction on X3- Parallel EPS BOX side. • Please refer to "8.3 AC Connection" "8.6.2 Parallel Communication Connection" for the corresponding setup on the inverter. Parallel setting ①...
  • Page 169 Appendix ③ External ATS setting Displaying path: Menu>Setting>Advance Setting>External ATS When the X3-Parallel EPS BOX is connected in the parallel system, please enable the function. =====External ATS===== Function Control > Enable < NOTICE! • If the output power does not reach the expected level, you can check whether the output power is set reasonably by following the path: "Menu>...
  • Page 170 Contact Information UNITED KINGDOM AUSTRALIA Unit C-D Riversdale House, Riversdale 21 Nicholas Dr, Dandenong South VIC 3175 Road, Atherstone, CV9 1FA +61 1300 476 529 +44 (0) 2476 586 998 service@solaxpower.com service.uk@@solaxpower.com TURKEY GERMANY KIZILSARAY MAH. 76 SK. LATİF AYKUT Am Tullnaupark 8, 90402 Nürnberg, İŞMERKEZİ...
  • Page 171 SolaX Power Network Technology (Zhejiang) Co., Ltd. Add.: No. 288, Shizhu Road, Tonglu Economic Development Zone, Tonglu City, Zhejiang Province, 310000 P. R. CHINA Tel.: +86 (0) 571-56260008 E-mail: info@solaxpower.com 320101077203 Copyright © SolaX Power Technology (Zhejiang) Co., Ltd. All rights reserved.

This manual is also suitable for:

X3-ult-15kX3-ult-15kpX3-ult-19.9kX3-ult-20kX3-ult-20kpX3-ult-25k ... Show all

Table of Contents

Save PDF
