Summary of Contents for MP Filtri HPB050
- Page 1 HIGH PRESSURE FILTERS INSTALLATION, SERVICE AND MAINTENANCE MANUAL AND SAFETY INSTRUCTIONS INSTRUCTIONS HPB050 HPB050 BOWL KIT PASSION PERFORM...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Page Description General warnings Tools Handling Dimensional drawings Installation Commissioning Standard maintenance Filter element replacement Special maintenance Seals replacement Instructions for use in explosive atmospheres Regulations Spare parts list Ordering code 13.1 Bowl assembly 13.2 Filter element Troubleshooting 14.1 Misuse of the product... -
Page 4: Description
- Connect the filter with an anti-loosening system and regularly check the condition of the connection - The declared performances and the safety of the product are only guaranteed when MP Filtri original spare parts are used - Warranty is only effective if MP Filtri original spare parts are used. -
Page 5: Handling
HPB050 Handling - The unit is shipped in a cardboard box with dimensions depending on the order - The handling must be carried out in accordance with the laws in force in the country of use of the product - Handle the product with care, avoid impacts - Store in a dry and frost-free room - The unit should be stored in a suitable location away from the production area when not in use. -
Page 6: Dimensional Drawings
Dimensional drawings HPB050 Filter length [mm] Ø19 Ø23.7 Ø62 Ø67 O-Ring seal Anti-extrusion ring Drain plug Recommended only length 5 clearance space for maintenance High Pressure filters... -
Page 7: Installation
Parts identification HPB050 HPB050 - HPBX050 Item Description O-Ring seal Anti-extrusion ring Thread-protection seal Installation Drain plug O-Ring seal Anti-extrusion ring Thread-protection seal Drain plug - Check that the system working pressure does not exceed the maximum working pressure of the filter. -
Page 8: Standard Maintenance
Standard maintenance FILTER ELEMENT REPLACEMENT - Check the availability of the right spare filter element by comparing the part number shown on the element with that shown on the spare parts list. - For the disassembly and the assembly of the parts, please refer to the tools table in paragraph 3 - Switch off the system - (Fig. - Page 9 HPB050 - (Fig. 5) Empty the operating fluid from the bowl into the collection vessel - (Fig. 6) Pull the filter element out - Clean the cavity in the housing, the tap and the bowl. Check them for damage - Check the condition of the bowl seals and, if necessary, replace them referring to the “Special maintenance” paragraph - (Fig.
-
Page 10: Special Maintenance
Special maintenance SEALS REPLACEMENT - Check the availability of the right spare filter element by comparing the part number shown on the element with that shown on the spare parts list. - For the disassembly and the assembly of the parts, please refer to the tools table in paragraph 3 - Switch off the system - (Fig. - Page 11 HPB050 - (Fig. 13) Empty the operating fluid from the bowl into the collection vessel - (Fig. 14) Pull the filter element out - Remove all the seal from the bowl and the filter element and prepare the spare parts referring to the list in paragraph 12 - Clean the cavity in the housing, the tap and the bowl.
-
Page 12: Instructions For Use In Explosive Atmospheres
MP FILTRI has carried out a voluntary certification of a part of the product range in compliance with directive 2014/34/EU, in order to guarantee an appropriate degree of safety in these particular conditions. -
Page 13: Spare Parts List
HPB050 12. Spare parts list Spare parts list HPB050 Item Quantity Description Designation / Ordering code Item Q.ty Description Designation / ordering code Complete filter Complete filter See ordering table See “Ordering Code” table Filter element See ordering table Filter element... -
Page 14: Ordering Code
Filtration rating (filter media) Inorganic microfiber 3 µm Inorganic microfiber 6 µm Inorganic microfiber 10 µm Inorganic microfiber 16 µm Inorganic microfiber 25 µm Wire mesh 25 µm Element ∆p 20 bar 210 bar Execution MP Filtri standard Customized High Pressure filters... -
Page 15: Filter Element
Inorganic microfiber 3 µm Inorganic microfiber 6 µm Inorganic microfiber 10 µm 16 µm Inorganic microfiber Inorganic microfiber 25 µm M25 Wire mesh 25 µm Seals EPDM Element ∆p 20 bar 210 bar Execution MP Filtri standard Customized High Pressure filters... -
Page 16: Troubleshooting
14. Troubleshooting 14.1 MISUSE OF THE PRODUCT This product should be connected to a hydraulic line; this must not exceed upper pressure limit of the product. his product should follow all standard operating procedures previously set at the operating location as well as the procedures required by the manufacturer. - Page 17 NOTES High Pressure filters...
- Page 18 NOTES High Pressure filters...
- Page 19 All data, details and words contained in this publication are provided for use by technically qualifi ed personnel at their discretion, without warranty of any kind. MP Filtri reserves the right to make modifi cations to the models and versions of the described products at any time for both technical and/or commercial reasons.
- Page 20 WORLDWIDE NETWORK CANADA CHINA FRANCE GERMANY INDIA SINGAPORE UNITED ARAB EMIRATES UNITED KINGDOM ITALY PASSION PERFORM mp ltri.com...
