ASSEMBLY INSTRUCTIONS FOR THE HH - 24/54

LEG ASSEMBLY

STRETCHER

STEP-I

Unpack, inspect and lay the parts on a clean, flat, soft surface to avoid marring the wood.

NOTE: During assembly of the furniture please match all joints with the corresponding

letters or numbers stamped on the furniture.

WICKER TOP

STEP-II

Find the LEG ASSEMBLY with the numbers or letters

stamped on it and lay it down first. Fit the WICKER TOP,

STRETCHER tenons into the LEG ASSEMBLY mortise

holes as shown in the photographs. Use a rubber mallet to

drive joints together if necessary.

LEG ASSEMBLY

* NOTE *

A TENON

B MORTISE HOLE
