Summary of Contents for BAFANG DP C030.CA

  • Page 1: Table Of Contents

    7.6.3 View the Data 7.7.10 View the Sensor Info 7.6.4 Adjust the Headlight/backlight 7.7.11 View Historical Error Codes 7.6.5 Walk Assistance 7.7.12 View Historical Warn Codes 7.6.6 Bluetooth Function 7.8 ERROR CODE DEFINITION 7.6.7 ANT+ Function BF-UM-C-DP C030.CA-EN June 2024...
  • Page 2: Important Notice

    7.2 INTRODUCTION OF DISPLAY • Model: DP C030.CA • The housing is made of PC/silicone and the LCD screen is made of aluminosilicate glass. BF-UM-C-DP C030.CA-EN June 2024...
  • Page 3: Product Description

    • Smart indication: remaining mileage can be shown as RANGE, energy consumed can be shown as Cal (calories). • Error code indication. • Walk assistance. • Maintenance prompt. • ANT+ • 6 languages: English, German, Dutch, French, Italian, Czech. BF-UM-C-DP C030.CA-EN June 2024...
  • Page 4: Display Overview

    7.4 DISPLAY OVERVIEW (2) (3) Headlight Bluetooth Maintenance Battery Real-time speed Power-assisted mode Power curve Data switch BF-UM-C-DP C030.CA-EN June 2024...
  • Page 5: Control Buttons Overview

    7.5 CONTROL BUTTONS OVERVIEW Down/Walk Assistance " " Press " "/" " to select your desired item on the menu. Up/Headlight " " • Power on/off the HMI. On/Off/Confirm " " • Confirm your selection BF-UM-C-DP C030.CA-EN June 2024...
  • Page 6: Normal Operation

    " " or " " to switch the power-assisted mode and change the power of the motor. The lowest gear is ECO, and the highest gear is BOOST (user setable). The default mode is ECO; OFF means the e-bike is in neutral position. Green TOUR Blue SPORT Indigo SPORT+ Orange BOOST Purple BF-UM-C-DP C030.CA-EN June 2024...
  • Page 7: View The Data

    HMI will decrease, and the light icon appears. • Press and hold the " " again to turn off the headlight, the HMI backlight luminance will increase, and the light icon will disappear. BF-UM-C-DP C030.CA-EN June 2024...
  • Page 8: Walk Assistance

    If no operation within 5s, the mode will be automatically switched to OFF mode. 7.6.6 Bluetooth Function The HMI is equipped with Bluetooth 5.0 BLE module, and can be connected with BAFANG GO+. For detailed functions, see the corresponding App operation instruction.
  • Page 9: Ant+ Function

    " " to select "Metric"/"Imperial", and press " " to save and return to "Unit." To save and return to the main interface, press and hold " " and " " at the same time. BF-UM-C-DP C030.CA-EN June 2024...
  • Page 10: Set The Auto Off Time

    The numbers 1 through 5 correspond to different levels of light sensitivity, from weak to strong. Press " " to save and return to "AL sensitivity". To save and return to the main interface, press and hold " " and " " at the same time. BF-UM-C-DP C030.CA-EN June 2024...
  • Page 11: Reset The Trip

    " " and " " at the same time. Note: The maintenance prompt function is turned off by default. When it is turned on and the ODO of the e-bike exceeds 5,000 km, " " will appear on the HMI. BF-UM-C-DP C030.CA-EN June 2024...
  • Page 12: View The Battery Info

    Press " " or " " to view SW, HW, Wheel Size, and Speed Limit. To return to the main interface, press and hold " " and " " at the same time, or press "BACK" → "EXIT". BF-UM-C-DP C030.CA-EN June 2024...
  • Page 13: View The Sensor Info

    " " to view the last 10 warn messages, "W-Code1" to "W-Code10". To return to the main interface, press and hold " " and " " at the same time, or press "BACK" → "EXIT". Note: For detailed information, see the error code list. BF-UM-C-DP C030.CA-EN June 2024...
  • Page 14: Error Code Definition

    Note: Please read carefully the description of the error code. When the error code appears, please first restart the system. If the problem is not eliminated, please contact your dealer or technical personnel. See Appendix B for the detailed error code list. BF-UM-C-DP C030.CA-EN June 2024...
