DND Mode
The default Do Not Disturb (DND) period is
from 22:00 to 08:00. You can use the app to
disable the DND mode or modify the DND
period. When DND mode is activated, the
robot will not automatically resume cleanup,
the power indicator light will dim, and the
volume of the voice prompts will lower.
Child Lock
Press and hold the button to enable/
disable the child lock. You can also set it in
the app. Once enabled, the robot will not
react to button presses when it is stationary.
When the robot is cleaning or docking,
press any button to stop it.
Charging
After cleaning, the robot will automatically
return to the dock to charge. In pause mode,
press the button to send the robot back
to the dock. The power indicator will breath
as the robot charges.
Note: If the robot fails to find the dock, it will automatically
return to its starting location. Place the robot on the
dock manually to recharge.
Error
If an error occurs, the power indicator light
on the robot will flash red or status indicator
light on the dock will be steady red. A pop-up
notification will receive in the app and a
voice alert may sound.
Notes:
• The robot will go to sleep automatically if left in a
malfunctioning state for over 10 minutes.
• Placing a malfunctioning robot on the dock manually
will end the current cleanup.
Resetting the System
If the robot does not respond when a button
is pressed or cannot be turned off, reset the
system. Press the Reset button, and the
robot will reset automatically.
Note: After resetting the system, scheduled cleaning,
WiFi, etc. will be restored to factory settings.
Restoring Factory Settings
If the robot does not function properly after a
system reset, switch it on. Press and hold the
button and at the same time, press the
Reset button until you hear the "Restoring
factory settings" voice prompt. The robot will
then be restored to factory settings.

Routine Maintenance

C
Note: The frequency of replacement may vary with the
actual situation. If abnormal wear occurs, replace the
parts immediately.
Main Brushes
C1
* Clean every 2 weeks and replace every 6-12 months.
C1-1—Main Brush Cover
C1-2—Latches
C1-3—Main Brush Bearings
C1-4—Main Brush Caps
C1-5—Main Brushes
10
C1-6—Turn over the robot and press the
latches to remove the main brush cover.
C1-7— Remove the main brush and pull out
the main brush bearing.
C1-8— Pull out the main brush caps.
C1-9— After removing the tangled hair or
dirt at both ends of the main
brushes, reinstall them, press the
main brush cover to lock it in place
until hear a click. Make sure that the
main brush cover has been properly
attached.
Notes:
• Main brushes should be wiped down with a wet cloth
and left to dry away from direct sunlight.
• Do not use corrosive cleaning fluids or disinfectants to
clean the main brushes.
Side Brush
C2
* Clean monthly and replace every 3-6 months.
1. Unscrew the side brush screw.
2. Remove and clean the side brush.
Reinstall the brush and tighten the screw.
Omnidirectional Wheel
C3
* Clean as required.
C3-1— Use a tool, such as a small screwdriver, to
pry out the axle and take out the wheel.
Note:
The omnidirectional wheel bracket cannot be removed.
C3-2— Rinse the wheel and the axle with
water to remove any hair and dirt. Dry
and reattach the wheel, pressing it
firmly in place.
