Roborock Q5 DuoRoller+ User Manual page 11

Main Wheels
C4
* Clean as required.
Clean the main wheels with a soft, dry cloth.
Dustbin and Washable Filter
C5
* Clean every week and filter should be replaced every
6-12 months.
C5-1— Press the dustbin latch and slide the
dustbin backwards.
C5-2— Remove the washable filter and empty
the dustbin.
C5-3— Fill the dustbin with clean water.
Gently shake the dustbin, and then
pour out the dirty water.
Note: To prevent blockage, only use clean water without
any cleaning liquid.
C5-4— Rinse the washable filter repeatedly
and tap it to remove as much dirt as
possible.
Note: Do not touch the surface of the filter with your
hands, brush, or hard objects to avoid potential damage.
C5-5— Allow at least 24 hours for the
dustbin and washable filter to dry
thoroughly before reinstalling them.
Note: Purchase an additional filter and alternate if
necessary.
Robot Sensors
C6
* Clean as required.
Use a soft, dry cloth to wipe all sensors,
including:
C6-1—Dock Locator
C6-2—Wall Sensor
C6-3—Four Cliff Sensors
Dust Bag Replacement
C7
* Replace as required.
C7-1— Remove the dustbin cover vertically
as shown.
C7-2— Lift the dust bag out of the dustbin
and discard it.
Note: The dust bag handle seals the bag on removal to
prevent dust leakage.
C7-3— Clean the filter with a dry cloth.
C7-4—Install a new dust bag in place along
the slot and put the dustbin cover
back.
Air Duct
C8
* Clean as required.
C8-1—Unscrew the screws (10) and remove
the cover.
C8-2—Wipe the air duct and cover with a
dry cloth.
C8-3—Reinstall the cover and screw it back
in place.
Charging Contacts
C9
* Clean as required.
Use a soft, dry cloth to wipe the charging
contacts on the robot. Clean the dock
location beacon, charging contacts, and
electrode brushes on the dock.
Battery
The robot is equipped with a high-
performance lithium-ion rechargeable
11
battery pack. To maintain battery
performance, keep the robot charged
during normal use.
Note: If the robot will be left unused for a long period,
turn it off and charge it at least every three months to
avoid battery damage caused by over-discharge.
