Skope ProSpec Series User Manual

ProSpec Series
User Guide
Thank you for purchasing a SKOPE refrigeration product.
Safety
Always observe safety precautions when using any electrical appliance. Read these instructions carefully and keep them for future reference.
WARNING
•
Ensure the appliance is disconnected from the power supply before performing any cleaning or maintenance.
•
Do not cover the grilles or block the entry or exhaust of airflow by placing objects up against the refrigeration unit.
•
Should manual defrosting be necessary, turn off the refrigeration system and allow the ice to melt by air circulation. Collect
ice and water during defrost to prevent a slip hazard. Do not use mechanical methods to remove ice, as this may damage
the refrigeration circuit.
•
Do not use any electrical devices or appliances inside the food storage compartment.
•
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.
•
Do not use this appliance for other than its intended use.
•
Do not insert fingers/foreign objects into any holes.
•
Only use this appliance with the voltage specified on the cabinet rating label.
•
Ensure the appliance has adequate ventilation as this is essential to economical, high performance.
•
Be careful not to touch moving parts and hot surfaces.
•
For your own safety and that of others, ensure that all electrical work is done by authorised personnel.
•
If the power supply flexible cord becomes damaged, it must be replaced by an authorised service agent or similarly qualified person in order
to avoid a hazard.
•
If installing or removing the refrigeration unit, refer to the Installation Guidelines below, and observe all necessary safety precautions.
•
The appliance is not designed to be stable while in motion. Use extreme caution when moving or transporting it.
•
Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
•
Do not exceed a maximum load of 20 kg per shelf or drawer.
•
If the cabinet is to be scrapped, ensure the cabinet is unplugged from the power supply and cut off the mains flex close to the back of the
cabinet. Be mindful of the risk of animals or children becoming trapped in the appliance – either remove or secure doors if necessary.
•
Refrigerant must be removed by a qualified service person and the cabinet recycled/disposed of in accordance with local regulations.
•
When moving a vertical cabinet, always:
•
Use at least two people, as cabinets are heavy and may tip over. This could cause injury to a person, or damage to the cabinet which
requires repair or replacement.
•
Move the cabinet slowly, and with care.
This cabinet is designed to operate within a specific climatic class environment.
See the cabinet rating label inside the cabinet for climate class number.
Climate class Ambient temperature
3 25°C
4 30°C
5 40°C
7 (tropical) 35°C
Shelves
Each shelf is held in place with shelf rails, which clip into the shelf support strips. You can
adjust the height of the shelf rails.
The shelf rails are suitable to use with Gastronorm pans.
Lock/s
The cabinet is fitted with key locks, which can be operated with the supplied key.
Lights
The interior lights switch on and off automatically depending on use.
PRN80218 Rev. 3.0 Jun. 2024
The cabinet includes relevant hazard symbols that may be associated with
the cooler. Refer to the information below for symbol description.
Relative humidity
60%
55%
40%
75%
WARNING
The refrigeration system contains flammable R290
refrigerant. Do not tamper with it.
The refrigeration system must only be serviced by qualified
personnel.
Shelf support strip
Shelf rail
Shelf
Page 1 of 4
