Omni Pro Installation and Operating Instructions
Operation
1. Turn on your TV. (Turn on the power injector.)
Note: You must have a properly installed KING wall mount power injector to operate the KING OmniPro.
2. Perform a channel scan.
Note: See your TV or converter box owner's manual for instructions on performing a channel scan.
https://tiffin-motor-homes-prod.mindtouch.us/Technical_Support/Class_A/2024/Phaeton/44_OH/Component_Manuals/King/O...
Updated: Thu, 11 Jul 2024 14:42:11 GMT
Powered by
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Omni Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KING Omni Pro

Summary of Contents for KING Omni Pro

  • Page 1 Operation 1. Turn on your TV. (Turn on the power injector.) Note: You must have a properly installed KING wall mount power injector to operate the KING OmniPro. 2. Perform a channel scan. Note: See your TV or converter box owner’s manual for instructions on performing a channel scan.

  • Page 2: Antenna Installation

    3. Apply sealant to the base mount, and fill the coax channel with sealant. Place the base mount in position. 4. Fasten the base mount to the roof. Make sure the base mount is sealed all the way around. Make sure the coax https://tiffin-motor-homes-prod.mindtouch.us/Technical_Support/Class_A/2024/Phaeton/44_OH/Component_Manuals/King/O… Updated: Thu, 11 Jul 2024 14:42:11 GMT...

  • Page 3: Specifications

    Specifications Power Dimensions: 9” H x 13” W x 13” L +12 Volt / 100 mA requirement: KING Power Injector OA1000 • OA1001 (supplied with this product) Weight: 2.2 lbs. Power supplied by: OA1000-OE •...

  • Page 4: Power Injector Installation

    Over-the-Air Antenna In Cable TV In Power Button Not Depressed No power to KING OmniPro, and the cable TV signal will be fed to the two TV outputs (if wired for cable TV input). Over-the-Air Antenna In Cable TV In (Cable input must be connected to power injector.
  • Page 5 • Has an internal fuse rated @ 400 mA max. If tripped, the fuse will reset when the circuit cools. • Is not an amplifier. No devices other than those shown below should be connected (unless approved by KING) https://tiffin-motor-homes-prod.mindtouch.us/Technical_Support/Class_A/2024/Phaeton/44_OH/Component_Manuals/King/O…...
