Panduit ATLONA OMEGA AT-OME-MH21 Manual

Panduit ATLONA OMEGA AT-OME-MH21 Manual

Two-input switcher for hdmi and usb-c with usb hub
Hide thumbs Also See for ATLONA OMEGA AT-OME-MH21:

Advertisement

Quick Links

Download this manual
Two-Input Switcher for HDMI and USB-C
with USB Hub
Application Programming Interface
AT-OME-MH21
AT-OME-MH21-CP
1.0.6
Atlona Manuals
Switchers

Advertisement

loading
Need help?

Need help?

Do you have a question about the ATLONA OMEGA AT-OME-MH21 and is the answer not in the manual?

Questions and answers

Related Manuals for Panduit ATLONA OMEGA AT-OME-MH21

Summary of Contents for Panduit ATLONA OMEGA AT-OME-MH21

  • Page 1 Two-Input Switcher for HDMI and USB-C with USB Hub Application Programming Interface 1.0.6 AT-OME-MH21 Atlona Manuals AT-OME-MH21-CP Switchers...

  • Page 2: Version Information

    Version Information Version Release Date Notes Jul 2024 Firmware 1.0.6 - Updated commands AT-OME-MH21 / AT-OME-MH21-CP...
  • Page 3 Introduction General This document provides an alphabetical list of commands available for AT-OME-MH21 / AT-OME-MH21-CP. Commands are case-sensitive. If the command fails or is entered incorrectly, then the feedback is “Command FAILED”. Commands can be sent using RS-232, Telnet, SSH, or TCP. There should be a 500 millisecond delay between each command sent to the unit.
  • Page 4 Introduction RS-232 A 4-pin captive screw connector has been included for RS-232. DE-9 (RS-232) port RS-232 is often connected through a DB 9-pin to captive screw Pin out will be determined by the RS- connector. The pins will have functions associated with them, some 232 cable and connect as RX (receive), will be unassigned.
  • Page 5 Commands Command Description All# Sets all input and outputs to the 1-to-1 state APwrOffTime Sets the power-off time interval AutoSW Enable or disables auto switching or display auto switching status Blink Enables or disables blinking of the POWER button on the front panel CliIPAddr Sets the IP address of the Telnet client when display control is set to IP CliMode...
  • Page 6 Commands Command Description ScalerMode Enables or disables the scaler on the AT-OME-MH21 / AT-OME-MH21-CP SetCmd Assigns an RS-232 or IP command to the specified button on the front panel SHostName Sets the hostname of the AT-OME-MH21 / AT-OME-MH21-CP Status Displays which input is routed to the HDMI output System Displays the status of the AT-OME-MH21 / AT-OME-MH21-CP TrigCEC...
  • Page 7 Commands All# Resets all inputs and outputs to a 1-to-1 state. When set to the state, input 1 is routed to output 1, input 2 is routed to output 2, and so on. Syntax All# This command does not require any arguments Example Feedback All#...
  • Page 8 Commands Blink Enables or disables blinking of the POWER button on the front panel. When set to on, the POWER button will flash, alternating between red and blue, and can be used to physically identify the unit on a network. The POWER button will flash until the off argument is specified.
  • Page 9 Commands CliPass Sets the password for the controlled device when display control is set to IP. Execute the CliPass command without arguments to display the current password. The default password is Atlona. Syntax CliPass X Parameter Description Range Password 20 characters (max.) Example Feedback CliPass R3ind33r...
  • Page 10 Commands CSpara Sets the baud rate, data bits, parity bit, and stop bits for the serial device. Each argument must be separated by a comma; no spaces are permitted. Brackets must be used when executing this command. Syntax CSpara[W,X,Y,Z] Parameter Description Range Baud rate...
  • Page 11 Commands EDIDMSet Assigns an EDID to the specified input. The EDID can be either one of the internal preprogrammed EDIDs or a custom EDID that can be stored in memory. A brief description of each preprogrammed EDID is listed in the table below.
  • Page 12 Commands HDCPSet Set the HDCP reporting mode of the specified port. Some computers will send HDCP content if an HDCP-compliant display is detected. on = reports to the source device that the display (sink) is HDCP-compliant, off = reports to the source device that the display (sink) is not HDCP-compliant (HDCP content will not be sent), auto = uses the attributes of the display device to accept or not accept HDCP content.

  • Page 13: Input Format

    Commands InputBroadcast Enables or disables broadcast messages for input changes. The default setting is off. Syntax InputBroadcast X Parameter Description Range State on, off, sta Example Feedback InputBroadcast on InputBroadcast on InputFormat Returns the video format on the specified input. No space should exist between the command and the argument. Syntax InputFormatX Parameter...
  • Page 14 Commands IPCFG Displays the current network settings for the AT-OME-MH21 / AT-OME-MH21-CP. Syntax IPCFG This command does not require any parameters Example Feedback IPCFG IP Addr 192.168.11.176 Netmask 255.255.255.0 Gateway 192.168.11.1 IP Port 23 IPDHCP Enables or disables DHCP mode on the AT-OME-MH21 / AT-OME-MH21-CP. on = DHCP mode ON; off = DHCP mode OFF;...
  • Page 15 Commands IPLogin Enables or disables the use of login credentials when initiating a Telnet session on the AT-OME-MH21 / AT-OME- MH21-CP. If this feature is set to on, then the AT-OME-MH21 / AT-OME-MH21-CP will prompt for both the username and password. Use the same credentials as the web GUI. on = login credentials required; off = no login required. Use the sta argument to display the current setting.
  • Page 16 Commands IPStatic Sets the static IP address, subnet mask, and gateway (router) address of the AT-OME-MH21 / AT-OME-MH21- CP. Before using this command, DHCP must be disabled on the AT-OME-MH21 / AT-OME-MH21-CP. Refer to the IPDHCP command for more information. Each argument must be entered in dot-decimal notation and separated by a space.
  • Page 17 Commands IRSetCmd Defines the IR command used by the AT-OME-MH21 / AT-OME-MH21-CP to perfom the specified function on the display (sink) device. For example, to define the “display off” command, use the off argument as the first parameter, then locate the equivalent “power off” command for the display by consulting the display’s User Manual. Specify the command as the second argument.
  • Page 18 Commands Lock Locks the buttons on the front panel. This feature is useful when the unit is installed in a rack environment or other remote location, to prevent accidental pressing of the front-panel buttons. Also refer to the Unlock command. Syntax Lock This command does not require any parameters...
  • Page 19 Commands ProjSWMode Sets the time interval before the “display on” command is sent. This value should be the same as the projector’s delay setting. Use the sta argument to display the current setting. Syntax ProjSWMode X Parameter Description Range Time interval 10 ...
  • Page 20 Commands Reboot Executing this command will reboot the unit. All unit settings will remain unchanged. Syntax Reboot This command does not require any parameters Example Feedback Reboot Reboot RepCmdTime Sets the number of time a command will be sent. Some devices may require that a command be sent multiple times before an acknowledge message is sent back to the AT-OME-MH21 / AT-OME-MH21-CP.
  • Page 21 Commands RHostName Displays the hostname of the unit. Execute the SHostName command to set the hostname. Syntax RHostName This command does not require any parameters Example Feedback RHostName RHostName OMEMH21-068823 ScalerMode Sets the scaler mode. When set to OFF, the scaler is bypassed, and the output signal will be the same as the input signal.
  • Page 22 Commands SHostName Sets the hostname of the unit. The hostname can be changed to easily identify the unit within the Atlona Management System (AMS) or a network. If using a custom hostname, it must meet the hostname standards defined here: https://tools.ietf.org/html/rfc1123. Syntax SHostName X Parameter...
  • Page 23 Commands System Displays the status of the AT-OME-MH21 / AT-OME-MH21-CP. The dev argument will display verbose format. The sta argument will display pretty information. Syntax System X Parameter Description Range Request sta, dev Example Feedback System sta Model: AT-OME-MH21 / AT-OME-MH21-CP MAC Addr: B8-98-B0-06-88-23 Address Type: DHCP IP Addr: 192.168.11.176...
  • Page 24 Commands TrigIP Sends the specified command to the display using IP. Syntax TrigIP X Parameter Description Range Command on, off, vol+, vol-, mute Example Feedback TrigIP on TrigIP on TrigIR Sends the specified command to the display using IR. Syntax TrigIR X Parameter Description...
  • Page 25 Commands Type Displays the SKU of the AT-OME-MH21 / AT-OME-MH21-CP. Syntax Type This command does not require any parameters Example Feedback Type AT-OME-MH21 / AT-OME-MH21-CP Unlock Unlocks the buttons on the front panel. Also refer to the Lock command. Syntax Unlock This command does not require any parameters Example...

  • Page 26: Usb Mode

    Commands UsbHostRoute Sets the routing state of the USB host. 1 = USB-C, 2 = USB HOST. Specify the sta argument to return the current setting. Syntax UsbHostRoute X Parameter Description Range Port 1, 2, sta Example Feedback UsbHostRoute 1 UsbHostRoute 1 UsbMode Sets the USB mode for the AT-OME-MH21 / AT-OME-MH21-CP.
  • Page 27 Commands Version Displays the current firmware version of the unit. Syntax Version This command does not require any parameters Example Feedback Version 1.0.5 VOUTMute Enables or disables muting of the output audio. Specify the sta argument to return the current setting. Syntax VOUTMuteX Y Parameter...
  • Page 28 Commands x1All Routes the specified input to all outputs. Syntax x1All Parameter Description Range Input 1, 2 Example Feedback x1All x1AVx1 xYAVxZ Routes the specified input (Y) to the HDMI output (Z). Syntax xYAVxZ Parameter Description Range Input 1 (USB-C), 2 (HDMI) Output 1 (HDMI) Example...
  • Page 29 International atlona.com 408.962.0515 41.43.508.4321 • • 40336-R5...

This manual is also suitable for:

Atlona omega at-ome-mh21-cp
