Update Instructions
Updating the firmware can be completed using either the USB interface or the web GUI. Atlona recommends
using the web GUI for updating the firmware. However, if a network connection is not available, the AT-OME-ST31A
firmware can be updated using a USB-A to USB mini-B cable.

Using the Web GUI

Requirements:
•
AT-OME-ST31A
•
Firmware file
•
Computer running Microsoft Windows
1. Connect an Ethernet cable from the computer, containing the firmware, to the same network where the AT-OME-
ST31A is connected.
2. Launch a web browser and enter the IP address of the AT-OME-ST31A in the address bar.
3. Login to the web GUI, then click System in the menu bar, near the top of the screen.
Choose File button
4. Click the Choose File button, under the Firmware Update section.
5. Browse to the location of the firmware file, select it, and click the Open button.
6. Click the Update button, under the Firmware Update section.
7. The following message box will be displayed.
Atlona Technical Support: +1 877.536.3976 option 1
AT-OME-ST31A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Atlona AT-OME-ST31A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panduit Atlona AT-OME-ST31A

Summary of Contents for Panduit Atlona AT-OME-ST31A

  • Page 1 AT-OME-ST31A Update Instructions Updating the firmware can be completed using either the USB interface or the web GUI. Atlona recommends using the web GUI for updating the firmware. However, if a network connection is not available, the AT-OME-ST31A firmware can be updated using a USB-A to USB mini-B cable. Using the Web GUI Requirements: •...
  • Page 2 Update Instructions 6. Click the OK button to begin the firmware update process. Click the Cancel button to cancel the process. 7. After the firmware update process is complete, the Login screen will be displayed. Using USB Requirements: • AT-OME-ST31A •...
  • Page 3 Update Instructions 3. The USB UPDATE folder will be displayed. If this folder is not displayed, automatically, select the USB UPDATE drive from Windows Explorer. 4. Delete all files from the USB UPDATE drive, if any are present. 5. Drag-and-drop the firmware file to the drive. 6.
