- Page 1 LogTag USB Product firmware updater WORK INSTRUCTION MANUAL © Copyright LogTag Recorders, 2014 Revision 0.02 Tuesday, June 13, 2017...
-
Page 2: Table Of Contents
6. Repeat steps 2-5 to firmware update more USRICs ................... 9 6. P ..........................10 RODUCTION LOG FILES Revision History Date Version Auth Details 24/11/14 0.01 Initial release 12/06/17 0.02 Updated for Multiproduct Firmware Updater LogTag USB firmware updater Work Instruction Manual v0.02 Page 2/10... -
Page 3: Firmware Updater For Usric-8
Example shown below :- Recommended to have option to be powered. 3. Software required Firmware updater installed with version as stipulated by LogTag. For this WIM the examples are generated with firmware updater installer filename “LTFirmwareUpdateInstaller1.2r5.exe” LogTag USB firmware updater Work Instruction Manual v0.02... -
Page 4: Software Installation
4. Software Installation Copy installer to Windows 7/Windows 8.1 production computer. Double click on installer exe file and install software. Click Next > Click Next > Click Install Click Finish LogTag USB firmware updater Work Instruction Manual v0.02 Page 4/10... - Page 5 Note that if required, the software will also install a .NET installer. This will only happen if the operating system is missing required software components. Below shows the additional software installation steps :- Click Next Click Next Click Install Click Finish LogTag USB firmware updater Work Instruction Manual v0.02 Page 5/10...
-
Page 6: Firmware Update Procedure
Software presents similar to the example below :- The first screen presents the possible products that can currently be upgraded or converted, once a selection is made the updater is locked to that product until the program is re-started. LogTag USB firmware updater Work Instruction Manual v0.02... -
Page 7: Plug In Usrics To Be Updated Into Usb Hub
The USRIC(s) in this state will also have both their LEDs on to indicate to the operator that they should be removed. 2. Observe that all USRICs plugged are ready for update. LogTag USB firmware updater Work Instruction Manual v0.02... -
Page 8: Start Programming
Click on ‘Initiate Firmware Upgrade’ or press the ‘Enter’ key to start firmware update programming. The software will display the progress as shown in examples below :- Note: During this action the units being programmed have the RED LED permanently ON. LogTag USB firmware updater Work Instruction Manual v0.02 Page 8/10... -
Page 9: When Firmware Update Is Complete The Software Displays Completion
5.7. Repeat steps 3-6 to firmware update more USB products NOTE: ALWAYS use the Close function or click to exit program DO NOT reset or switch off computer while it is running to avoid production log files becoming corrupted. LogTag USB firmware updater Work Instruction Manual v0.02 Page 9/10... -
Page 10: Production Log Files
6. Production log files An ltl file is generated by the software during use: name format “LT_FirmwareUpdater_USB_” + yyyy- WW.ltl in the “..\Documents\LogTagProduction\Reports” folder. This file should be forwarded to LogTag production for checking/approval. LogTag USB firmware updater Work Instruction Manual v0.02...
