About Your Hardware

Hardware Specifications
Hardware
Processor
Memory
Radios
Antennas
Ethernet Interfaces
Power Interface
Power Consumption
MTBF
(Mean Time Between
Failures)
Dimensions
Weight
Description
Qualcomm Cypress IPQ6010 Quad-core A53 1.8 GHz
NOR Flash: SPI 8 MB
NAND Flash: 256 MB
RAM: DDR4 1 GB (x1)
2.4 GHz 2x2 802.11b/g/n/ax. Max data rate: 574 Mbps
5 GHz 2x2 802.11a/n/ac/ax. Max data rate: 1.2 Gbps
2 x 2.4 GHz, 3 dBi
2 x 5 GHz, 3 dBi
1 x 2.4/5 GHz Scanning radio, 2 dBi (2.4 GHz), 3 dBi (5 GHz)
1 x 10/100/1000 Mbps Gigabit Ethernet (PoE+ In LAN/Uplink) port for a wired
LAN connection. This port also provides PoE+ (802.3at) power for the device.
3 x 10/100/1000 Mbps Gigabit Ethernet ports for a wired LAN connection
1 x 10/100/1000 Mbps Gigabit Ethernet port for a wired LAN connection with
PoE/PSE output power (802.3af, 7W)
PoE In: 54V DC PoE+ (802.3af/at)
DC In: 54V DC 1A
The access point must be connected to PoE+ (802.3at) or a power adapter to enable
power on the LAN4 (PoE Out) port.
Max 20.19W with 802.3af class 2 PSE
Max 13.19W / 10.5 W (avg) without PSE
367,953 hours at 25°C / 77°F
192,621 hours at 40°C / 104°F
130mm x 110mm x 34.2mm (5.12" x 4.33" x 1.34")
384 g (0.847 lb)
