- Page 1 WatchGuard AP AP102 Hardware Guide AP102...
- Page 2 Copyright© 2012–2016 WatchGuard Technologies, Inc. All rights reserved. WatchGuard, the WatchGuard logo, LiveSecurity, and any other mark listed as a trademark in the “Terms of Use” portion of the WatchGuard Web site that is used herein are either registered trademarks or trademarks of WatchGuard Technologies, Inc.
-
Page 3: Hardware Specifications
The WatchGuard AP102 device must be managed by a WatchGuard Firebox or XTM device that uses Fireware XTM OS v11.8.3 or higher. See the AP102 Quick Start Guide or the WatchGuard System Manager help for information about how to use your XTM device to manage your WatchGuard AP device. -
Page 4: Package Contents
Hardware Specifications Package Contents WatchGuard AP device Quick Start Guide Mounting kit About Your Hardware Hardware Specifications MCU Processor Atheros AR9344 533MHz Memory: Flash 16 MB Memory: RAM 128 MB (64 MB x 2) Radio (Radio 1) Atheros AR9344 for switchable 2.4Ghz/5GHz... -
Page 5: Environmental Requirements
Hardware Specifications Environmental Requirements To safely install your WatchGuard AP device, we recommend that you: Install the device indoors or outdoors, preferably under cover. Make sure the device has adequate clearance for air flow and cooling. Connect the device to a surge-protected power source to prevent damage from sudden power changes. -
Page 6: Hardware Description
If you use the optional 12V AC adapter, connect the AC adapter to the device and to a power source. Use only the WatchGuard AC power adapter for this AP device model. If you use a PoE adapter other than the optional PoE adapter from WatchGuard, make sure that it complies with the IEEE 802.3af/at PoE specifications. -
Page 7: Device Indicators
Hardware Specifications Device Indicators The top of the AP device has three status indicators. Indicator Indicator color Interface Status Wireless Not lit Wireless off or disabled Amber 2.4GHz and 5GHz wireless network active Amber flashing Transmitting and receiving data Green 5GHz wireless network active Green flashing Transmitting and receiving data... - Page 8 4. Connect a straight-through Ethernet cable from the WatchGuard AP device Ethernet interface to the OUT connector on the Ethernet Power Injector. See the AP102 Quick Start Guide for detailed steps to remove the rear cover, and connect the Ethernet cable to the AP102 device.
- Page 9 Output Voltage 12VDC 1.25A Use only the WatchGuard AC power adapter for this AP device model. See the AP102 Quick Start Guide for detailed steps to remove the rear cover, and connect the power adapter to the AP102 device. Hardware Guide...
-
Page 10: Mounting Instructions
1. Position the mounting bracket on the wall or ceiling where you want to install the WatchGuard AP device. 2. Use the mounting bracket as a guide to mark the position of the WatchGuard AP device on the wall or ceiling. -
Page 11: Safety Notices
When removing or installing the device, follow the general installation safety instructions. Disclaimer WatchGuard shall not be held liable if the end user alters, modifies, or repairs any WatchGuard hardware appliance. Hardware Guide... - Page 12 Beim Entfernen oder Installieren eines Gerätes, nach den allgemeinen Installation Sicherheitshinweise. AVISO DE SEGURIDAD Todos los productos WatchGuard están diseñados y probados para satisfacer estrictos requisitos de seguridad. Estos requisitos incluyen la homologación de productos de seguridad y otras normas de cumplimiento global.
-
Page 13: Legal And Regulatory Information
2. REMEDIES. If any Product does not comply with the WatchGuard warranties set forth in Section 1 above, WatchGuard will, following the receipt of the product you claim is defective and at its option, either (a) repair the Product, or (b) replace the Product with a like or similar product; provided, that you will be responsible for returning the Product and for all costs of shipping and handling. - Page 14 UNDER THE WARRANTY DO NOT VIOLATE ANY THIRD-PARTY AGREEMENT TO WHICH THE ENTITY IS A PARTY. No change or modification of the Warranty will be valid unless it is in writing and is signed by WatchGuard. All WatchGuard products are designed and tested to meet strict safety requirements. These requirements include product safety approvals and other global compliance standards.
-
Page 15: Declaration Of Conformity
Legal and Regulatory Information Declaration of Conformity Hardware Guide... -
Page 16: Fcc Certification
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. WatchGuard AP102... -
Page 17: Industry Canada Certification
Legal and Regulatory Information Industry Canada Certification This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 18: For Mobile Device Usage
This device may not be used for setting up outdoor radio links in France and in some areas the RF output power may be limited to 10 mW EIRP in the frequency range of 2454 – 2483.5 MHz. For detailed information the end-user should contact the national spectrum authority in France. WatchGuard AP102... - Page 19 Legal and Regulatory Information CE Notice WatchGuard tímto prohlašuje, že tento AP102 je ve shodě se základními požadavky a dalšími Česky příslušnými ustanoveními směrnice 1999/5/ES. [Czech] Undertegnede WatchGuard erklærer herved, at følgende udstyr AP102 overholder de Dansk væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
-
Page 20: R&Tte Compliance Statement
WEEE statutes, and that the recovery of our product per the specific EU country legislative requirements is seamless for our product’s end users. If you have a WatchGuard product that is at its end of life and needs to be disposed of, please contact WatchGuard Customer Care Department at: U.S. Customers: 877.232.3531 International Customers: +1.206.613.0456... - Page 21 In accordance with the regulations, the products of WatchGuard do not need to be registered for the following reasons: WatchGuard does not import more than 1 metric ton per year of a substance as defined by REACH. WatchGuard products are non-chemical products that are not designed to release any substance under normal and reasonably predictable application.
- Page 22 Legal and Regulatory Information China VCCI Notice Class B ITE (Japan) これは VCCI 評議会の基準に基づくクラス B 製品です。本製品がラジオやテレビ受信機の近 くで使用されている場合は、電波障害を引き起こすことがあります。インストールして、 取扱説明書に従って機器を使用しています。 WatchGuard AP102...
- Page 23 Legal and Regulatory Information Korea Mexico La operación de este equipo está sujeta a las siguientes dos condiciones: 1. es posible que este equipo o dispositivo no cause interferencia perjudicial y 2. este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su propia operación no deseada.
-
Page 24: Gnu General Public License ("Gpl")
General Public License. The “Program”, below, refers to any such program or work, and a “work based on the Program” means either the Program or any derivative work under copyright law: that is to say, a work containing the Program or WatchGuard AP102... - Page 25 Legal and Regulatory Information a portion of it, either verbatim or with modifications and/or translated into another language. (Hereinafter, translation is included without limitation in the term “modification”.) Each licensee is addressed as “you”. Activities other than copying, distribution and modification are not covered by this License; they are outside its scope.
- Page 26 This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License. WatchGuard AP102...
- Page 27 Legal and Regulatory Information 8. If the distribution and/or use of the Program is restricted in certain countries either by patents or by copyrighted interfaces, the original copyright holder who places the Program under this License may add an explicit geographical distribution limitation excluding those countries, so that distribution is permitted only in or among countries not thus excluded.
- Page 28 THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. WatchGuard AP102...
