WatchGuard
Quick Start Guide
AP230W
Schnellstartanleitung
Guide de
démarrage rapide
Installer Installieren Instalar インストールする
INSTALL
2
AP
®
Guía Rápida
Mounting Bracket
Activer Aktivieren Activar 有効化する
ACTIVATE
1
watchguard.com/activate
Connecter Verbinden Conectar 接続する
CONNECT
3
PoE+ IN
LAN/Uplink
802.3at (54VDC, 0.6A)
Ethernet
Ethernet LAN Port
LAN Ports
Power Options
WG8599 (US), WG8600 (EU), WG8601 (UK),
WG8602 (AUS)
WG9028 (US), WG9029 (EU), WG9030 (UK),
WG9031 (AUS)
LED
Indicators
Reset
Button
Bracket
Screw Hole
54VDC
(PoE Out)
Power Input
WatchGuard 802.3at PoE+ Injector
with AC cord
Power Supply for WatchGuard
AP230W
