Botex DPX-1210T NET User Manual page 14

Connections and controls
Back
+
PUSH
PUSH
5 4
,
10 [DMX OUT] | XLR output socket, 3-pin, XLR output socket, 5-pin
11 [DMX IN] | XLR input socket, 3-pin, XLR input socket, 5-pin
12 [CH1]...[CH12] | Dimmer outputs, 12 × connection terminals (note the device label when connecting the cables).
13 [INPUT] | Mains connection terminals (note the device label when connecting the cables).
DPX-1210T NET
14
Dimmer Pack
- .
