Connections in 'DMX' mode
Regardless of the actual use, all three blocks should always be connected.
Connect the DMX input of the device to the DMX output of a DMX controller or another DMX
device. Connect the output of the first DMX device to the input of the second one and so on,
to form a series connection. Make sure that the output of the last DMX device in the chain is
terminated by a resistor (110 Ω, ¼ W).
Installation and starting up
DPX-1210T NET
Dimmer Pack
