Operating Instructions
CP MICROTHERM DNA
HOM106450059en-7 • 11/06/2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP THERM Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Intertec Data Systems CP THERM Series

  • Page 1 Operating Instructions CP MICROTHERM DNA HOM106450059en-7 • 11/06/2024...
  • Page 2: Table Of Contents

    www.intertec.info Table of contents 1 General .................................. 3 2 Use...................................  3 3 Specific conditions for use ...........................  3 4 Explanation of symbols for warnings and signal words .................. 3 5 Safety information.............................. 4 6 Installation accessories............................ 4 7 Technical Data ................................  4 8 Installation ................................
  • Page 3: General

    www.intertec.info Operating Instructions CP MICROTHERM DNA General See http://www.intertec.info These operating instructions describe the safe and Specific conditions for use proper way to work with the device. The safety information and instructions given as well as the local 1. The connecting lead shall be installed to provide for accident prevention regulations and general safety permanent wiring and adequate protection against regulations valid in the area of application must be...
  • Page 4: Safety Information

    www.intertec.info Operating Instructions CP MICROTHERM DNA Piece Description NOTICE Heating unit Angle bracket made of flat steel NOTE Packet of screws containing the following: It is essential to pay attention to this safety advice as you Hexagon bolts M 6x12 may otherwise incur material damage.
  • Page 5: Installation

    www.intertec.info Operating Instructions CP MICROTHERM DNA Temperature class Thermostat Rated output Rated voltage/Operating voltage Year of manufacture Illustration 1: Example: CP MICROTHERM DNA 50 T3 TS10 label Installation NOTICE Carefully remove When removing from the packaging and during transport, the connection line must not be stressed or bent.
  • Page 6 www.intertec.info Operating Instructions CP MICROTHERM DNA Additional equipotential bonding is required. The terminal block designated for this purpose has the ground sign. In a TT or TN system, a residual current device (RCD) must be used where the measured triggering residual current does not exceed 100 mA.
  • Page 7 www.intertec.info Operating Instructions CP MICROTHERM DNA CAUTION Sufficient heat dissipation must be ensured. Unauthorized covers must be removed as otherwise there is the risk of the heater overheating. Terminal box The heating circuit is permanently disconnected by a temperature melt fuse which can't be reset if these installation instructions are not adhered to.
  • Page 8 www.intertec.info Operating Instructions CP MICROTHERM DNA If the heater fails, check the installation. Carry out a NOTICE continuity test on the heating circuit. Pay attention to the connection diagram switching point Environmental damage may be caused if thermostat! disposed of incorrectly! In the case of overheating, the thermal indicator (see Electrical scrap and electronics components are subject figure) indicates a discoloration.
  • Page 9: 16 Further Information And Service

    www.intertec.info Operating Instructions CP MICROTHERM DNA Further information and service If the information contained in this instruction manual should not be sufficient in any way, then INTERTEC would be glad to be at your disposal to provide further information and service. Please contact your INTERTEC contact person or directly contact INTERTEC-Hess GmbH...
