In the box
1
2

Set up the system

Step 1 - Connect to power

The system must be correctly grounded. Refer to the Safety and Compliance Manual (80669C) for
grounding requirements available at www.hypertherm.com/docs.
Voltage configurations
To operate the plasma power supply at full output as rated, your electrical service must be sufficient
for your system. Refer to the table below for the maximum rated output for several typical input
voltages.
Unit
CSA / CE / CCC
CSA
CE / CCC
CE / CCC
CSA
*Hypertherm recommends that you use time-delay fuses.
Powermax45 SYNC Getting Started Guide
3
4
NOTICE
Input voltage
(functional range)
200 V - 240 V
208 V
230 V / 220 V
400 V / 380 V
480 V
811520MU
5
6
1 Documentation
2 SmartSYNC
3 15° or 75° hand torch with lead
or machine torch with lead
4 Work clamp with work lead
5 Region-specific gas inlet fitting
6 Power cord
7
7 Remote-start pendant (optional -
mechanized configurations only)
Input current at
Phase
rated output
1-phase 33 A - 40 A
1-phase 37 A
1-phase 34 A / 35 A
3-phase 12 A / 13 A
3-phase 10 A
Revision 0 English
Getting Started Guide
cartridge
®
Input current
at rated arc Fuse*
stretch
36 A - 44 A 50 A
43 A 50 A
37 A / 39 A 50 A
15 A - 20 A 20 A
12 A - 17 A 20 A
3
