- Page 1 Wheelchair Life i Directions for use 000690946.GB...
- Page 2 Wheelchair Components We at SUNRISE MEDICAL have been awarded the ISO-13485 certificate, which affirms the quality of our products at every stage, from R & D to production. This product complies with the standards set forth in EU and UK regulations. Options or accessories shown are available at extra cost.
- Page 3 ° 1125 1190 1130 < 10° 10° 10° MAX. < 10° 10° 10° MIN. < 120° 12° -5° X° MAX. < X° X° 110° 0° 30° MIN. 20,0 14,5 2,2 KG Rev. I Quickie Life i...
- Page 4 ° 123 mm 123 mm 123 mm 4” 5” 6” 6” (101.6 mm) (127 mm) (152.4 (152.4 Quickie Life i Rev. I...
- Page 5 ° 22” 24” (558.8 mm) (609.6 mm) Rev. I Quickie Life i...
- Page 6 ° 4” 5” 6” 7” (101.6 (127 (152.4 (177.8 143 mm 480* 510* 168 mm 510* 530* Quickie Life i Rev. I...
- Page 7 7 Nm 7 Nm 7 Nm 7 Nm 7 Nm 7 Nm 7 Nm 30 Nm 7 Nm 7 Nm 10 Nm 7 Nm 10 Nm 7 Nm Loctite 243 50 Nm M6 = 7.0 Nm Rev. I Quickie Life i...
-
Page 8: Table Of Contents
The manufacturer reserves the right to alter without notice any weights, measurements or other technical data shown in this manual. All figures, measurements and capacities shown in this manual are approximate and do not constitute specifications. Dealer signature and stamp Quickie Life i English Rev. I... - Page 9 Sunrise Medical either in writing or by telephone or find the partner in your life. information on www.sunrisemedical.co.uk For Sunrise Medical, it is very important that we have a good Sunrise Medical relationship with our customers. We like to keep you up-to-date Thorns Road about new and current developments at our company.
-
Page 10: Area Of Application
The intended lifetime of this product is 5 years. physical and psychological constitution, the age of the person, Please DO NOT use or fit any 3rd party components to the living conditions and environment wheelchair unless they are officially approved by Sunrise Medical. Contraindication: DANGER! • Perception disorder •... -
Page 11: General Safety Notes And Driving Limits
• Secure your wheelchair on uneven ground or when active light. transferring, e.g. into a car, by using the brakes. • To avoid falls and dangerous situations, you should first practice using your new wheelchair on level ground with good visibility. Rev. I English Quickie Life i... - Page 12 When wheelchair is significantly lighter and easier to manoeuvre using safety elements offered by SUNRISE MEDICAL and when the rear wheels are pumped up correctly and both using a specially designed safety system, lightweight wheels have the same pressure.
-
Page 13: Warranty
The warranty will only cover manufacturing defects 2. To enforce the warranty, please contact Sunrise Medical Customer Service with the exact details of the nature of the difficulty. Should you be using the wheelchair outside the area covered by the Sunrise Medical customer service agent, repairs or replacement will be carried out by another agency as designated by the manufacturer The wheelchair must be repaired by a Sunrise Medical designated Customer Service agent, (dealer). -
Page 14: Transportability
Failure to do advice must be followed: so will invalidate the ability of a Sunrise Medical wheelchair to be transported within a vehicle. 1. Confirm that the vehicle is suitably equipped to transport a 9. - Page 15 The upper torso restraint belt must fit over the shoulder and across the shoulder as illustrated in Fig D and E. Fig. G Fig.C Fig.E PREFERED PREFERED ZONE ZONE Fig.D Fig. H Fig. F Rev. I English Quickie Life i...
-
Page 16: Handling
Release the button to lock the wheel in place. The quick- release button should snap back to its original position. Fig. 4.0 Fig. 5.0 Fig. 4.1 Quickie Life i English Rev. I... -
Page 17: Options
To readjust, loosen screw and set the appropriate interval. Then re-tighten the screw (Fig. 6.0, 6.1, 6.2). After each adjustment of the rear wheels, check the interval to the wheel locks and readjust if necessary. Rev. I English Quickie Life i... -
Page 18: Footplates
Fig. 6.7 Fig. 6.7 adjusted, please undo the screw (1), set the desired width, by positioning 1, 2 or 3 spacers (2) from outer to the inner side and then refit the screws, (Fig. 6.7): Quickie Life i English Rev. I... - Page 19 Fig. 6.14 Fig. 6.14 Fig. 6.13 Fig. 6.13 Fig. 6.18 FIG. 6.19 AMPUTEE SUPPORT (Fig.6.15). The Amputee Support can be adjusted in every direction as required. FIG.19 Fig. 6.15 Rev. I English Quickie Life i...
-
Page 20: Castor
If necessary, the brakes and castors must be re-adjusted. both sides are at the same height and then re-tighten the screws. Please note the torque required (see the page on Fig. 6.21 Fig. 6.22 torque). Fig. 6.19.2 Quickie Life i English Rev. I... -
Page 21: Sedeo Back
The back sling upholstery can be accessed from the inside via an opening and can be padded to suit individual tastes. WARNING! Ensure that each strap is firmly secured before using the wheelchair. Rev. I English Quickie Life i... -
Page 22: Headrest
(2). CAUTION! Make always sure that the Fig. 6.33 Fig. 6.34 Fig. 6.34 connections are set Fig. 6.35 properly to avoid injuries. Fig. 6.32.1 Fig. 6.35 Fig. 6.36 Quickie Life i English Rev. I... -
Page 23: One Hand Operation Armpad
CAUTION: one hand. • Neither the sideguards nor the armrests are to be used for lifting or carrying the wheelchair. • Take care of your fingers when adjusting the arm pad height. Rev. I English Quickie Life i... -
Page 24: Options - Hemiplegic Armrest
2. Height adjustment of the locking lever 3. Release lever 4. Armrest Pad 5. Transfer bar 6. Sideguard 7. Receiver 8. Adjustment clamp Fig. 6.44 Fig. 6.43 9. Parts to adjust the receiver 10. Clamp screws Quickie Life i English Rev. I... -
Page 25: Push Handles
This device permits crutches to be transported directly on a wheelchair. It has a Velcro loop to fasten crutches or other aids. CAUTION! Never try to use / remove the crutches or other aids while moving. Rev. I English Quickie Life i... -
Page 26: Pelvic Restraint Belt
The lap belt should be adjusted to suit the end user as detailed (Fig. 6.49) above. Sunrise Medical recommends that the length and fit of the belt be checked on a regular basis to reduce the risk of the end user inadvertently re-adjusting the belt to an excessive length. -
Page 27: Seat Sling
Separate sling A from sling B, set the desired position and then be sitting in the wheelchair. push both slings back together, one on top of each other. Fig. 6.54 Fig. 6.52 Fig. 6.53 Fig. 6.51 Rev. I English Quickie Life i... -
Page 28: Transit Wheels
The nameplate indicates the exact model designation and other technical specifications. Please provide the following pieces of information whenever you have to order replacement parts or to file a claim: • Serial number • Order number • Month/Year Quickie Life i English Rev. I... -
Page 29: Maintenance And Care
We therefore recommend that you dispose of seat and back slings to avoid micro-bacterial contamination with active agents according to your local infection protection law. Rev. I English Quickie Life i... - Page 30 Maximum user weight: • Easy Life i = load of 140 kg = 136 kg crash tested = 100 kg with lightweight wheel. Fig. 12.0 192 mm 673 mm 1047 mm Quickie Life i English Rev. I...
- Page 31 Rev. I Quickie Life i...
- Page 32 F: +31 (0)30 – 60 55 880 Sunrise Medical Aps E: info@sunrisemedical.nl Mårkærvej 5-9 www.SunriseMedical.nl 2630 Taastrup Denmark Sunrise Medical HCM B.V. +45 70 22 43 49 Vossenbeemd 104 info@sunrisemedical.dk 5705 CL Helmond Sunrisemedical.dk The Netherlands T: +31 (0)492 593 888 E: customerservice@sunrisemedical.nl...
