Chandler
Installation Guide
For Model:
CHS52
WARNING:
DC Motor will not
operate until blades
are installed
4007498
net weight of fan: 14.88 lb. (6.75 kg)
AND SAVE THEM FOR FUTURE USE

Table of Contents:

Wiring. pg. 7
Warranty. pg. 14
page 1
READ THESE INSTRUCTIONS
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Chandler CHS52 and is the answer not in the manual?

Questions and answers

Related Manuals for Craftmade Chandler CHS52

Summary of Contents for Craftmade Chandler CHS52

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Chandler Installation Guide For Model: CHS52 Table of Contents: Safety Tips. pg. 3 Unpacking Your Fan. pg. 4 Parts Inventory. pg. 4 WARNING: Installation Preparation. pg. 5 DC Motor will not Hanging Bracket Installation.
  • Page 2 Activating Your New Smart Fan; Downloading the Bond Home App • Using your smart device, navigate to the application store (Apple App store or Google Play), download the free Bond Home app and create account. • Ensure the fan and receiver are receiving power from the house by supply using the remote control to turn the fan and light ON and OFF.

  • Page 3: Safety Tips

    (2) this LED light kit must accept any interference received, including interference that may cause undesired operation. Distributed by: Craftmade, 3901 S. 20th Avenue, DFW Airport, TX 75261; 1800 486-4892 NOTE: The important safety precautions and instructions appearing in the manual are not meant to cover all possible conditions and situations that may occur.

  • Page 4: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. Check against parts inventory that all parts have been included.

  • Page 5: Installation Preparation

    blade edge 3. Installation Preparation. 7 feet inches To prevent personal injury and damage, ensure (2.13 m) (76 cm) that the hanging location allows the blades a clearance of 7 feet (2.13m) from the floor and 30 in (76cm) from any wall or obstruction. 12 ft.

  • Page 6: Fan Assembly. Pgs

    5. Fan Assembly. set screw stop pin Remove hanging ball from downrod provided by loosening set screw on hanging ball. Remove pin hanging ball and clip. Lower hanging ball and remove stop pin. Then slide hanging ball off downrod. [Refer to diagram 1.] clip diagram 1 IMPORTANT: NEVER remove set screw from...

  • Page 7: Wiring

    5. Fan Assembly. (cont.) safety cable loop wood With the hanging bracket secured to the outlet box ceiling and able to support the fan, you are now ready to joist hang your fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging wood screw and washer...

  • Page 8: Canopy Assembly

    7. Canopy Assembly. Locate 2 screws on underside of hanging bracket and remove screw closest to the open end of the hanging bracket. Partially loosen the hanging bracket other screw. Lift canopy to hanging bracket. screw Place rounded part of slotted hole in canopy over loosened screw in hanging bracket and push up.

  • Page 9: Light Kit Assembly

    9. Light Kit Assembly. motor housing Remove 1 screw from motor plate on underside of motor housing and partially motor plate loosen the other 2 screws. Align slotted holes in fitter plate with loosened screws in motor plate, allowing molex connections fitter plate from motor housing to come through holes in middle of fitter plate.

  • Page 10: Automated Learning Process./ Activating Code

    10. Automated Learning Process./ Activating Code. REMOTE CONTROL CAUTION: The remote control can be programmed to (back) multiple receivers or fans. If this is not desired, turn wall switch off to any other programmable receiver or fan. Remove battery cover on back side of remote control.

  • Page 11: Remote Control Operation

    11. Remote Control Operation. REMOTE CONTROL I I I Fan SPEED buttons--1: Use to control ceiling fan speeds 1-6 Fan OFF button--2: Use to turn the fan off REVERSE function button--3: Use to control fan direction LIGHTING button--4: Use to control down-light and up-light (if applicable) IMPORTANT : The Automated Learning Process takes approximately 5 minutes to complete.

  • Page 12: Smart Ceiling Fan Wi-Fi Control

    12. Smart Ceiling Fan Wi-Fi Control (Optional) Without Wi-Fi activation, you will not enjoy the expanded features and functionality of your ceiling fan: Breeze speed setting, Creating Schedules and Voice Activation. To enjoy all the potential of your new device, refer to the following steps to complete Smart setup.

  • Page 13: Testing Your Fan

    13. Testing Your Fan. It is recommended that you test fan before finalizing installation. Restore power from circuit box and wall switch (if applicable). Test fan speeds with the different fan speed buttons (I - VI) on remote control. Test the light ON/OFF function by pressing the button;...

  • Page 14: Troubleshooting

    WARNING: Failure to disconnect power supply CRAFTMADE™ LIFETIME LIMITED WARRANTY: prior to troubleshooting any wiring issues may CRAFTMADE warrants this fan for use as intended under result in serious injury. the following provision: CRAFTMADE will replace any fan which has faulty performance due to a defect in material Problem: Fan fails to operate.
