Craftmade CH52 Specifications

DIMENSIONS
A (6" DR) – 20 1 ⁄ D – 6 1
2
B (6" DR) – 17 E – 7
C – 13 1 ⁄
4
All Craftmade fans are shipped
with two down rods,
a 2" for mounting close to the
ceiling, a 6" rod for
mounting farther away.
WARRANTY
Limited Lifetime Warranty
MODEL CH52

SPECIFICATIONS

Blade Sweep – 44", 52", 56"
# of Blades – 5
Blade Pitch – 14°
Motor Size – 188 x 15
AMPS (HI Speed) – .70
Watts (HI Speed) – 80
RPM (HI⁄MED⁄LO) – 210/120/78
⁄
2
FINISHES
Aged Bronze, Saddle Leather,
Burnt Sienna
Chamberlain
Model # CH52AG
w/ B5/52C-CT1
The Chamberlain Fan in Aged Bronze
Finish with Pecan Constantina-Style
Blades.
Shown with LK366 Light Kit (Optional)
STANDARD
OPERATION
CHAIN
™
