KI3600 Power Meter Service Instructions
TARGET AUDIENCE
1) Technicians using this manual should be appropriately qualified to inspect complex electrical device and
to determine basic operating errors. Familiarity with laser optical safety, anti-static and optical fiber
handling procedures is required, otherwise extensive damage can occur.
2) These instructions enable general testing of common problems and do not detail every possible problem
that may occur.
3) If the problem is found to be related to the optics or PCB component failure, then the unit has to be
returned to Kingfisher. Alternatively, contact our Service department for further instructions.
NOTE: If you require technical support, please contact us via email with as much information as possible.
For urgent support enquiries, our Service team would be happy to provide phone support where
appropriate.
To assist you further, the following information available in the User Manual/on our web site at
www.kingfisher.com.au:
Optical Connector Care
Operation Instructions
Product Brochures (including latest Product Specifications)
RETURNING UNITS TO KINGFISHER
If an approved repairer has opened a unit that has to be returned to Kingfisher for any reason, the
repairer's warranty sticker must be in place or the warranty will be void.
Please fill out the Return Material Authorisation (RMA) Form available from our web site at
http://www.kingfisher.com.au/support.htm. RMA form contains all the details you will need to return the
instrument to Kingfisher.
WARRANTY PERIOD
Kingfisher International products are guaranteed against defective components and workmanship for a
period of three (3) years from the date of delivery, unless specifically stated in the original purchase
contract or agreement. This warranty excludes optical connectors or damage/malfunctioning due to
incorrect use.
KINGFISHER INTERNATIONAL PTY LTD
30 Rocco Drive, Scoresby, Victoria 3179 Australia
Phone:
+61 3 9757 4100
Fax:
+61 3 9757 4193
E-mail:
sales@kingfisher.com.au
Website:
http://www.kingfisher.com.au
Revision: 1
Commercial in Confidence
December 2009
Page: 1/8
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kingfisher KI3600
Summary of Contents for Kingfisher KI3600
- Page 1 Product Brochures (including latest Product Specifications) RETURNING UNITS TO KINGFISHER If an approved repairer has opened a unit that has to be returned to Kingfisher for any reason, the repairer’s warranty sticker must be in place or the warranty will be void.
- Page 2 KI3600 Power Meter Service Instructions Commercial in Confidence TABLE OF CONTENTS: SECTION 2 – INITIAL INSPECTION ..................3 SECTION 3 – QUICK REFERENCE GUIDE .................. 3 MODEL: ________________________ REPORT NO: ______________ DATE: ________________ SECTION 7 – QUICK CHECKS ..................... 8...
- Page 3 KI3600 Power Meter Service Instructions Commercial in Confidence SECTION 1 - TOOLS AND EQUIPMENT Tools, instruments and accessories required for the service and performance verification tests are given below: - SM Light Source - SM Light Source, CWDM laser, 1550nm, APC...
- Page 4 KI3600 Power Meter Service Instructions Commercial in Confidence AUTOTEST OPERATION • To start Autotest, press [Autotest] on light source and wait a few seconds. No user action is required from the meter side. • To display just one wavelength at the time on the power meter, press [ λ] or [λ ].
- Page 5 KI3600 Power Meter Service Instructions Commercial in Confidence optical detector or lens. This test is not related to any published instrument specifications, however it is seen as a valuable to avoid practical customer problems. For this test, use Light Source with CWDM laser, 1550nm and SM PC-APC patch lead.
- Page 6 Problems with electro-optic or fiber devices typically require specialised expertise. In our experience, this is best handled by Kingfisher’s service center. Use static protection procedures. • Open battery compartment, remove the batteries and leave cover open. Pull open the optical connector cover.
- Page 7 KI3600 Power Meter Service Instructions Commercial in Confidence Figure 3. Inside KI3600 Power Meter General electrical parameters are as follows: Vss to GND = 3V3, -Vss = -3V3, battery power down current about 0.2 mA, active power meter current about 6.5 mA.
- Page 8 Technical data provided in this manual is given in good faith as part of our program of continuous improvement and is subject to change without notice. It cannot be used as the basis for claims against Kingfisher International or its representatives, if accidental damage or inconvenience results from use or attempted repair of this equipment.
